AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-10DN

AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-10DN Specification

Measurement Range
0 - 10 mm (Sensing distance)

IP Rating
IP67

Sensitivity
Adjustable

Mounting Type
Non-flush (standard)

Interface
3-wire DC

Wireless
No

Signal Type
NPN output

Application
Position sensing, counting, automation equipment

Response Time
Max. 2 ms

Power Consumption
Max. 15 mA

Features
LED operation indicator, short-circuit protection

Cable Length
2 meters

Operating Temperature
-25C to +70C

Sensor Type
Inductive Proximity Sensor

Product Type
Proximity Sensor

Material
ABS, Metal

Input
12-24V DC

Output
NPN Normally Open (NO)

Function
Object detection (non-contact)

Usage
Industrial automation, object detection

Accuracy
High precision

Resolution
10 mm

Voltage
12-24V DC

Weight
Approx. 170 g

Protection Circuit
Reverse polarity, surge, overcurrent protection

Case Material
Nickel-plated brass

Frequency
500 Hz

Switching Frequency
500 Hz

Sensing Object
Ferrous metal

Diameter
30 mm

Storage Temperature
-30C to +80C

Control Output
Open Collector

Connection Type
Pre-wired cable

Housing Size
M30

Indicator
Red LED (Operation Indicator)

Insulation Resistance
50 M min. (at 500 VDC)

Hysteresis
10% of sensing distance

Relative Humidity
35% to 95% RH (non-condensing)

About AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-10DN

Unlock a new level of industrial automation with the top-rated AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-10DN. Renowned for its unassailable precision and spectacular reliability, this virtuoso sensor effortlessly detects ferrous metals with a 10 mm resolution, ensuring high accuracy and stability. Outfitted with robust nickel-plated brass housing, LED operation indicator, and comprehensive protection circuits, it stands strong in demanding environments. Enjoy easy installation with its pre-wired 2-meter cable, and shop now to add this superior, high-performance sensor to your automation arsenal. Exported globally from China, it's the ultimate in object detection.

Applications and Key Features of AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-10DN

This sensor is used extensively for position sensing, counting, and non-contact object detection in automation equipment and industrial processes. Its versatility makes it suitable for both general purpose and specific use cases in industrial automation. The machine boasts standout features such as high-resolution sensing (10 mm), adjustable sensitivity, IP67 rating, and strong durability against harsh environmental conditions, ensuring consistent, reliable operation every time.

Export Markets, FOB Port, and Certifications for AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-10DN

Quick dispatch is guaranteed for this product, which is primarily handed over to main export markets across Asia, Europe, and the Middle East. FOB port is typically located in China, ensuring efficient charges and global shipment. Backed by industry certifications and quality guarantees, this sensor arrives ready for integration into your automation systems, meeting international standards with dependable performance and rapid, secure delivery.

FAQ's of AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-10DN:

Q: How does the AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-10DN operate for object detection?

A: The sensor operates using inductive technology to detect ferrous metal objects within a 0-10 mm range, without the need for physical contact. It provides a non-contact, high-precision detection capability, making it ideal for automation and counting processes.

Q: What are the main benefits of using this proximity sensor in industrial automation?

A: This sensor offers spectacular reliability and unassailable accuracy, with a high switching frequency, robust protection features, and an IP67 rating for use in demanding environments. Its versatile applications and adjustable sensitivity ensure efficiency in position sensing and object detection.

Q: Where is the AUTONICS PROXIMITY SENSOR primarily used?

A: It is widely used in automation equipment, manufacturing assembly lines, position sensing, process monitoring, and object counting systems where high precision and durability are essential.

Q: What features contribute to the durability of this sensor?

A: Constructed with a nickel-plated brass case and an ABS/metal build, the sensor offers resistance to harsh environments, moisture, and dust, supported by protection against reverse polarity, surge, and overcurrent.

Q: How can I install or connect this sensor?

A: The sensor features a pre-wired 2-meter cable and a non-flush mounting style, facilitating straightforward and secure integration into existing systems. Simply follow the wiring guidelines and ensure correct voltage and output connections for optimal operation.

Q: What certifications and export terms apply to this product?

A: The AUTONICS PROXIMITY SENSOR is backed by industry-standard certifications, making it suitable for international export. It is shipped under standard FOB terms from China, ensuring quick dispatch and reliable handover to global clients.
