PEPPERL FUCHS DIFFUSE MODE SENSOR,OBT500-18GN60-E5-V1

PEPPERL FUCHS DIFFUSE MODE SENSOR,OBT500-18GN60-E5-V1 Specification

Mounting Type
Threaded barrel, M18

Power Consumption
20 mA (typical)

Signal Type
Digital

Features
LED status indicator, Short-circuit protection

Measurement Range
20 mm to 500 mm detection range

Operating Temperature
-25°C to +60°C

Response Time
< 1.0 ms

Sensitivity
Adjustable sensitivity via potentiometer

Wireless
No

Cable Length
2 m, PVC cable

IP Rating
IP67

Application
Diffuse Mode Sensor

Interface
OBT500-18GN60-E5-V1

Sensor Type
Optical Sensor

Product Type
PEPPERL FUCHS DIFFUSE MODE SENSOR

Material
Plastic housing

Input
Sensor input with diffuse mode detection capability

Output
PNP switching output, normally open (NO)

Function
Detection of objects by sensing reflected light

Usage
Automation and industrial sensing applications

Accuracy
High, accurate object detection within range

Resolution
Fine resolution for precise object positioning

Voltage
10 V to 30 V DC

Weight
Approx. 90 g

Vibration Resistance
10 g, 10 Hz ... 55 Hz

Background Suppression
Yes, with teach-in adjustment

Light Type
Red light, 660 nm wavelength

Hysteresis
< 15% of detected range

EMC Compliance
EN 60947-5-2

Housing Dimensions
M18 x 62 mm

Connection Type
4-pin, M12 connector

Max Switching Frequency
250 Hz

About PEPPERL FUCHS DIFFUSE MODE SENSOR,OBT500-18GN60-E5-V1

Discover instant savings and reduced downtime with the outstanding PEPPERL FUCHS OBT500-18GN60-E5-V1 Diffuse Mode Sensor. This noteworthy optical sensor features a robust plastic housing and advanced background suppression, ensuring extraordinary accuracy in object detection. With a highly visible red light at 660 nm, rapid response time (<1.0 ms), and a wide detection range of 20500 mm, this sensor is ideal for automation and industrial applications. Get enhanced reliability and peace of mind thanks to EMC compliance, IP67 rating, and practical teach-in adjustment. Available from trusted German suppliers, traders, and wholesalers.

Noteworthy Features and Versatile Applications

The PEPPERL FUCHS OBT500-18GN60-E5-V1 stands out with teach-in adjustment, adjustable sensitivity potentiometer, and robust short-circuit protection. Its IP67-rated housing endures harsh environments, making it suitable for applications on conveyor systems, manufacturing lines, and automated machinery. This sensor excels on metal, plastic, or composite surfaces, reliably detecting objects with fine resolution and high accuracy, even in challenging industrial settings.

FOB Port, Supply Capacity, and Certifications

Delivered promptly via an established FOB port, the PEPPERL FUCHS OBT500-18GN60-E5-V1 sensor ensures seamless global distribution. With a reputable supply ability to meet large-scale demands, customers will benefit from a transparent list price and low delivery charge. Certified to rigorous standards including EN 60947-5-2, this sensor guarantees the reliability that automation professionals expect from top German suppliers and wholesalers.

FAQs of PEPPERL FUCHS DIFFUSE MODE SENSOR,OBT500-18GN60-E5-V1:

Q: How does the PEPPERL FUCHS Diffuse Mode Sensor achieve accurate object detection?

A: The sensor uses a 660 nm red light beam and advanced background suppression, allowing for precise object detection through high-resolution optics and adjustable sensitivity.

Q: What applications are best suited for this sensor?

A: It is ideal for industrial automation, material handling, conveyor systems, and manufacturing lines where reliable, non-contact object detection is needed.

Q: Where can this sensor be installed for optimal performance?

A: Due to its IP67 housing and environmental resistance, it can be mounted on machinery, conveyor frames, or equipment where exposure to dust or moisture may occur.

Q: What is the process for teach-in adjustment on this sensor?

A: The teach-in adjustment allows users to easily calibrate detection sensitivity and background suppression, ensuring optimal performance for specific applications.

Q: What are the key benefits of the sensors EMC compliance?

A: EMC compliance ensures the sensor functions reliably by reducing electromagnetic interference, critical in environments with multiple electronic devices operating simultaneously.
