PEPPERL+FUCHS ,ML100-8H-350-RT/95/103,NBB8-18GM60-A2-5M-PUR-Y0168

PEPPERL+FUCHS ,ML100-8H-350-RT/95/103,NBB8-18GM60-A2-5M-PUR-Y0168 Specification

Response Time
< 1 ms

Operating Temperature
-25C to +55C

Cable Length
2 m, integrated cable

Mounting Type
Surface/Through holes, M3 screws

Sensitivity
Adjustable via potentiometer

Signal Type
3-wire, PNP output

Features
Polarization filter, visible red light, compact design

Power Consumption
< 30 mA

Application
Industrial automation, object detection

Interface
Cable connection

Measurement Range
0-3.5 m (with reflector)

Sensor Type
Retroreflective

IP Rating
IP67

Wireless
No

Product Type
Photoelectric Sensor

Material
LDPE

Input
10-30 V DC

Output
PNP, Light/Dark switching

Function
Retroreflective sensor with polarization filter

Usage
Detection of objects, presence, and materials

Accuracy
High switching precision

Voltage
10-30 V DC

Weight
Approx. 50 g

Status Indicators
LED for supply voltage and switching state

Housing
Plastic (LDPE)

Connection Type
2 m cable, 3 wire, PVC

Switching Frequency
800 Hz

Light Source
LED, red light, 660 nm

Enclosure Color
Black

Control Elements
Sensitivity adjustment via potentiometer

Ambient Light Immunity
Up to 5000 Lux

Activation/Deactivation delay
< 0.5 ms

Maximum Switching Distance
3.5 m (using reflecting tape)

Dimensions
31 mm x 19 mm x 11 mm

Target Type
Opaque and reflective objects

Reflection Type
Polarized retroreflective

Mechanical Protection
Reverse polarity protection, short-circuit protection

About PEPPERL+FUCHS ,ML100-8H-350-RT/95/103,NBB8-18GM60-A2-5M-PUR-Y0168

Redeem the benefits of advanced detection with the venerable PEPPERL+FUCHS ML100-8H-350-RT/95/103, a crowning achievement in retroreflective sensor technology. Powered by a praiseworthy red LED light source (660 nm), this sensor boasts a switching frequency of 800 Hz and a maximum detection range of 3.5 m using polarized retroreflection. Its robust LDPE housing, IP67 rating, and comprehensive protection features assure reliability in industrial automation. Pick yours to experience accuracy, fresh design, and versatile connections. Precise, fast, and built for performance, its ideal for critical object detection applications.

Industrial Application and Usage Areas

The PEPPERL+FUCHS ML100-8H-350-RT/95/103 sensor excels in industrial automation settings, with type of usage spanning object and material detection, presence verification, and quality control. Commercially, it is prized by manufacturers, wholesalers, and traders in China and beyond for its adaptable mounting, polarized retroreflection, and high immunity to ambient light. Its application areas include conveyor systems, packaging lines, and logistics, ensuring accurate detection of opaque and reflective objects under tough operating conditions.

Sample Policy and Supply Information

Samples of the ML100-8H-350-RT/95/103 can be shipped upon exchange of a formal quotation request. Our supply ability meets bulk orders efficiently, ensuring prompt delivery to our clients worldwide. Sample availability allows potential users to evaluate sensor performance firsthand, fostering trust before committing to larger purchases. We support smooth processes for exchanging order details or requesting tailored quotations, ensuring satisfaction from inquiry through delivery. Reach out to discuss your requirements and request a sample for assessment.

FAQs of PEPPERL+FUCHS ,ML100-8H-350-RT/95/103:

Q: How can I adjust the sensitivity of the ML100-8H-350-RT/95/103 sensor?

A: The sensitivity of this sensor can be easily modified using the built-in potentiometer, allowing you to tailor detection settings to your specific object or material.

Q: What type of objects can the retroreflective sensor detect?

A: This sensor reliably detects both opaque and reflective objects, making it suitable for use across various industrial automation processes.

Q: Where is the ML100-8H-350-RT/95/103 most commonly used?

A: It is primarily used in commercial and industrial settings such as factories, warehouses, and automated production lines for object, material, and presence detection.

Q: When can I expect a sample to be shipped after placing a request?

A: Samples are shipped promptly following the exchange and confirmation of a formal quotation, subject to product availability and shipping arrangements.

Q: What is the process to obtain a quotation for the ML100-8H-350-RT/95/103?

A: Contact us with your requirements and our team will provide a tailored quotation. Once accepted, you can request a sample or place a bulk order as needed.

Q: What benefits does using a polarized retroreflective sensor offer?

A: Polarized retroreflective sensors offer high reliability in differentiating between target objects and reflective backgrounds, ensuring accurate performance under diverse lighting conditions.
