PEPPERL FUCHS PROXIMITY SENSOR, SU18-40A/110/115/126A

PEPPERL FUCHS PROXIMITY SENSOR, SU18-40A/110/115/126A Specification

Operating Temperature
-25C to +70C Celsius (oC)

Mounting Type
Flush (Embeddable)

Sensitivity
Adjustable by installation distance

Features
LED switch indicator, short-circuit protection, reverse polarity protection

Interface
2-wire AC connection

Cable Length
2 m, PVC Meter (m)

IP Rating
IP67

Measurement Range
40 mm sensing distance

Application
Metal object detection

Signal Type
Switching (NO)

Wireless
No

Power Consumption
2 VA Volt-Ampere (VA)

Sensor Type
Inductive Proximity Sensor

Product Type
Proximity Sensor

Material
Plastic Housing, Nickel-plated Brass

Input
AC 110/115/126V

Output
Normally Open (NO), 2-wire

Function
Detection of metallic objects without physical contact

Usage
Industrial automation, conveyor systems, position monitoring

Resolution
Precise switching point

Voltage
110/115/126 Vac Volt (v)

Weight
Approx. 75 g Grams (g)

Switching Frequency
15 Hz

Protection Circuits
Surge suppression, overload protection

Hysteresis
3...15% of switching distance

Housing Size
M18 Threaded

Repeat Accuracy
0.1 mm

Material Sensing Face
Plastic

Approvals/Standards
CE, cULus

Thread Size
M18 x 1

Connection Type
Pre-wired cable

Insulation Resistance
> 50 M (at 500 VDC)

Operating Mode
NO (Normally Open), 2-wire AC

Ambient Humidity
35 to 95% RH

Maximum Load Current
200 mA

PEPPERL FUCHS PROXIMITY SENSOR, SU18-40A/110/115/126A Trade Information

Minimum Order Quantity
2 Number

Supply Ability
1000 Per Month

Delivery Time
7 Days

PEPPERL FUCHS PROXIMITY SENSOR, SU18-40A/110/115/126A About

The PEPPERL FUCHS PROXIMITY SENSOR SU18-40A/110/115/126A is a crackerjack masterpiece in metal object detection for industrial automation. Featuring exclusive switching precision (repeat accuracy 0.1 mm), this sensor boasts customizable installation, high sensitivity, and flush mounting versatility. Perfect for conveyor systems and position monitoring, it offers competitive pricing with surge suppression, overload protection, and a robust IP67-rated housing. Superior reliability is ensured through its CE and cULus approvals, while a 40 mm sensing distance and LED switch indicator guarantee seamless, safe, and precise operation. Its pre-wired cable and adjustable sensitivity suit various applications.

Application, Direction of Use, and Features

Ideal for deployment in industrial automation, conveyor environments, and metal object detection, the PEPPERL FUCHS SU18-40A/110/115/126A is mounted flush for optimal sensing performance. Direction of use involves simple installation via its pre-wired cable and M18 threaded housing, with adjustable sensitivity by modifying installation distance. Noteworthy features include an LED switch indicator, robust surge suppression, overload protection, and repeat cycle accuracy that delivers precise results every time.

Sample Availability, Market Reach, and Certifications

Samples of the PEPPERL FUCHS PROXIMITY SENSOR SU18-40A/110/115/126A are available for evaluation, facilitating confident purchasing decisions. Serving the main domestic market and supported by timely delivery, dispatching, and affordable freight options, it stands as a reliable choice for suppliers, traders, and wholesalers across China. Certified with CE and cULus standards, the sensor offers guaranteed quality and consistent performance upon every shipment.

FAQ's of PEPPERL FUCHS PROXIMITY SENSOR, SU18-40A/110/115/126A:

Q: How is the PEPPERL FUCHS SU18-40A/110/115/126A installed for industrial use?

A: The sensor is installed flush to metal surfaces, using its M18 threaded design and pre-wired 2 m PVC cable, ensuring straightforward integration into existing automation setups.

Q: What benefits does the sensor offer in terms of reliability and safety?

A: Equipped with surge suppression, overload and short-circuit protection, CE and cULus certifications, and an LED switch indicator, it delivers high safety, reliability, and operational assurance even in demanding industrial environments.

Q: Where can samples of the PEPPERL FUCHS proximity sensor be obtained?

A: Samples are available through authorized suppliers, traders, and wholesalers in China, facilitating hands-on evaluation prior to bulk purchase or deployment.

Q: When is the sensor's accuracy most advantageous?

A: The sensor's precise switching point and high repeat accuracy are especially beneficial during applications demanding tight tolerances, such as position monitoring and conveyor systems.

Q: What is the process for dispatching and delivery of this proximity sensor?

A: Delivery and dispatch are managed by networked suppliers who ensure prompt shipment with reliable freight options across the main domestic market in China.

Q: How does the adjustable sensitivity enhance usage flexibility?

A: Sensitivity can be modified by adjusting the installation distance, allowing for customized detection settings tailored to various industrial requirements.
