PANASONIC,PHOTOELECTRIC SENSOR, CX-441-P

PANASONIC,PHOTOELECTRIC SENSOR, CX-441-P Specification

Cable Length
2 m (Standard)

Power Consumption
30 mA or less

Response Time
0.5 ms or less

IP Rating
IP67

Sensitivity
Adjustable

Features
Short-circuit protection, Reverse polarity protection, LED indicator

Mounting Type
DIN Rail / Panel Mount

Application
Object Presence Detection, Position Sensing

Measurement Range
Up to 5 m (Through-beam type)

Wireless
No

Interface
3-wire cable

Sensor Type
Through-beam (Polarized) Photoelectric

Operating Temperature
-25C to +55C (No condensation or icing)

Signal Type
Digital Output

Product Type
Photoelectric Sensor

Material
Polycarbonate Housing

Input
DC 12-24V

Output
NPN Open Collector

Function
Object Detection

Usage
Industrial Automation, Conveyor Systems

Accuracy
High Repeatability, Max. 0.05 mm

Resolution
Min. 0.1 mm

Voltage
12-24 V DC

Weight
Approx. 50g

Sensitivity Adjustment
1-turn adjuster

Light Source
Red LED (660 nm)

Shock Resistance
500 m/s2, 3 times in each of X, Y, Z directions

Ambient Humidity
35 to 85% RH (Non-condensing)

Connection Type
Pre-wired (2 m cable) / Connector type optional

Storage Temperature
-30C to +70C

Vibration Resistance
10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of X, Y, Z directions

Protection Circuit
Reverse polarity protection, Output short-circuit protection

Material (Case/Enclosure)
Polycarbonate

Control Output
NPN Output: 100 mA max. at 30 V DC (Residual voltage: 1 V max.)

Operating Indicator
Red LED (ON when output is ON)

PANASONIC,PHOTOELECTRIC SENSOR, CX-441-P About

The resplendent PANASONIC PHOTOELECTRIC SENSOR, CX-441-P, stands out in the competitive world of industrial automation, offering a fresh approach to accurate object detection. Powered by an in-demand Red LED (660 nm) light source and encased in a robust, polycarbonate housing, this sensor guarantees steadfast performance and enviable reliability in demanding environments. Its towering list of features - from high repeatability, adjustable sensitivity, and self-protective circuits, to simple personalisation using a 1-turn adjuster - ensure optimal precision and longevity. With an IP67 rating, it's engineered to thrive in rigorous conditions, making it a premier choice for those seeking lasting quality.

Specific and Versatile Usage Applications

The PANASONIC PHOTOELECTRIC SENSOR, CX-441-P is designed for specific use in industrial automation, particularly excelling in conveyor systems and precision-driven environments where object presence detection and position sensing are vital. Suitable for both general use and specialized tasks, it is used as a reliable component to ensure efficiency and accuracy. Its versatile mounting options make it ideal for multiple installation scenarios, further enhancing its applicability across diverse operational settings.

Supply Estimate and Dispatch Process

We strive to maintain enviable supply ability for the PANASONIC CX-441-P sensor to meet your industrial demands. Orders are typically dispatched from a major FOB port in China, ensuring streamlined logistic expenditures. The estimated delivery time varies depending on location, with most shipments arriving promptly to minimize operational downtime. Our efficient order processing allows for quick turnarounds, so your business can maintain seamless progress and productivity without unnecessary delays.

FAQ's of PANASONIC,PHOTOELECTRIC SENSOR, CX-441-P:

Q: How does the PANASONIC CX-441-P sensor detect objects?

A: The PANASONIC CX-441-P utilizes a polarized through-beam photoelectric sensing method with a red LED light source, providing reliable object detection up to 5 meters with high repeatability and accuracy.

Q: What benefits does the adjustable sensitivity feature offer?

A: Adjustable sensitivity allows users to personalize the sensor's detection threshold, optimizing performance for different applications, object sizes, or challenging environmental conditions.

Q: When should routine maintenance be performed on the CX-441-P sensor?

A: Routine maintenance is minimal due to its robust design; however, it is advisable to periodically check connections and ensure the sensor lens is clean to sustain optimal operation.

Q: Where should this sensor be installed for optimal results?

A: The sensor performs best when mounted on DIN rails or panels in industrial environments such as conveyor systems, where precise object presence detection and position sensing are required.

Q: What is the process for connecting the sensor to a control system?

A: The CX-441-P features a user-friendly 3-wire cable connection, allowing straightforward integration into digital output systems, and offers optional connector types for installation flexibility.

Q: How does the sensor withstand harsh industrial conditions?

A: With a polycarbonate housing, IP67 protection rating, and advanced protection circuits against reverse polarity and short circuits, the CX-441-P operates reliably even in demanding settings.
