PANASONIC PHOTOELECTRIC SENSOR, CX-421

PANASONIC PHOTOELECTRIC SENSOR, CX-421 Specification

Power Consumption
Under 900 mW (40 mA at 24V DC)

IP Rating
IP67

Operating Temperature
-25C to +55C (No condensation or icing)

Mounting Type
Screw Mount or Side-mount

Signal Type
Digital (On/Off)

Wireless
No

Interface
Wire connection

Application
Packaging, Conveyors, Production Lines

Sensitivity
Adjustable (via potentiometer)

Sensor Type
Through-beam (also available in Retro-reflective and Diffuse types)

Response Time
0.5 ms or less

Features
Compact size, LED Indicator, Short-circuit protection

Cable Length
2m standard

Measurement Range
10 to 1000 mm (model-dependent)

Product Type
Photoelectric Sensor

Material
ABS Resin (housing)

Input
DC 12-24V

Output
NPN/PNP open-collector, 100mA max.

Function
Detects the presence or absence of objects

Usage
Industrial Automation

Accuracy
High detection accuracy

Resolution
Detects objects as small as 0.2 mm

Voltage
12-24V DC 10%

Weight
Approx. 70g (with 2m cable)

Connection Method
Pre-wired (cable type)

Ambient Humidity
35% to 85% RH (no condensation)

Vibration Resistance
10 to 55 Hz, 1.5 mm amplitude, 2 hours each in X, Y, Z axes

Protective Circuit
Reverse polarity, surge absorption, output short-circuit protection

EMC Compliance
Conforms to EN, IEC standards

Enclosure Material
Polycarbonate

Control Output
NPN open-collector output (max. 30V DC, 100mA)

Shock Resistance
10G, 3 times each in X, Y, Z axes

Indicator
Operation indicator (Orange LED)

Hysteresis
Within 15% of sensing distance

Light Source
Red LED (modulated)

About PANASONIC PHOTOELECTRIC SENSOR, CX-421

Experience the breathtaking innovation of the PANASONIC PHOTOELECTRIC SENSOR, CX-421. Engineered for monumental precision, it boasts unprecedented detection accuracy-capable of identifying objects as tiny as 0.2mm, with an adjustable sensing range. Enjoy instant checkout and redeem cutting-edge performance for packaging, conveyors, and production lines. Get it now, and benefit from robust polycarbonate housing, IP67 protection, and advanced circuit safeguards. The ergonomic, pre-wired format and vivid LED indicators ensure seamless integration into your industrial automation projects. Elevate your workflow with reliability and speed.

Unmatched Application Versatility and Usage

PANASONIC PHOTOELECTRIC SENSOR, CX-421 excels on varied industrial surfaces, supporting both screw and side-mount installations. Optimized for through-beam detection (with retro-reflective and diffuse options available), it effortlessly functions across media including packaging materials and conveyors. Its digital signal output and high-resolution capabilities render it ideal for high-precision object presence detection, empowering robust automation solutions in fast-moving production environments.

Effortless Global Delivery and Market Reach

With a primary export focus on China and strong domestic market presence, the PANASONIC CX-421 sensor is shipped with rapid order processing to ensure fast delivery times. Shipped goods are securely handled to maintain product integrity. Our streamlined logistics guarantee your order is dispatched promptly, arriving ready for seamless integration into your operations, whether procured individually, as part of a trade arrangement, or through wholesale distribution.

FAQ's of PANASONIC PHOTOELECTRIC SENSOR, CX-421:

Q: How can the PANASONIC CX-421 sensor benefit my industrial automation needs?

A: The CX-421 boasts high detection accuracy and a compact build, making it ideal for precise object detection in packaging, conveyors, and production lines. Its robust design ensures reliability even under severe industrial conditions.

Q: What is the process for installing the CX-421 sensor?

A: Installation is straightforward thanks to screw or side-mount options. The sensor comes pre-wired with a standard 2m cable, allowing for quick and secure setup in various industrial applications.

Q: Where can the CX-421 sensor be used?

A: The sensor is engineered for diverse environments such as packaging lines, conveyor systems, and automated production facilities. It performs exceptionally well on different application surfaces and industrial media types.

Q: When will my order be shipped after purchase?

A: Your PANASONIC CX-421 sensor order is processed swiftly, with shipping arranged promptly upon confirmation. Typical delivery times vary by region but are managed for quick turnaround and secure delivery.

Q: What features enhance the CX-421's durability and safety?

A: The sensor includes reverse polarity, surge absorption, short-circuit protection, and an IP67 rating. Its housing material and shock/vibration resistance guarantee long-lasting operation even in challenging environments.

Q: How does the CX-421 sensor handle different operational conditions?

A: Designed to operate within a wide temperature and humidity range, the CX-421 maintains high performance despite fluctuations in environmental conditions, ensuring consistent and reliable object detection.
