PANASONIC PHOTOELECTRIC SENSOR,EX-L221-P

PANASONIC PHOTOELECTRIC SENSOR,EX-L221-P Specification

Sensitivity
Adjustable by teaching

Signal Type
Digital

Mounting Type
Direct mount using M2 screws

Application
Factory Automation, Robotics, Conveyor Systems, Packaging Machinery

Measurement Range
Detecting distance: 100 mm (white paper) - 20 mm (black paper)

Interface
3-wire NPN/PNP

Cable Length
2 m

Sensor Type
Ultra-compact Photoelectric Sensor

Response Time
0.5 ms or less

Features
Ultra thin compact design, bright spot type, stability indicator, dirt immunity

Power Consumption
10 mA or less

Operating Temperature
-10C to +55C (No freezing)

IP Rating
IP67

Wireless
No

Product Type
Photoelectric Sensor

Material
Plastic Body

Input
12 to 24 V DC

Output
PNP Open Collector

Function
Diffuse Reflective

Usage
Object Detection, Automation Systems

Accuracy
High precision detection

Resolution
0.3 mm

Voltage
10 to 30 V DC

Weight
Approx. 10 g (with cable)

Case Dimensions
31 11 5.5 mm

Ambient Humidity
35% to 85% RH

Emission Direction
Side view

Light Source
Red LED (wavelength: 630 nm)

Connector Type
Pigtail cable

Reverse Polarity Protection
Available

Tolerance
10% for supply voltage

Overcurrent Protection
Available

Control Output Capacity
30 V DC, 50 mA maximum (resistive load)

About PANASONIC PHOTOELECTRIC SENSOR,EX-L221-P

Unlock remarkable precision and dependability with the PANASONIC PHOTOELECTRIC SENSOR, EX-L221-P. This top-notch sensor boasts a red LED light source (630 nm), delivers a detecting range of 100 mm, and features both reverse polarity and overcurrent protection. Its ultra-compact plastic case maximizes scarce mounting space, while the triumphant side-view emission ensures optimal alignment in automation tasks. With adjustable sensitivity, 0.3 mm resolution, and rapid 0.5 ms response, this sensor excels in object detection for robotics, packaging, and conveyor systems, making it a remarkable asset for modern factory automation.

Versatile Sensor for Diverse Plant Applications

The PANASONIC PHOTOELECTRIC SENSOR, EX-L221-P is designed for high-precision object detection in modern automation systems. Ideal for use in factories, this sensor's ultra-thin design enables seamless integration across robotics, conveyor lines, and packaging machinery. Its side-view detection and advanced dirt immunity ensure reliable performance, even in demanding industrial environments. This scarce and compact device is perfect for installation in spaces with strict spatial limitations, delivering top-tier accuracy and stability across numerous plant applications.

Export Markets, Sample Policy, and Payment Flexibility

This product is available for trading, wholesaling, and supply within China and is well suited for international export markets. Experience competitive sale prices and tailored rates based on bulk order quotations. Sample policies are buyer-friendly, permitting evaluation before major procurement. Payment terms are flexible, designed to suit diverse business needs and support smooth transactions, ensuring a seamless process from quotation request to product delivery.

FAQ's of PANASONIC PHOTOELECTRIC SENSOR,EX-L221-P:

Q: How does the EX-L221-P ensure high detection accuracy in automation systems?

A: The sensor offers a 0.3 mm resolution and features adjustable sensitivity by teaching, enabling precise detection of objects with varying sizes and materials. Its advanced dirt immunity and stability indicator also boost reliability in challenging environments.

Q: What benefits does the ultra-compact design provide?

A: The ultra-thin, plastic-bodied EX-L221-P allows for installation in scarce or tight spaces where larger sensors might not fit. This maximizes design flexibility and is particularly valuable in complex factory layouts or miniaturized robotics applications.

Q: Where is the PANASONIC PHOTOELECTRIC SENSOR primarily used?

A: It is prominently used in factory automation, robotics, conveyor systems, and packaging machinery, where high-speed, high-precision object detection is critical to system performance.

Q: What is the process for installing this sensor in automation equipment?

A: Installation is straightforward using M2 screws for direct mounting, and the 2-meter pigtail cable simplifies wiring. Its side-view emission direction is optimal for seamless alignment within equipment.

Q: When should the EX-L221-P be selected over other sensor types?

A: Choose the EX-L221-P when you require rapid response times, tight space integration, and the ability to detect a wide range of object colors and textures at short distances in highly automated environments.
