AUTONICS PROXIMITY SENSOR, PSN40-20DN

AUTONICS PROXIMITY SENSOR, PSN40-20DN Specification

Response Time
10ms

IP Rating
IP67

Sensitivity
Adjustable

Signal Type
Digital (ON/OFF)

Features
LED Status Indicator, Reverse Polarity Protection

Operating Temperature
-25C to +70C

Mounting Type
Flush/Non-Flush

Power Consumption
Max. 20mA

Interface
3-Wire DC

Sensor Type
Inductive Proximity

Measurement Range
0-20mm

Cable Length
2 meters

Wireless
No

Application
Position and Presence Sensing

Product Type
Proximity Sensor

Material
ABS (Body), Nickel-plated Brass (Sensing Surface)

Input
DC

Output
NPN Normally Open

Function
Non-contact Object Detection

Usage
Industrial Automation, Object Sensing

Accuracy
High

Resolution
Standard

Voltage
12-24VDC Volt (v)

Weight
Approx. 430g

Control Output
NPN Open Collector

Cable Specifications
6mm, 3-wire, Oil-resistant PVC

Sensing Distance
20mm

Storage Temperature
-30C to +80C

Storage Humidity
35-95% RH

Insulation Resistance
Min. 50M (at 500VDC megger)

Quiescent Current
Max. 10mA

Operating Humidity
35-95% RH

Vibration Resistance
10-55Hz, 1.5mm double amplitude

Standard Sensing Target
50x50x1mm iron

Housing Dimensions
40x40x68mm (WxHxD)

Shock Resistance
500m/s2 (approx. 50G)

Detection Object
Ferrous metals (best), can detect non-ferrous metals at reduced distance

Response Frequency
20Hz

Protection Circuit
Surge, Short-circuit, and Overload Protection

Model
PSN40-20DN

Connector Type
Pre-wired

Dielectric Strength
1500VAC, 50/60Hz for 1 minute

AUTONICS PROXIMITY SENSOR, PSN40-20DN About

Find first-class performance with the AUTONICS PSN40-20DN Proximity Sensor, designed for opulent industrial automation solutions. This invincible, top-tier sensor offers a rare combination of high sensitivity and robust durability, excelling especially in detecting ferrous metals at a superior 20mm range. Engineered with advanced protection circuits and an oil-resistant, pre-wired cable, it stands resilient in demanding environments. Its wide temperature and humidity tolerance, along with surge and overload protection, makes it an indispensable asset for precise, reliable positioning and presence sensing in commercial and manufacturing applications.

Unmatched Versatility and Competitive Edge

The AUTONICS PROXIMITY SENSOR, PSN40-20DN is ideal for a spectrum of applications, including conveyor systems, automated assembly lines, and robotics. Its top-resolution performance offers a rare advantage in environments demanding invincible reliability. Commercial users benefit from easy integration, durable construction, and energy-efficient operation, ensuring continuous productivity. Whether for new installations or system upgrades, this sensor delivers opulent accuracy and dependability, securing a competitive edge in modern industry.

Packaging Details and Global Availability

Professionally packaged for damage-free drop-off, the PSN40-20DN is stock ready for rapid dispatch. Each unit undergoes strict valuation to ensure top quality before shipping. With strong supply chains, this sensor is available across main domestic markets in China and throughout major export regions. Prompt delivery and robust packaging guarantee that clients receive their sensors intact, allowing for immediate installation and operation, wherever the commercial need arises.

FAQs of AUTONICS PROXIMITY SENSOR, PSN40-20DN:

Q: How does the AUTONICS PSN40-20DN proximity sensor enhance industrial automation systems?

A: The PSN40-20DN provides precise, non-contact object detection with high sensitivity, ensuring accurate positioning and presence sensing, thus minimizing errors in automated processes.

Q: What types of materials can this sensor effectively detect?

A: This sensor is optimized for detecting ferrous metals up to 20mm, while also sensing non-ferrous metals at reduced distances, offering versatile usage across various applications.

Q: Where can the AUTONICS PSN40-20DN be used effectively?

A: It is well-suited for installation in manufacturing plants, conveyor lines, robotic systems, and any commercial application requiring reliable position or presence detection.

Q: What protection features does the sensor offer?

A: The PSN40-20DN is equipped with surge, short-circuit, and overload protection, as well as an oil-resistant cable and reverse polarity protection, ensuring safety and longevity.

Q: How is the sensor packaged and delivered to ensure quality?

A: Each sensor is professionally packaged for secure drop-off, stock ready for rapid shipment, and undergoes quality valuation before dispatch to both domestic and international markets.

Q: What is the benefit of the adjustable sensitivity feature?

A: Adjustable sensitivity allows users to optimize detection performance according to the specific needs of their application or variation in target materials.
