PANASONIC, DP-102

PANASONIC, DP-102 Specification

Sensitivity
High Sensitivity, 0.5% F.S.

Wireless
No

Response Time
2.5ms, 5ms, 100ms, 500ms Selectable

Sensor Type
Pressure Sensor

Features
Compact Design, Easy Operation, Key Lock Function, Overcurrent Protection

Cable Length
Standard 2m

Operating Temperature
0C to +50C

Mounting Type
Panel or DIN Rail Mount

IP Rating
IP40

Power Consumption
960mW

Measurement Range
100 kPa to +100 kPa

Signal Type
Digital Output

Application
Pneumatic and Hydraulic Equipment, Industrial Automation

Interface
LED Digital Display

Product Type
Sensor

Material
ABS Plastic

Input
DC 12-24V

Output
NPN/PNP Open Collector

Function
Pressure Detection

Usage
Industrial Pressure Monitoring

Accuracy
1% F.S.

Resolution
0.01 MPa

Voltage
1224V DC

Weight
Approx. 80g

Pressure Port Size
M5 Female Thread

Storage Temperature
-10C to +60C

Shock Resistance
100m/s2, 3 times in each direction

Model Number
DP-102

Protection Circuit
Reverse Polarity, Overload, Short Circuit

Ambient Humidity
35% to 85% RH (Non-Condensing)

Reset Type
Auto/Manual Reset

Adjustable Setpoints
2 Points (N.O./N.C. Selectable)

Repeatability
0.2% F.S. 1 Digit

Panel Cut Size
24 24mm

Compliance
CE Marked

Case Color
Grey

Vibration Resistance
10-55Hz, Double Amplitude 1.5mm

Display Type
3-Digit 7-Segment Red LED

Display Update Frequency
5 times/sec

About PANASONIC, DP-102

Jump on the transcendent performance of the PANASONIC DP-102 Pressure Sensor, a sterling choice for industrial automation and process monitoring. Experience ineffable savings through its precise pressure detection (1%% F.S.) and adjustable setpoints, ensuring optimal control for pneumatic and hydraulic equipment. With a vivid 3-digit red LED display, high sensitivity, and robust protection circuits, the DP-102s compact yet durable ABS construction suits demanding environments. Purchase with confidenceits CE compliance, repeatability, and versatile mounting provide unmatched reliability and value for your investment.

Application & Use in Industrial Environments

The PANASONIC DP-102 excels in a wide range of industrial pressure monitoring applications, including pneumatic and hydraulic systems. To use, mount the device on a control panel or DIN rail, connect the standard 2m cable, and adjust setpoints as needed. With its high repeatability and digital output, the DP-102 delivers dependable measurements, supporting plant automation and precision processes. Its key lock and easy operation features further streamline integration in manufacturing and automation plants.

Supply, Packaging, and Shipment Details

Our supply of the PANASONIC DP-102 is abundant to meet bulk industrial demands, offered at a competitive sale price. Each unit is carefully packaged for secure transit and reliable delivery. The FOB shipment is arranged via dedicated ports for timely dispatch. Product rates are designed to suit traders and wholesalers seeking dependable components for integration, ensuring both cost-effectiveness and expedited shipping for large-scale orders.

FAQs of PANASONIC, DP-102:

Q: How does the DP-102 ensure accurate pressure measurement in demanding conditions?

A: The DP-102 features high accuracy (1%% F.S.), high sensitivity (0.5%% F.S.), and repeatability (0.2%% F.S. 1 Digit), alongside robust protection circuits and a clear 3-digit LED display for reliable and precise results, even in harsh industrial settings.

Q: What are the key applications and industries for the PANASONIC DP-102?

A: This sensor is ideal for industrial automation, pneumatic and hydraulic equipment, and general pressure monitoring in manufacturing plants, providing precise monitoring and process control in various plant environments.

Q: Where can I mount and install the DP-102 sensor?

A: The PANASONIC DP-102 supports both panel and DIN rail mounting, allowing flexible integration within different control panels or industrial setups for ease of use and maintenance.

Q: What protection features are built into the DP-102?

A: It offers reverse polarity, overload, short-circuit, and overcurrent protection, ensuring the safety and longevity of both the sensor and connected equipment during operation.

Q: How does the PANASONIC DP-102 benefit industrial processes?

A: By delivering accurate, rapid, and stable digital pressure readings, the DP-102 optimizes pressure control, reduces system errors, and streamlines automationresulting in increased efficiency and savings over time.
