OMRON TERMINAL RELAY, G6B-4BND

OMRON TERMINAL RELAY, G6B-4BND Specification

Ambient Temperature
-25C to +55C (no icing or condensation)

Contact Material
Silver Alloy

Power Consumption
Approx. 0.53W per relay

Coil Voltage
24V DC

Protect Feature
Built-in diode for coil surge absorption

Working Temperature
Up to 55C

Contact Form
4PDT (4 Form C)

Dielectiric Strength
1,000 VAC, 50/60 Hz for 1 min between coil and contacts

Mechanical Life
20,000,000 operations min.

Contact Resistance
100 m max. (initial)

Coil Power
Approx. 530 mW

Product Type
Terminal Relay Module

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
Industrial Automation, Control Panels

Contact Load
5A at 250VAC / 30VDC (Resistive Load)

Operate Time
10 ms max.

Terminal Type
Screw Terminal

Rated Voltage
24V DC

Supply Terminal
8-Point Type

Size
Compact

Color
Black & Gray

Dimension (L*W*H)
Approx. 80 mm x 70 mm x 20 mm

Weight
Approx. 180g

Rated Current
5A

Input Method
Transistor or Contact Input compatibility

LED Indicator
Yes, for coil activation

Series
G6B-4BND

Mounting Type
DIN Rail or Screw Mounting

Accessories Included
Socket, Jumpers

Number of Relays
4

About OMRON TERMINAL RELAY, G6B-4BND

Discover the exquisite OMRON TERMINAL RELAY, G6B-4BND-engineered for triumphant performance in industrial automation and control panels. Boasting a compact design and sturdy black & gray finish, this first-rate unit features four relays with screw terminals, LED indicators, and built-in diode protection. Compatible with DIN Rail or screw mounting, it supports both transistor and contact inputs. Rated at 5A with a 24V DC coil, this affordable solution is available at the lowest price for a limited time. Mechanical durability, exceptional insulation, and rapid operate time ensure optimal efficiency for your application.

Competitive Edge & Versatile Applications

The OMRON TERMINAL RELAY, G6B-4BND outshines competitors with its reliable 4PDT contacts, robust insulation, and lightning-fast 10 ms max operating time. Its mechanical life exceeds 20 million operations, making it a triumphant choice in automated machinery and control panels. This relay is widely used for industrial automation, signaling, and switching, offering exquisite performance in process control applications. With multiple mounting options, it integrates effortlessly into OEM designs and cutting-edge industrial solutions.

Delivery, Certifications & Freight Information

We ensure prompt delivery of the G6B-4BND, with standard domestic mar shipments dispatched swiftly from our China FOB port. All products are certified to meet industry safety and quality standards, giving you assured reliability in every exchange. Our freight partners handle both bulk and single orders meticulously for secure arrival. Explore quick order processing and prompt logistics for your automation needs with peace of mind knowing each relay meets OMRON's stringent requirements.

FAQ's of OMRON TERMINAL RELAY, G6B-4BND:

Q: How do I mount the OMRON G6B-4BND Terminal Relay?

A: The G6B-4BND offers versatile mounting options, allowing installation either on a DIN Rail or via screw mounting for adaptable integration in various control panels.

Q: What input methods are compatible with this relay model?

A: This relay supports both transistor and contact input methods, offering flexibility for different industrial automation requirements.

Q: When should I use the G6B-4BND in my automation system?

A: You should consider using the G6B-4BND for applications demanding rapid switching, high reliability, and where space-saving is essential, such as in process control panels and factory automation.

Q: What are the main benefits of the built-in LED indicator?

A: The LED indicator provides a clear visual status for the coil activation, enhancing usability and reducing troubleshooting time in busy panel environments.

Q: Where can I expect delivery of this relay and what is the typical lead time?

A: Deliveries are available worldwide, with prompt shipment from China's FOB port. Lead times vary depending on order quantity and destination, but domestic mar orders are generally processed quickly.
