PHOENIX RELAY SOCKET, PLC-BSC-24DC/21

PHOENIX RELAY SOCKET, PLC-BSC-24DC/21 Specification

Coil Voltage
24 V DC

Dielectiric Strength
2,500 V AC, 50 Hz, 1 min

Contact Form
SPDT (1CO)

Contact Resistance
100 m

Mechanical Life
10,000,000 Operations

Power Consumption
Approx. 0.53 W

Working Temperature
-40C to +60C

Ambient Temperature
-40C to +60C

Contact Material
AgNi

Protect Feature
Integrated Free-wheeling Diode

Coil Power
0.53 W

Product Type
Relay Socket

Insulation Resistance
>100 M (at 500 V DC)

Theory
Electromagnetic Relay

Usage
General Purpose Relay Interface Module

Contact Load
6 A at 250 V AC/30 V DC

Operate Time
10 ms

Terminal Type
Screw Terminal

Rated Voltage
24 V DC

Supply Terminal
Pluggable Connection

Size
Slim, 14 mm width

Color
Green

Dimension (L*W*H)
80 mm x 14 mm x 80 mm

Weight
Approx. 50 g

LED Status Indicator
Yes (Integrated)

Mounting Type
DIN Rail

Relay Included
Yes, pluggable relay module

Model Number
PLC-BSC-24DC/21

Protection Class
IP20

Vibration Resistance
10...55 Hz, amplitude 0.35 mm

Number of Pins
6

Max Switching Voltage
250 V AC / 30 V DC

About PHOENIX RELAY SOCKET, PLC-BSC-24DC/21

Experience instant savings with our classic PHOENIX RELAY SOCKET, PLC-BSC-24DC/21, a true blue-ribbon masterpiece for relay interfaces. Enjoy the benefits of advance purchase offers on this pluggable relay module featuring a slim 14 mm width and robust general-purpose relay capacity. Its integrated LED status indicator and free-wheeling diode deliver reliable performance, while the 6-pin, 24 V DC coil ensures seamless operation even in demanding environments. With IP20 protection, vibration resistance, high insulation, and SPDT contacts rated up to 6A, this masterpiece guarantees durability and precision. Ideal for industrial automation, it's the supplier's classic interface solution.

Competitive Advantages and Application Flexibility

The PHOENIX RELAY SOCKET, PLC-BSC-24DC/21 stands out for universal compatibility in control panels, machinery, and automation systems. Its slim, space-saving design allows easy DIN rail mounting, making it advantageous for high-density installations. Enhanced by integrated LED status indicators and robust vibration resistance, it provides reliable performance in challenging environments. The pluggable relay and free-wheeling diode integration ensure maintenance ease and longevity, establishing this model as a competitive, cost-effective solution for electrical suppliers, traders, and wholesalers alike.

Swift Delivery, Payment Terms, and FOB Port Details

Place your Purchase Order and experience prompt dispatching of the PHOENIX RELAY SOCKET, PLC-BSC-24DC/21. With efficient logistics from China, orders are handed over promptly for shipment through designated FOB ports to ensure your schedule is met. Flexible payment terms support diverse business needs, while our streamlined distribution guarantees timely delivery. Rest assured that our process minimizes lead time and maximizes reliability for traders, wholesalers, and direct users seeking quick and consistent supply solutions.

FAQ's of PHOENIX RELAY SOCKET, PLC-BSC-24DC/21:

Q: How does the integrated LED status indicator of the PLC-BSC-24DC/21 enhance its operation?

A: The integrated LED status indicator provides instant visual feedback on the relay's operation status, allowing for quick troubleshooting and monitoring without the need for additional indicators.

Q: What competitive advantages does the PHOENIX RELAY SOCKET offer for automation projects?

A: Its compact DIN rail-mountable design, vibration resistance, and integrated features such as free-wheeling diode and pluggable connections reduce installation time and maintenance efforts, making it highly efficient for automation projects.

Q: When can I expect my order to be dispatched after submitting the Purchase Order?

A: Once your Purchase Order is confirmed, the relay sockets are promptly dispatched, and shipment is typically organized through the FOB port specified, ensuring timely delivery.

Q: Where is the main supply and FOB port for this product?

A: The PHOENIX RELAY SOCKET, PLC-BSC-24DC/21 is supplied from China, with main shipment and handover organized through local FOB ports for international delivery.

Q: What is the process for installing the PLC-BSC-24DC/21 relay socket?

A: Installation is straightforward: simply mount on a DIN rail, connect the screw terminals according to your circuit, and plug in the relay module. The pluggable connections facilitate quick replacements.

Q: What are the primary benefits of using this relay socket in industrial applications?

A: Its durability, high mechanical life, integrated safety features, and fast installation make it an ideal solution for use in control panels, machinery, and other demanding industrial environments.
