PEPPERL FUCHS PROXIMITY SENSOR, NMB5-12GM65-E0-V1

PEPPERL FUCHS PROXIMITY SENSOR, NMB5-12GM65-E0-V1 Specification

Measurement Range
0-5 mm (sensing distance)

Wireless
No

Operating Temperature
-25C ... +70C

Sensitivity
Factory set

Response Time
1 ms

Mounting Type
Flush mountable, cylindrical (M12)

Signal Type
Switching output

Cable Length
Connector (no fixed cable)

IP Rating
IP67

Interface
M12 plug connector (4-pin)

Features
Short-circuit protection, reverse polarity protection, LED status indicator

Power Consumption
10 mA (no load)

Sensor Type
Inductive

Application
Automation, industrial machinery, robotics

Product Type
Inductive Proximity Sensor

Material
Nickel-plated brass housing

Input
3-wire

Output
PNP, NO (Normally Open)

Function
Object detection (non-contact)

Usage
Position and limit sensing

Accuracy
High repeat accuracy

Resolution
Discrete (On/Off)

Voltage
10-30 V DC

Weight
Approx. 50 g

Connection Type
Plug connector

Housing Size
M12 x 1

Protection Class
II

Hysteresis
1-10% of sensing distance

LED Status Indication
Yes (yellow LED)

Active Face Material
PBT plastic

Environmental Temperature Range
-25 to +70C

Enclosure Material
Metal (nickel-plated brass)

Type Approval
CE, cULus

Switching Frequency
Up to 2000 Hz

Max Output Current
200 mA

Repeat Accuracy
0.1 mm

Vibration Resistance
55 Hz, amplitude 1 mm

Shock Resistance
30 g, 11 ms

Target Material
Ferrous metals (e.g. steel)

Operating Principle
Inductive, shielded

PEPPERL FUCHS PROXIMITY SENSOR, NMB5-12GM65-E0-V1 About

Act now on the limited time offer for the PEPPERL FUCHS PROXIMITY SENSOR, NMB5-12GM65-E0-V1-a hot-selling solution equipped with competitive pricing and extraordinary reliability. This sensor stands dominant in its class, ensuring remarkable performance with ferrous targets like steel, an M12 x 1 nickel-plated brass housing, and an inductive, shielded operation. Designed for challenging environments with IP67 protection, it features high accuracy (0.1 mm repeatability) and a rapid 2000 Hz switching frequency. Suitable for robotics, automation, and industrial machinery, this sensor guarantees durability, safety, and efficiency-all in compact, robust construction.

Competitive Advantages & Versatile Applications

The PEPPERL FUCHS NMB5-12GM65-E0-V1 sensor boasts outstanding accuracy with up to 2000 Hz switching frequency and high repeatability, making it a dominant choice for demanding automation tasks. It is well-suited for position and limit sensing in industrial machinery, assembly lines, and robotic applications where precision is critical. Built with a rugged nickel-plated brass enclosure and compliant with CE and cULus standards, its shielded inductive design ensures reliable performance-even in harsh environments.

Swift Handover, FOB Port & Sample Policy Offer

We guarantee prompt handover of the PEPPERL FUCHS NMB5-12GM65-E0-V1 sensor, shipping swiftly from major China FOB ports to your location. For your assurance, we offer a competitive outlay for initial samples, enabling you to evaluate product compatibility with minimal risk. Efficient processing ensures your orders are delivered reliably and on time, allowing seamless integration into your automation projects without delay.

FAQ's of PEPPERL FUCHS PROXIMITY SENSOR, NMB5-12GM65-E0-V1:

Q: How does the PEPPERL FUCHS NMB5-12GM65-E0-V1 sensor operate?

A: It works using inductive, shielded technology to detect the presence of ferrous metals without physical contact, providing reliable switching at up to 2000 Hz.

Q: What application areas are best suited for this sensor?

A: It excels in industrial automation, robotics, position sensing, and limit detection in machinery, particularly where high accuracy, durability, and fast response are necessary.

Q: When can I expect delivery after placing an order?

A: Delivery is typically prompt, with fast handover from major FOB ports in China. Exact lead times may vary based on your location and order size.

Q: Where should the sensor be installed for best performance?

A: Install the sensor in flush-mounted, cylindrical (M12) arrangements in areas requiring object detection of ferrous materials. Ensure protection from excessive vibration and shock as specified in the datasheet.

Q: What is the sample policy for initial procurement?

A: We offer an initial sample at a reasonable outlay, giving you the opportunity to test compatibility before committing to larger quantities.

Q: How does the sensor benefit automated systems?

A: It provides high repeat accuracy, rapid response, and a robust IP67 certified enclosure, enhancing system reliability and minimising downtime in automated environments.
