PANASONIC PROXIMITY SENSOR, EX-11A

PANASONIC PROXIMITY SENSOR, EX-11A Specification

Response Time
0.5 ms max.

Signal Type
Digital

Operating Temperature
-25C to +55C (no freezing)

Sensor Type
Photoelectric Sensor

Wireless
No

Features
Ultra Compact Size, High-speed Response, LED Indicator, Water and Oil Resistant

Application
Position Sensing, Object Detection, Conveyor Lines

Cable Length
2 m

Power Consumption
10 mA or less (at 24 V DC)

Mounting Type
Through-hole Mounting / Screw Mount

Sensitivity
Adjustable

Measurement Range
0.5 mm to 2 m (depending on target)

IP Rating
IP67

Interface
3-wire (Brown, Blue, Black)

Product Type
Proximity Sensor

Material
Plastic Housing

Input
DC 12-24V

Output
NPN Open Collector

Function
Object Detection

Usage
Industrial Automation

Accuracy
High Repeat Accuracy

Resolution
Fine Detection Capability

Voltage
12-24 V DC

Weight
Approx. 10g

Sensing Method
Through-beam (EX-11A)

Control Output
NPN, 100 mA max.

Light Source
Red LED

Case Size
W10H19D3.5 mm

Storage Temperature
-30C to +70C

Indicator
Operation Indicator (Red LED)

Protection Circuit
Reverse Polarity, Surge Absorption

Ambient Humidity
35 to 85% RH

PANASONIC PROXIMITY SENSOR, EX-11A About

The PANASONIC PROXIMITY SENSOR, EX-11A stands in the spotlight, earning favorable reviews for its world-class reliability and monumental performance. Designed for industrial automation, this incomparable sensor features a robust plastic housing, ultra-compact 10x19x3.5 mm size, and high repeat accuracy. Its red LED through-beam sensing method and adjustable sensitivity ensure fine detection, even in challenging environments. With a rapid 0.5 ms response and IP67-rated protection, the EX-11A is ready for demanding object detection, position sensing, and conveyor applications. Try now to experience unmatched functionality and durability.

Advantages and Applications: The EX-11A Edge

PANASONIC's EX-11A Proximity Sensor delivers a clear advantage through high-resolution detection and swift response, making it ideal for applications requiring precision. Its primary competitive strengths are durability, ultra-compact design, and IP67 water/oil resistance. Beyond conveyor lines and position sensing, the EX-11A can be used in robotics, packaging, and smart factory setups. Its dependable performance and versatility set it apart among other sensors in the market.

Premium Packaging, Shipping & Main Domestic Market

Each PANASONIC PROXIMITY SENSOR, EX-11A is shipped in premium, secure packaging to ensure safety during delivery. We offer reliable transport services and flexible payment terms for a seamless purchasing experience. The main domestic market covers key industrial hubs across China, with quick dispatch times and dedicated support. Choose this sensor for both quality assurance and top-tier customer satisfaction.

FAQ's of PANASONIC PROXIMITY SENSOR, EX-11A:

Q: How does the EX-11A's through-beam sensing method work?

A: The EX-11A uses a red LED through-beam sensor, emitting light from the transmitter to receiver. When an object interrupts the beam, the sensor detects its presence or position with high accuracy.

Q: What are the primary benefits of using the PANASONIC EX-11A Proximity Sensor?

A: The main benefits include high repeat accuracy, fine detection resolution, fast 0.5 ms response time, IP67 protection, robust build, and ultra-compact design. These qualities make it suitable for demanding industrial environments.

Q: Where can the EX-11A be used aside from conveyor lines?

A: Besides conveyor lines, the EX-11A is ideal for position sensing, object detection in automation, robotics, packaging machinery, and any operations requiring reliable, high-speed sensor input.

Q: When is it recommended to adjust the sensor's sensitivity?

A: Adjust the sensor's sensitivity when working with different object sizes or materials, or when environmental factors such as dust or background reflections could influence detection accuracy.

Q: What is the process for installing the EX-11A sensor?

A: Installation is straightforward with options for through-hole or screw mounting. The sensor includes a 2-meter 3-wire interface, making electrical connection simple and secure with Brown, Blue, and Black wires.
