OMRON SOCKET, PYFZ-14-E

OMRON SOCKET, PYFZ-14-E Specification

Mechanical Life
10,000 operations min.

Working Temperature
-40C to +70C

Contact Form
14-pin configuration

Dielectiric Strength
2000VAC for 1 min

Coil Power
Not Applicable (for socket)

Power Consumption
Low

Ambient Temperature
-40C to +70C

Contact Material
Nickel-plated copper alloy

Protect Feature
Finger protection (IP20)

Coil Voltage
Not Applicable (for socket)

Contact Resistance
100 m max.

Product Type
Socket

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromechanical

Usage
Relay connection

Contact Load
10A max at 250V AC

Operate Time
Instantaneous

Terminal Type
Screw terminal

Rated Voltage
250V AC

Supply Terminal
14-pin

Size
Standard DIN size

Color
Black

Dimension (L*W*H)
Approx. 97mm x 30mm x 26mm

Weight
Approx. 60g

Material
Flame-resistant plastic body with metal terminals

Current Capacity
10A max.

Pitch
8mm (between pins)

Model
PYFZ-14-E

Mounting Method
DIN rail or screw mounting

Applicable Relay
Omron LY2, LY3, LY4 series

About OMRON SOCKET, PYFZ-14-E

Jump on the hot-selling OMRON SOCKET, PYFZ-14-E, engineered for ace performance in relay connections. With its enlightened designflame-resistant plastic body and metal terminalsthis socket guarantees glorious reliability and safety. Compatible with Omron LY2, LY3, and LY4 series relays, it offers dual mounting methods (DIN rail or screw), a robust 10A max capacity, and finger protection (IP20). Its 14-pin screw terminal, black color, and low power profile make it ideal for industrial automation. Limited time availability, so upgrade your setup now!

Key Features & Applications of OMRON SOCKET, PYFZ-14-E

OMRON SOCKET, PYFZ-14-E is distinguished by its flame-resistant construction, metal terminals, and IP20 finger protection. Designed for instantaneous relay operation with Omron LY2, LY3, and LY4, this 14-pin black socket excels in panel boards, control cabinets, and factory automation environments. Its flexibility in DIN rail or screw mounting ensures easy integration. Ace reliability, high insulation resistance, and enduring mechanical life make it a favorite among engineers for diverse and demanding applications.

Delivery, Payment, and PackagingYour Quick Dispatch Solution

Experience quick dispatch and efficient shipment of the OMRON SOCKET, PYFZ-14-E. Packaging is secure to prevent damage during transit, ensuring your product arrives in glorious condition. Payment terms are flexible for both bulk and retail orders, with affordable shipment charges. With a standard delivery time frame, this hot-selling socket from our China-based supplier and wholesaler is readily available for immediate purchaseguaranteeing rapid fulfillment and customer satisfaction.

FAQs of OMRON SOCKET, PYFZ-14-E:

Q: How do I mount the OMRON SOCKET, PYFZ-14-E for reliable installation?

A: The OMRON SOCKET, PYFZ-14-E can be mounted using either DIN rail or screw mounting, providing flexibility to suit your installation environment and ensuring a secure fit in control panels or industrial enclosures.

Q: What are the main benefits of using this socket in relay connections?

A: This socket offers ace reliability, flame-resistant safety, finger protection (IP20), and strong insulation, ensuring stable operation for Omron LY2, LY3, and LY4 relays in automation and control applications.

Q: Where is the optimal site of application for the OMRON SOCKET, PYFZ-14-E?

A: Its widely used in factory automation, control cabinets, and electrical panels where quick relay replacement and durable performance are essential.

Q: What is the process for shipment and delivery of this socket?

A: After confirming payment, your order receives quick dispatch, with secure packaging and prompt shipment from our China-based supplier, ensuring timely delivery to your specified location.

Q: Can I use the PYFZ-14-E socket with any other relay models?

A: The PYFZ-14-E is specifically designed for Omron LY2, LY3, and LY4 series relays. Using it with non-compatible models may affect performance and is not recommended.
