TELEMECANIQUE, LIMIT SWITCH, XCE102C

TELEMECANIQUE, LIMIT SWITCH, XCE102C Specification

Mechanical Life
10 million operations

Protection Level
IP65

Temperature Range
-25C to +70C

Circuit Type
Snap-action switch

Number of Module
Single module

Rated Voltage
Ui 500V

Max. Current
AC15: 3A at 240V AC / DC13: 0.27A at 250V DC

Finish Type
Smooth / Painted

Response Time
Instantaneous

Automation Grade
Industrial

Product Type
Limit Switch

Material
Zamak Alloy (Actuator head), Thermoplastic (Enclosure)

Insulation Resistance
100 M (at 500V DC)

Contact Resistance
25 m (initial)

Max. Voltage
Ui 500V AC

Operating Temperature
-25C to +70C

Stoke
Short stroke with roller plunger

Size
31 x 56 x 30 mm (approx.)

Color
Blue/Black (body) with Silver actuator

Weight
Approx. 120g

Mounting Type
Panel or base mounting

Current Rating
10A

No Of Poles
1NO+1NC

Conduit Entry
PG13.5

Suitable For
Position detection in automation systems

Switching Capacity
10A/500V AC

Shock Resistance
30G (11 ms)

Model Number
XCE102C

Ambient Humidity
35% to 95% RH, non-condensing

Vibration Resistance
10~55Hz, amplitude 1.5mm

Electrical Life
500,000 operations

Contact Configuration
SPDT (1NO+1NC)

Connection Type
Screw terminal

Actuator Type
Roller plunger (top push)

TELEMECANIQUE, LIMIT SWITCH, XCE102C About

Experience enviable longevity and savings with the TELEMECANIQUE LIMIT SWITCH XCE102C. Highlighted for its blue-ribbon performance, this classic automation component offers fresh reliability for position detection in demanding environments. Designed with a roller plunger actuator, SPDT contacts, and a shock-resistant Zamak alloy head, it ensures durability through 10 million mechanical operations. Featuring a robust IP65 rating, smooth finish, and optimized for easy installation, this limit switch combines an impressive electrical life with premium switching capacity-making it a trusted choice for industrial automation.

Versatility in Industrial Applications

The TELEMECANIQUE LIMIT SWITCH XCE102C is custom-built for site-specific and general-purpose usage across automation systems. Commonly deployed in machine safety, conveyance control, and automated assembly lines, its instantaneous response and snap-action circuit are ideal for real-time position detection. Whether for heavy industries, logistics, or manufacturing, this single-module switch adapts seamlessly to both general and specialized applications, ensuring a seamless fit where precision and dependability matter most.

Logistics and Packaging with Assured Quality

Goods featuring the TELEMECANIQUE LIMIT SWITCH XCE102C are expertly shipped from China's premier FOB ports to safeguard timely delivery. Each premium switch is securely packaged to withstand transit rigors, ensuring it arrives in optimal condition. The product comes with standard certifications for industry compliance, reinforcing its quality and reliability. The well-organized logistics management guarantees every batch meets your requirements, with meticulous attention to packaging details for wholesalers, suppliers, and traders.

FAQ's of TELEMECANIQUE, LIMIT SWITCH, XCE102C:

Q: How does the TELEMECANIQUE LIMIT SWITCH XCE102C benefit automation systems?

A: The switch enhances efficiency and safety in automation systems through instant and reliable position detection, reducing downtime and maintenance needs due to its robust design and long operational life.

Q: What types of machinery or environments are suitable for the XCE102C limit switch?

A: It is ideal for industrial automation, machinery safety systems, conveyor belts, and other mechanical assemblies that require precise position feedback and durability in challenging environments.

Q: Where should the XCE102C limit switch be installed for optimal performance?

A: Install the XCE102C on panels or bases near moving machine parts where accurate position detection is needed-preferably within its specified ambient and temperature range for best results.

Q: What certifications and packaging details are provided with each XCE102C unit?

A: Each unit offers industry-standard certifications and is packaged securely to preserve product integrity during logistics and shipment, ensuring it reaches users in premium condition.

Q: How does the short-stroke roller plunger actuator enhance the switch's functionality?

A: The short-stroke roller plunger responds instantly to mechanical movement, ensuring rapid and precise operation in automation, which is essential for time-sensitive control applications.
