PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR, NEN20-18GM50-E2-V1

PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR, NEN20-18GM50-E2-V1 Specification

Sensor Type
Inductive

Wireless
No

Cable Length
Not applicable (M12 connector)

IP Rating
IP67

Features
LED indicator, reverse polarity protection, short-circuit protection

Mounting Type
Flush (shielded)

Measurement Range
Sn = 20 mm

Power Consumption
10 mA (no load)

Application
Industrial automation, assembly lines, robotics

Sensitivity
Factory set, optimized for 20 mm range

Response Time
1 ms

Interface
M12 plug connector, 4-pin

Operating Temperature
-25C to +70C

Signal Type
Discrete (Switching, ON/OFF)

Product Type
Inductive Proximity Sensor

Material
Nickel plated brass

Input
DC 3-wire

Output
PNP, normally open (NO)

Function
Detection of metal objects without contact

Usage
Position sensing, end limit detection, automation systems

Accuracy
High accuracy (typical for inductive sensors)

Resolution
Determined by sensing face size, not specified

Voltage
10...30 V DC

Weight
Approx. 50 g

Protection Circuits
Short-circuit/overload protection, reverse polarity protection, surge protection

Vibration Resistance
10...55 Hz, amplitude 1 mm, IEC 60068-2-6

Shock Resistance
30 g, 11 ms, IEC 60068-2-27

Housing Size
18 mm diameter (M18)

Connection Type
M12 x 1 connector (V1)

Enclosure
Cylindrical, nickel plated brass

Sensing Surface Material
Plastic (PBT)

EMC Compliance
EN 60947-5-2

Control Output Current
200 mA

Switching Frequency
0...250 Hz

PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR, NEN20-18GM50-E2-V1 About

Experience superior accuracy and reliability with the PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR, NEN20-18GM50-E2-V1, a top-rated, best-selling sensor designed for grandiose automation needs. Featuring a premier M18 housing, this new sensor delivers high-precision position sensing with a sensing range up to 20 mm and a robust nickel-plated brass enclosure. Offering superior short-circuit, overload, and reverse polarity protection, this sensor excels in challenging environments. Ideal for industrial automation, assembly lines, and robotics, its high EMC compliance and IP67 rating ensure longevity and consistent performance.

Distinguished Features & Versatile Applications

The PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR, NEN20-18GM50-E2-V1 boasts extra features such as a LED indicator, factory-set sensitivity, and multiple protection circuits for fail-safe operations. Optimized for use in position sensing, end limit detection, and high-speed automation systems, this premier sensor seamlessly integrates into assembly lines and robotic applications. Its flush-mount design, superior vibration and shock resistance, and high-accuracy build make it a reliable component for continuous industrial use.

Ordering, Payment, and Delivery Terms

Enjoy secure shipping and prompt dispatching with every order of the PEPPERL FUCHS NEN20-18GM50-E2-V1. We provide transparent quotations, flexible payment terms, and consistent supply ability to fulfill both small and large orders. Shipments are processed through reliable FOB ports, ensuring timely and efficient worldwide delivery. Our support team ensures clients receive first-class communications from initial inquiry to final shipment, guaranteeing your experience is as premier as the product itself.

FAQ's of PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR, NEN20-18GM50-E2-V1:

Q: How does the PEPPERL FUCHS NEN20-18GM50-E2-V1 sensor detect objects?

A: This inductive proximity sensor detects metal objects without physical contact through electromagnetic fields, ensuring precise and non-intrusive position or end limit sensing in industrial environments.

Q: What are the primary benefits of using this sensor?

A: Key benefits include high switching frequency, robust short-circuit and overload protection, IP67-rated enclosure for harsh environments, and high accuracy, making it ideal for demanding automation and assembly line applications.

Q: Where can this sensor be deployed for optimal performance?

A: It is best suited for industrial automation systems, assembly lines, robotics, and applications requiring reliable, contactless detection of metal objects with consistent performance.

Q: What type of output signal does the sensor provide?

A: The sensor offers a discrete (ON/OFF) signal with a PNP, normally open (NO) configuration, suitable for integration into various industrial control systems.

Q: How is the sensor installed and connected?

A: Installation is performed using the flush (shielded) mounting and M12 x 1 connector. Simply plug into a compatible 4-pin M12 interface for secure operation.

Q: What protection features does the sensor offer during operation?

A: It provides superior protection through built-in short-circuit, overload, reverse polarity, and surge protection circuits for long-term durability and reliability.
