OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M12KN08-WP-B2 2M

OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M12KN08-WP-B2 2M Specification

Sensor Type
Inductive

Operating Temperature
-25C to +70C

Measurement Range
8 mm sensing distance (flush mount)

Mounting Type
M12 Threaded, Flush/Shielded

Response Time
1 ms

Features
Short circuit protection, Reverse polarity protection, LED indicator

Application
Industrial automation, assembly lines, conveyors

Cable Length
2 meters

Signal Type
Discrete

IP Rating
IP67

Sensitivity
Detects Metals

Power Consumption
10 mA (no load)

Interface
2-wire DC

Wireless
No

Product Type
Inductive Proximity Sensor

Material
Nickel-Plated Brass Housing

Input
10 to 30 VDC

Output
PNP NO (Normally Open)

Function
Object Detection

Usage
Automation, Position Sensing, Metal Detection

Accuracy
High repeat accuracy

Resolution
Standard industrial resolution

Voltage
10-30 VDC

Weight
Approx. 110g

Storage Temperature
-40C to +85C

Model
E2B-M12KN08-WP-B2 2M

Sensing Face Material
PBT

Enclosure Material
Nickel-plated brass

Sensing Target
Ferrous metals (optimal for iron and steel)

Indicator
Operation indicator (Red LED)

Shock Resistance
500 m/s2 (approx. 50G), 3 times in each direction X, Y, Z

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Protection Circuitry
Yes (short-circuit and reverse polarity)

Standards Compliance
CE, RoHS

Housing Diameter
M12

Switching Frequency
Up to 1,000 Hz

Output Type
3-wire, PNP NO

Connection Type
Pre-wired cable

About OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M12KN08-WP-B2 2M

Discover the latest in industrial automation with the customizable OMRON PROXIMITY SENSOR 10 TO 30VDC, model E2B-M12KN08-WP-B2 2M. Famed for its robust nickel-plated brass housing and dazzling performance, this sensor offers excellent short-circuit and reverse polarity protection. Pick yours for superior metal detection and high repeat accuracy, all in a compact M12 design. With an 8 mm flush mount sensing range, IP67 protection, and CE/RoHS compliance, it is crafted for reliability and outstanding durability in demanding environments. Trusted by top suppliers and traders across China.

Exceptional Performance for Automation and Metal Detection

The OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M12KN08-WP-B2 2M, stands out in industrial automation, assembly lines, and conveyor systems. Its high repeat accuracy and standard resolution ensure precise object and position sensing. Made with a durable nickel-plated brass housing and a PBT sensing face, this sensor excels at detecting ferrous metals such as iron and steel, providing dependable usage for various industrial settings.

Payment Terms, Certifications, and Export Markets

We offer flexible payment arrangements to suit your proposal amount and business needs. The OMRON sensor arrives with recognized certifications such as CE and RoHS, ensuring compliance and trust. Our main export markets include Asia, Europe, and North America, delivering excellence to automation suppliers and wholesalers across the globe. Contact us to discuss specific payment and shipping terms for your customized sensor requirements.

FAQ's of OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M12KN08-WP-B2 2M:

Q: How does the OMRON PROXIMITY SENSOR detect metal objects?

A: The sensor uses inductive technology to sense ferrous metals like iron and steel by generating and monitoring electromagnetic fields, making it highly reliable for metal detection in industrial environments.

Q: What is the recommended usage for this sensor?

A: It is ideal for applications such as automation systems, assembly lines, conveyors, and precise position and object detection where accurate sensing of metal components is crucial.

Q: Where can the OMRON E2B-M12KN08-WP-B2 2M be installed?

A: You can install it in harsh industrial settings due to its IP67 protection rating, vibration and shock resistance, and wide operating temperature range, making it suitable for both indoor and outdoor installations.

Q: What process is involved in connecting the sensor?

A: The sensor features a pre-wired cable for easy implementation. Simply mount the M12 threaded body, connect the pre-wired cable to your control system, and use the built-in LED to verify operation.

Q: What are the main benefits of choosing this particular model?

A: This model offers excellent durability, high repeat accuracy, protection circuitry against short circuits and reverse polarity, quick response time, and compliance with CE and RoHS standards.
