PEPPERL FUCHS PROXIMITY SENSOR, ML100-8-H-100-RT/103/115

PEPPERL FUCHS PROXIMITY SENSOR, ML100-8-H-100-RT/103/115 Specification

Application
Packaging, material handling, conveyor systems, automation machinery

Response Time
<1 ms

IP Rating
IP67

Measurement Range
10 mm to 100 mm

Cable Length
2 m, PVC cable

Signal Type
Digital (discrete output)

Power Consumption
Approx. 20 mA (no load)

Operating Temperature
-25C to +55C

Interface
Cable connection, 3-wire

Wireless
No

Sensitivity
Adjustable sensitivity via teach-in button

Sensor Type
Photoelectric sensor (diffuse mode)

Features
Red light emission, background suppression, compact housing, status LED

Mounting Type
Surface/through-hole mounting via slotted holes

Product Type
Photoelectric Proximity Sensor

Material
Plastic (housing), PMMA (optics)

Input
10-30 V DC

Output
PNP normally open (NO), 100 mA max load current

Function
Diffuse mode sensor with background suppression

Usage
Non-contact object detection

Accuracy
High accuracy for industrial automation

Resolution
Fine spot, precise switching

Voltage
10-30 V DC

Weight
Approx. 50 g

Model Number
ML100-8-H-100-RT/103/115

Housing Dimensions
21.8 mm x 14.6 mm x 8 mm (W x H x D)

Ambient Light Immunity
Up to 10,000 Lux

Switching Frequency
Up to 1 kHz

Max Load Current
100 mA

Status Indication
LED (output status/search status)

Control Elements
Teach-in button for adjustment

Series
ML100 Series

Protection Circuitry
Reverse polarity and short-circuit protection

Connection Type
Pre-wired cable, 3 x 0.34 mm2

Optics Material
PMMA (acrylic)

Light Source
Red LED (visible)

Enclosure Material
ABS plastic

About PEPPERL FUCHS PROXIMITY SENSOR, ML100-8-H-100-RT/103/115

Explore the peerless capabilities of the PEPPERL FUCHS PROXIMITY SENSOR, ML100-8-H-100-RT/103/115. With its immaculate Red LED for precise detection, this ephemeral photoelectric sensor offers instant checkout of objects in dynamic environments. Engineered for the finest accuracy, it features a robust background suppression and a fine resolution spot. The sensor's ABS housing and PMMA optics ensure durability, while the teach-in button allows effortless adjustment. Benefit from flawless non-contact object detection, enhanced by IP67 protection and reverse polarity circuitry, perfect for demanding industrial applications.

Advantageous Sensing with Superior Features

The ML100-8-H-100-RT/103/115 model delivers high accuracy and reliability for industrial automation. Extra features include a visible red light source, adjustable sensitivity via teach-in button, and immune operation in ambient light up to 10,000 Lux. Its compact size, LED indicators, and weather-resistant IP67 enclosure enhance usability. Gain fine resolution for precise switching, further supported by fast response time under 1 ms and robust ABS and PMMA construction for long-lasting performance.

Flexible Payment, Smooth Packing & Dispatch

Flexible outlay options are provided to streamline procurement of the ML100-8-H-100-RT/103/115. Packing & dispatch are handled with utmost care for international goods transport, tailored for global export markets. Each sensor is securely packed to prevent damage during transit, ensuring reliability upon arrival. Our channel supports clients in China and worldwide, providing swift completion of payment and logistics processes for a seamless purchase experience.

FAQ's of PEPPERL FUCHS PROXIMITY SENSOR, ML100-8-H-100-RT/103/115:

Q: How does the teach-in button function on the ML100-8-H-100-RT/103/115 sensor?

A: The teach-in button enables users to easily adjust the sensor's sensitivity and detection range for different applications, facilitating convenient setup and calibration in automation systems.

Q: What distinguishes the PEPPERL FUCHS ML100 Series proximity sensor from other models?

A: It offers peerless accuracy with background suppression, a fine resolution detection spot, high immunity to ambient light, and robust protection features such as IP67 rating and reverse polarity circuitry.

Q: When should the ML100-8-H-100-RT/103/115 be used in industrial applications?

A: This sensor is ideal for non-contact object detection in environments like packaging, conveyor systems, and material handling, especially where quick response and precise detection are required.

Q: Where can the ML100-8-H-100-RT/103/115 be installed?

A: It supports surface or through-hole mounting using slotted holes and can be placed in various automated settings due to its compact form and 2-meter pre-wired cable for flexible installation.

Q: What is the process for payment and delivery of this proximity sensor?

A: Payment can be made through flexible terms tailored for global buyers. Once completed, the packing and dispatch process ensures careful handling and prompt goods transport to export markets.

Q: How does the background suppression benefit the sensor's operation?

A: Background suppression ensures the sensor only detects desired objects, reducing false triggers from objects or surfaces in the background. This makes detection more reliable and precise in complex settings.
