PANASONIC PHOTOELECTRIC SENSOR, EX-11A , EX-14A

PANASONIC PHOTOELECTRIC SENSOR, EX-11A , EX-14A Specification

Wireless
No

IP Rating
IP67

Features
Ultra-small size, High durability, Easy alignment

Measurement Range
EX-11A: 300 mm (through-beam), EX-14A: 10-50 mm (reflective)

Sensitivity
Adjustable (via potentiometer on EX-14A)

Signal Type
Digital (ON/OFF)

Operating Temperature
-25C to +55C Celsius (oC)

Interface
2-wire / 3-wire DC

Mounting Type
Side Mounting with M2 Screws

Application
Industrial Automation, Conveyors, Robotics

Cable Length
2 Meter (m)

Sensor Type
Through-beam (EX-11A), Reflective (EX-14A)

Product Type
Photoelectric Sensor

Material
Plastic (Housing)

Input
DC 12-24V

Output
NPN Open Collector (EX-11A), PNP Optional (EX-14A)

Function
Object Detection

Usage
Position Sensing, Automation Systems

Accuracy
±0.1 %

Resolution
0.01 mm

Voltage
12-24 V DC Volt (v)

Weight
10 Grams (g)

Insulation Resistance
Over 20 M (at 500 V DC)

Short Circuit Protection
Yes

Reverse Polarity Protection
Yes

Vibration Resistance
10 to 55 Hz, amplitude 1.5 mm, in X, Y, Z directions, for 2 h each

Case Dimensions
13 x 21 x 8 mm (approx.)

Repeatability
0.03 mm or less

Switching Frequency
1,000 Hz

Maximum Sensing Distance
300 mm (EX-11A), 50 mm (EX-14A)

Control Output
100 mA max at 30 V DC

Connector Type
M8 (optional for some models)

Compliance
CE, RoHS

Shock Resistance
500 m/s, 3 times in X, Y, Z directions

Light Source
Red LED (Visible)

PANASONIC PHOTOELECTRIC SENSOR, EX-11A , EX-14A Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About PANASONIC PHOTOELECTRIC SENSOR, EX-11A , EX-14A

Discover the featured Panasonic Photoelectric Sensors, EX-11A and EX-14Acost-effective solutions for precise object detection and position sensing. Renowned for their incomparable accuracy (0.1 mm) and gilt-edged durability, these sought-after sensors deliver reliable performance with visible red LED light. The EX-11A offers a maximum sensing distance of 300 mm, while the EX-14A extends up to 50 mm. With robust IP67 protection, high-frequency switching (1,000 Hz), compact dimensions, and resilience against shock and vibration, they are ideal for industrial automation, conveyors, and robotics applications. Certified with CE and RoHS compliance, these sensors redefine high-grade automation technology.

Versatile Application Areas and Specialized Uses

PANASONIC PHOTOELECTRIC SENSOR EX-11A and EX-14A excel across diverse industrial automation environments. Specifically engineered for position sensing and object detection, their applications expand to conveyors, robotics, and critical automation systems. Their precision and reliability make them a top choice for quality control, packaging lines, and electronic component assembly. Additionally, their high resolution and repeatability suit demanding sectors where accuracy and swift response are paramount, delivering seamless integration into numerous automation solutions.

Secure Packaging and Efficient Supply Management

Each Panasonic Photoelectric Sensor is meticulously packaged to ensure protection during shipment and dispatching. With a reliable supply ability, suppliers in India guarantee prompt processing and careful handling of every order. Products are handed over at designated FOB ports for swift export or local delivery. The process ensures timely availability and secure transit, preserving the sensors quality from dispatch to receipt. Customers can rely on a seamless procurement experience from initial order to final handover.

FAQs of PANASONIC PHOTOELECTRIC SENSOR, EX-11A , EX-14A:

Q: How do the EX-11A and EX-14A sensors ensure high accuracy in industrial automation?

A: Both models feature advanced photoelectric detection with exceptional repeatability (0.03 mm or less) and high accuracy (typically 0.1 mm), allowing precise object and position sensing even in demanding automation environments.

Q: What specific applications can Panasonic Photoelectric Sensors be used for?

A: These sensors are ideally suited for object detection, position sensing, conveyor automation, robotics, quality control lines, and electronic assembly processes due to their compact design, fast response, and adjustable sensitivity.

Q: Where can these sensors be installed for optimal performance?

A: The EX-11A and EX-14A are designed for side mounting with M2 screws, enabling easy integration in tight spaces on industrial machinery, conveyor frames, and robotic arms, enhancing versatility across various installations.

Q: When is shipment and dispatching typically completed after placing an order?

A: Shipment and dispatch are managed efficiently to ensure a prompt turnaround. Products are carefully packed and handed over at the designated FOB porttimelines can vary based on order quantity and location, but prompt handling is a priority.

Q: What protections and compliances do these sensors offer?

A: Both models are built with reverse polarity and short circuit protection, comply with CE and RoHS standards, and provide robust IP67-rated durability for use in challenging environments, ensuring safe and reliable operation.
