PEPPERL FUCHS PROXIMITY SENSOR, UB1000-18GM75-U-V15

PEPPERL FUCHS PROXIMITY SENSOR, UB1000-18GM75-U-V15 Specification

Features
Short blind zone, compact design, adjustable measuring range, LED status indicators

Response Time
< 50 ms

Sensitivity
Adjustable via teach-in

Mounting Type
Threaded barrel, M18 x 1

Sensor Type
Ultrasonic sensor

Measurement Range
30 mm to 1000 mm

Interface
V15 connector, 5-pin

IP Rating
IP67

Application
Position and level detection, fill level measurement

Power Consumption
< 1.2 W

Wireless
No

Cable Length
V15 connector type (cable not included)

Operating Temperature
-25 C to +70 C

Signal Type
Analog / Digital

Product Type
Ultrasonic Proximity Sensor

Material
Nickel-plated brass housing, Plastic components

Input
10-30 V DC

Output
Analog output (0-10 V), PNP switching output

Function
Distance measurement and object detection

Usage
Industrial Automation

Accuracy
1% of final value

Resolution
0.18 mm

Voltage
10-30 V DC

Weight
Approximately 60 g

Enclosure Material
Nickel-plated brass and plastic

Material of Sensing Face
Plastic, PBT

Short-circuit Protection
Yes

Housing Dimensions
M18 x 1 thread, 66 mm length

Blind Zone
0-30 mm

Control Elements
Teach-in button

Max Load Current
100 mA

Reverse Polarity Protection
Yes

Switching Frequency
Approx. 5 Hz

Connection Type
Plug, M12 x 1, 4-pin or V15 connector

About PEPPERL FUCHS PROXIMITY SENSOR, UB1000-18GM75-U-V15

The PEPPERL FUCHS PROXIMITY SENSOR UB1000-18GM75-U-V15 is a peerless solution for industrial automation, featuring superlative accuracy at 1% of final value with a flawless measurement range of 30 to 1000 mm. Highly recommended by professionals, it boasts favorable reviews due to its robust nickel-plated brass housing, IP67 rating, and intuitive teach-in button for adjustable sensitivity. Equipped with both analog and digital outputs, short-circuit and reverse polarity protection, and LED status indicators, this sensor consistently delivers reliable distance measurement and object detection. Add to cart now and upgrade your automation with this industry-leading ultrasonic sensor!

Feature-Rich Proximity Sensor for Industrial Precision

The PEPPERL FUCHS UB1000-18GM75-U-V15 sensor stands out with advanced features such as adjustable measuring range, short blind zone, LED indicators, and robust nickel-plated brass construction. It's primarily used for distance and level detection, position control, and fill level measurement in industrial automation. Applications span production lines, assembly lines, and material handling systems, providing accurate object detection even in challenging environments, maintaining consistent quality and efficiency in every operation.

Payment, Export Markets, and Swift Delivery

Rates for the PEPPERL FUCHS PROXIMITY SENSOR UB1000-18GM75-U-V15 are competitive in both domestic and international markets. Freight and handling costs vary based on location, ensuring a transparent process for all traders and wholesalers. The product is widely exported, with China being a major supplier, and caters to diverse global markets. Delivery time is prompt, tailored to customer requirements, and supported by robust logistics for efficient, timely fulfillment from order to installation.

FAQ's of PEPPERL FUCHS PROXIMITY SENSOR, UB1000-18GM75-U-V15:

Q: How does the PEPPERL FUCHS UB1000-18GM75-U-V15 achieve precise distance measurement?

A: This sensor uses ultrasonic technology, offering high accuracy (1% of final value) and fine resolution (0.18 mm) to provide reliable distance and object detection in industrial automation environments.

Q: What applications is the UB1000-18GM75-U-V15 sensor best suited for?

A: The sensor excels in industrial applications such as position and level detection, fill level measurement, and object detection, making it ideal for production and assembly lines.

Q: When can I expect delivery after placing an order for this sensor?

A: Delivery times depend on freight arrangements and your location, but the supplier ensures prompt dispatch and efficient handling for both domestic and export markets.

Q: Where should the sensor be mounted for optimal performance?

A: It is designed for threaded barrel mounting (M18 x 1), making it easy to install in a wide range of automated systems with restricted space.

Q: What is the process for adjusting the sensor's sensitivity?

A: You can conveniently adjust sensitivity and set detection ranges via the built-in teach-in button, allowing for tailored performance based on your specific application.

Q: How does the sensor maintain durability in industrial environments?

A: With an IP67 rating, nickel-plated brass housing, and high-quality plastic components, the sensor resists dust, moisture, and mechanical impact, ensuring long-term resilient operation.
