OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1,12MM DIA,8MM SD

OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1,12MM DIA,8MM SD Specification

Sensitivity
Adjustable by target material

Power Consumption
15 mA (no load)

Sensor Type
Inductive

Measurement Range
Sensing distance: 8 mm

Operating Temperature
25C to +70C

Interface
Cable

Features
Flush mounting, water resistant

Mounting Type
M12 Threaded

Wireless
No

Response Time
1 ms

Application
Position sensing, metal detection

Signal Type
Digital

Cable Length
2 meters

IP Rating
IP67

Product Type
Proximity Sensor

Material
Stainless Steel Housing

Input
DC 3-wire

Output
PNP NO (Normally Open)

Function
Non-contact object detection

Usage
Industrial automation

Accuracy
High accuracy

Resolution
Fine detection up to 8mm

Voltage
10 to 30 VDC

Weight
Approx. 34 g

Shell type
Cylindrical

Detection Surface Material
PBT

Standards
CE, RoHS

Housing Material
Nickel-plated brass

Switching Frequency
Up to 1 kHz

Indicator
LED operation indicator

Diameter
12 mm

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Polarity Protection
Yes

EMC Compliance
Yes

Short-circuit Protection
Yes

Enclosure Rating
IP67 (IEC standard)

Shock Resistance
30 G (3 times each in X, Y, Z directions)

Connection Type
Pre-wired

About OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1,12MM DIA,8MM SD

Explore a rarefied level of precision with the OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1, featuring a top-notch 12mm diameter cylindrical body and 8mm sensing distance. Built for monumental industrial performance, this sensor delivers high accuracy, robust EMC compliance, and IP67 protection, ensuring durability in challenging environments. Its stainless steel housing, advanced short-circuit and polarity protection, and LED operation indicator make it indispensable for metal detection and non-contact position sensing. Shop now-supplies are limited, and this exclusive offer is ending soon.

Advantageous Performance & Industrial Application

The OMRON E2B-M12KN08-WP-B1 proximity sensor provides exceptional reliability and steadfast operation in industrial automation environments. Its high accuracy and fine detection capability up to 8mm make it ideal for precise position sensing of metallic objects. Thanks to its shock and vibration resistance, it thrives in heavy-duty plant settings such as assembly lines, robotics, and machinery safety systems. Its advanced features facilitate smooth processes, ensuring operational efficiency and minimizing downtime in demanding manufacturing applications.

Easy Supply, Flexible Payment & Prompt Delivery

We offer competitive asking prices for the OMRON E2B-M12KN08-WP-B1 sensor, ensuring attractive supply terms for bulk orders or single units. Packing & dispatch are handled with care to guarantee safe delivery, complemented by secure packaging and reliable logistics. Flexible payment terms are available. Samples can be supplied upon request to evaluate before commitment. Standard delivery times are usually prompt, allowing for minimal production delays-explore convenient global shipping options and timely supply fulfillment.

FAQ's of OMRON PROXIMITY SENSOR, E2B-M12KN08-WP-B1,12MM DIA,8MM SD:

Q: How does the OMRON E2B-M12KN08-WP-B1 proximity sensor ensure reliable operation in industrial settings?

A: This sensor features high shock and vibration resistance, IP67 enclosure rating, and robust EMC compliance, making it suitable for demanding industrial and plant environments.

Q: What types of applications are best suited for this proximity sensor?

A: The E2B-M12KN08-WP-B1 excels in position sensing, metal detection, and automation tasks within manufacturing plants, assembly machinery, and robotics.

Q: When should I consider using this proximity sensor instead of other models?

A: Choose this model when you need reliable non-contact detection, high resolution up to 8mm, advanced protection features, and operation in environments subject to shock, vibration, and water exposure.

Q: Where can the OMRON sensor be installed for optimal performance?

A: The sensor's M12 threaded design and flush mounting option make it suitable for integration into control panels, conveyors, and industrial equipment, especially in metal detection zones.

Q: What is the process for ordering, sampling, and delivery?

A: Request a sample before ordering to evaluate performance. Upon confirming the asking price, place your order-after packing and dispatch, timely delivery is ensured through reliable logistics partners.

Q: How does the sensor benefit plant automation and maintenance?

A: The sensor's fast response time, robust construction, and advanced indicator features reduce errors and shutdowns, promoting efficient workflows in automated processes.
