OMRON SAFETY DOOR SWITCH, D4NL-4EFG-B

OMRON SAFETY DOOR SWITCH, D4NL-4EFG-B Specification

Protection Level
IP67

Rated Voltage
240 V AC

Finish Type
Matte

Response Time
Instantaneous

Temperature Range
-20C to +55C

Mechanical Life
1,000,000 operations min.

Max. Current
6 A (AC15), 2.5 A (DC13)

Circuit Type
Snap Action

Number of Module
Single

Automation Grade
Industrial

Product Type
Safety Door Switch

Material
Glass-fiber reinforced PBT

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial)

Max. Voltage
240 V AC / 24 V DC

Operating Temperature
-20C to +55C

Stoke
Approx. 20 mm

Size
30 mm 30 mm 82 mm

Color
Red/Black

Weight
Approx. 150 g

Mounting Type
Screw Mount

Current Rating
6A

No Of Poles
4 poles

Auxiliary Contact
Yes (1 NC auxiliary switch)

Electrical Life
100,000 operations min.

Vibration Resistance
10 to 55 Hz, 1.5mm double amplitude

Release Key
Standard flat key

Actuator Insertion Direction
4 directions possible

Standards
EN60947-5-1, EN1088, IEC60204-1

Application
Safety interlocking for guards/doors of machinery

Shock Resistance
1,000 m/s2 (approx. 100G)

Ambient Humidity
95% RH max. (non-condensing)

Connection Type
M20 conduit, pre-wired or connector type

Contact Configuration
3NC + 1NO or as specified

Locking Type
Solenoid Lock (Power-to-lock)

OMRON SAFETY DOOR SWITCH, D4NL-4EFG-B About

Purchase the redoubtable OMRON SAFETY DOOR SWITCH, D4NL-4EFG-B-an incomparable solution for industrial safety interlocking. This must-have component features a meritorious solenoid lock (Power-to-lock), engineered to meet EN60947-5-1, EN1088, and IEC60204-1 standards. Benefit from its versatile actuator insertion in four directions, robust M20 conduit connection, IP67 protection, and glass-fiber reinforced PBT construction. Exceptional reliability is ensured with a meritorious 1,000,000 mechanical operations minimum and 100,000 minimum electrical life. Its snap action mechanism and quick response time make it the ideal safety partner for machinery guards and doors.

Advanced Applications, Robust Usage & Extra Features

Perfect for safety interlocking on guards and machinery doors, the OMRON D4NL-4EFG-B ensures unmatched operational protection. This industrial-grade switch allows effortless mounting and connection, featuring a standard flat release key and backup auxiliary contact. Its meritorious shock and vibration resistance enable consistent performance in demanding environments, while temperature tolerance ranges from -20C to +55C. The snap action circuit and 4-direction actuator insertion offer exceptional flexibility for enhanced installation and usage options.

Production Capability, Domestic Market & Certifications

With a formidable supply ability, the OMRON D4NL-4EFG-B consistently meets bulk order completion for both domestic and export markets. Orders are fulfilled promptly, guaranteeing timely arrival and seamless integration into industrial applications. Certified to stringent international standards, this safety door switch upholds the highest level of reliability and compliance. Whether as a supplier, trader, or wholesaler in China, trust this product's certified performance and widespread availability.

FAQ's of OMRON SAFETY DOOR SWITCH, D4NL-4EFG-B:

Q: How is the OMRON SAFETY DOOR SWITCH, D4NL-4EFG-B typically used in industrial applications?

A: This switch is designed primarily for interlocking guards or doors on industrial machinery, ensuring safe access and preventing operation when guards are not in place.

Q: What makes the D4NL-4EFG-B an incomparable choice for safety interlocking?

A: Its Power-to-lock solenoid lock, multi-directional actuator insertion, IP67 protection, and compliance with multiple international standards make it a standout for industrial safety.

Q: Where can the OMRON D4NL-4EFG-B be mounted, and what connection types are possible?

A: The switch features a screw mount for secure installation and supports M20 conduit, pre-wired, or connector connection types for maximum flexibility.

Q: When is order completion and delivery typically expected for bulk purchases?

A: Order completion and product arrival are efficiently managed, ensuring swift fulfillment for both domestic and export markets.

Q: What is the process for integrating the safety door switch into machinery systems?

A: Mount the switch using the screw mount, connect via the appropriate conduit or pre-wired connector, and ensure correct actuator insertion from any of the four possible directions.

Q: How does using this switch benefit industrial automation safety?

A: It provides reliable interlocking, instantaneous response, durable construction, and long operational life, all contributing to enhanced safety in automated environments.
