OMRON PROXIMITY SENSOR, E2B-M12KS04-WP-C1

OMRON PROXIMITY SENSOR, E2B-M12KS04-WP-C1 Specification

Mounting Type
Flush Mounting

Power Consumption
15 mA at 24 V DC

Wireless
No

Application
Conveyor systems, packaging, robotics, manufacturing equipment

Sensor Type
Inductive Proximity Sensor

Cable Length
2 meters

Operating Temperature
-25C to +70C

Sensitivity
Adjustable via installation

Interface
Pre-wired cable

Response Time
1 ms

Features
Robust design, water and oil resistant

IP Rating
IP67

Signal Type
PNP Output

Measurement Range
4 mm (sensing distance)

Product Type
Proximity Sensor

Material
Stainless Steel Housing

Input
DC 3-wire

Output
PNP NO (Normally Open)

Function
Non-contact object detection

Usage
Industrial automation, position sensing

Accuracy
High accuracy

Resolution
Detects small metal objects

Voltage
10 to 30 V DC

Weight
Approx. 50 g

Storage Temperature
-40C to +85C

Shell Diameter
12 mm

Reverse Polarity Protection
Yes

Short-circuit Protection
Yes

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Thread Size
M12 x 1

Switching Frequency
1 kHz

Indicator
LED for operation indication

Housing Material
Nickel-plated brass or stainless steel (model dependent)

Shock Resistance
500 m/s2, 3 times in 6 directions

Connection Type
2 m cable

OMRON PROXIMITY SENSOR, E2B-M12KS04-WP-C1 About

Get ahead with advance purchase of the sensational OMRON PROXIMITY SENSOR, E2B-M12KS04-WP-C1 a best-seller in high-precision industrial sensing. This enviable proximity sensor features a ravishing M12 x 1 threaded design, robust stainless steel or nickel-plated brass housing, and a reliable 2-meter pre-wired cable for flush mounting. It delivers high accuracy, detecting small metal objects with a 4 mm range and <1 ms response, backed by LED indication, reverse polarity, and short-circuit protection. IP67 certification, vibration and shock resistance, and a water/oil-resistant build make it indispensable for manufacturing, packaging, and robotics applications.

Ravishing Versatility & Industry-Leading Applications

The OMRON PROXIMITY SENSOR, E2B-M12KS04-WP-C1 is perfectly suited for demanding industrial environments. It excels in conveyor systems, packaging lines, robotics, and complex manufacturing setups, reliably detecting metal components. Its enviable robustness, with IP67 water and oil resistance, gives it a sensational competitive edge for continuous, reliable operation even in harsh media. Suitable for use where precise, non-contact position detection is vital, this sensor ensures optimal accuracy and minimal downtime.

Effortless Sampling, Drop-off, and Secure Shipping

Sample requests for the OMRON PROXIMITY SENSOR, E2B-M12KS04-WP-C1 are efficiently processed with our clear sample policy and high supply ability. Drop-off is available for convenient pickup, and all sensor samples are packed with the utmost care. Secure shipping and swift dispatch ensure your operations never have to wait long. From safe packing to rapid delivery, we seamlessly bridge the path to testing and large-scale deployment.

FAQs of OMRON PROXIMITY SENSOR, E2B-M12KS04-WP-C1:

Q: How does the OMRON E2B-M12KS04-WP-C1 proximity sensor work in industrial automation?

A: The OMRON E2B-M12KS04-WP-C1 operates as an inductive proximity sensor, detecting non-contact metal objects within a 4 mm range. This enables reliable position sensing and automation in manufacturing, conveyor, packaging, and robotics environments.

Q: What primary benefits does this proximity sensor offer for industrial use?

A: Key benefits include high accuracy, robust stainless steel housing, IP67 protection against water and oil, superior vibration and shock resistance, and secure detection of small metal objects, reducing downtime and maintenance needs.

Q: Where is the ideal installation location for the OMRON proximity sensor?

A: This sensor is ideal for flush mounting in environments where metal object detection is needed, such as conveyor beams, automation equipment, and machinery in manufacturing or packaging lines.

Q: What is the process for obtaining a sample of the sensor?

A: Interested buyers can request a sample through our sample policy. We offer efficient packing and dispatch with secure shipping, and drop-off options may be available for convenience.

Q: How is the sensor protected against incorrect wiring and electrical faults?

A: The sensor is equipped with reverse polarity and short-circuit protection to prevent damage caused by incorrect wiring and sudden electrical surges, ensuring reliable and safe operation.

Q: When is it necessary to adjust the installation for optimal sensitivity?

A: Adjustment during installation is necessary to achieve optimal sensitivity based on the size and type of metal objects to be detected and the specific automation environment.
