AUTONICS AREA SENSOR, BWP20-08

AUTONICS AREA SENSOR, BWP20-08 Specification

Response Time
15 ms or less

Mounting Type
Bracket Mount

Application
Assembly Lines, Packaging, Safety Zones, Conveyors

Signal Type
Digital

Operating Temperature
-10°C to +50°C

Sensor Type
Photoelectric (Through-Beam Type)

Power Consumption
Max. 70 mA

Interface
Cable Output

Wireless
No

Cable Length
2 m

IP Rating
IP65

Features
Slim design, easy installation, high durability, dustproof, waterproof

Measurement Range
Sensing Distance 0.2-7 m

Sensitivity
Adjustable

Product Type
Area Sensor

Material
ABS Plastic

Input
12-24V DC

Output
NPN/PNP Open Collector

Function
Object Detection within Area

Usage
Automatic Detection/Counting

Accuracy
High

Resolution
20 mm Pitch

Voltage
12-24V DC Volt (v)

Weight
Approx. 330 g

Ambient Humidity
35% to 85% RH (No condensation)

Model
BWP20-08

Indicator
Operation indicator (Red LED)

Light Source
Infrared LED

Protection Circuit
Reverse polarity protection, Output short-circuit protection

Maximum Rated Voltage
30V DC

Number of Optical Axes
8

Material - Cover
Polycarbonate

Material - Case
ABS

Connection Method
Pre-wired (Cable)

About AUTONICS AREA SENSOR, BWP20-08

Experience the sublime reliability of the AUTONICS AREA SENSOR, BWP20-08, a sizzling addition to your automation toolkit. Personalise detection environments with this sought-after sensor, perfect for ephemeral object detection and counting needs. Boasting a high-resolution 20 mm pitch and a robust ABS/polycarbonate structure, it delivers terrific adaptability in challenging conditions. Its infrared LED technology ensures precise, high-speed sensing (0.27 m range) for packaging, assembly lines, or safety zones. Enjoy peace of mind with advanced protection circuits, remarkable IP65 durability, and effortless pre-wired installation.

Robust Build and Versatile Application

The AUTONICS AREA SENSOR, BWP20-08 features a sturdy ABS plastic case and a polycarbonate cover, ensuring longevity in tough industrial environments. Its slim, bracket-mount design makes it easy to install on assembly lines, packaging machinery, and conveyors. Thanks to its dustproof and waterproof IP65 rating, the sensor performs reliably on surfaces exposed to moisture and debris. The machines adjustable sensitivity and high-resolution detection meet high-precision requirements, making it ideal for automatic counting and safety applications.

Convenient Payment and Fast Delivery Options

We offer the AUTONICS AREA SENSOR, BWP20-08 at the lowest price, with flexible payment terms for your convenience. Secure your order with confidence we support sample policies for first-time buyers to evaluate our products quality. Expect your shipped goods to arrive on time through express shipping, ensuring minimal delays. Our streamlined process guarantees prompt delivery and excellent support every step of the way, helping traders, suppliers, and wholesalers across China and beyond.

FAQs of AUTONICS AREA SENSOR, BWP20-08:

Q: How does the AUTONICS AREA SENSOR, BWP20-08 detect objects?

A: This sensor uses infrared LED with through-beam photoelectric technology to detect and count objects within a sensing distance of 0.2 to 7 meters, ensuring accurate, high-speed detection on assembly lines, conveyors, and packaging systems.

Q: What are the main benefits of using the AUTONICS BWP20-08 sensor?

A: Its main benefits include high resolution (20 mm pitch), robust ABS/polycarbonate construction, advanced protection features, adjustable sensitivity, and waterproof/dustproof IP65 rating, making it ideal for demanding industrial environments.

Q: Where can the BWP20-08 sensor be installed?

A: The sensor is easy to install with a bracket mount and slim design, suitable for assembly lines, packaging machines, conveyors, and designated safety zones in manufacturing and automation industries.

Q: What payment terms and delivery options are available?

A: We provide competitive pricing, flexible payment terms, and express shipping for all orders. Sample policies are also available for new buyers to test product compatibility and performance.

Q: How do I connect and operate this area sensor?

A: Connection is simple with the pre-wired 2-meter cable. It supports voltage inputs of 1224V DC and offers both NPN/PNP open-collector outputs, ready for integration with your control systems.
