OMRON SAFTEY RELAY, G9SA-321-T075

OMRON SAFTEY RELAY, G9SA-321-T075 Specification

Mechanical Life
10,000,000 operations min.

Protect Feature
Safety input monitoring, Short circuit detection

Coil Power
1.8W

Coil Voltage
24V DC

Contact Form
3NO (Safety), 1NC (Auxiliary)

Power Consumption
Approx. 1.8W

Dielectiric Strength
2,500V AC for 1 min between input, output and contacts

Ambient Temperature
-10C to +55C

Contact Material
Ag alloy

Working Temperature
-10C to +55C

Contact Resistance
100 m max.

Product Type
Safety Relay Unit

Insulation Resistance
100 M min. (at 500V DC)

Theory
Electromagnetic Relay

Usage
Safety monitoring, emergency stop circuits, safety door monitoring

Contact Load
6A at 250V AC (Resistive load)

Operate Time
35ms max.

Terminal Type
Screw terminal

Rated Voltage
24V DC

Supply Terminal
Screw type

Size
Compact (22.5 mm width)

Color
Yellow/Gray

Dimension (L*W*H)
22.5mm x 102.5mm x 120mm

Weight
Approx. 270g

Number of Channels
2-channel input

Shock Resistance
100 m/s2 (approx. 10G)

Safety Category
Up to PLe/Cat.4 (EN ISO 13849-1)

Standards Compliance
EN 60947-5-1, EN 60204-1, EN ISO 13849-1, IEC 61508

Rated Frequency
50/60 Hz

Reset Method
Automatic and manual reset

Vibration Resistance
10 to 55 Hz, 0.5 mm double amplitude

LED Indicators
Supply, input, and output status

Storage Temperature
-25C to +85C

Mounting Type
DIN rail

Pollution Degree
2

Degree of Protection
IP20 (Terminals)

OMRON SAFTEY RELAY, G9SA-321-T075 About

Take advantage of a remarkable discount on the OMRON SAFTEY RELAY, G9SA-321-T075! This heroic device is engineered for inestimable reliability in safeguarding emergency stop circuits and safety monitoring applications. With ace features like LED indicators, dual-channel input, and both automatic/manual reset, it ensures maximum protection up to PLe/Cat.4. Born from standards compliance including EN ISO 13849-1 and built for DIN rail mounting, this compact relay boasts robust vibration and shock resistance. Order today and elevate your safety system with proven OMRON precision.

Application Method and Unique Advantages

The OMRON G9SA-321-T075 is designed for seamless DIN rail mounting and simple screw terminal connections, making installation swift. Its dual input channels and safety input monitoring feature guarantee robust control over emergency stop and safety door monitoring circuits. As an ace in its class, this safety relay offers inestimable value through standards compliance, high mechanical life, and dual reset methods. Other applications include usage in machinery safety controls and industrial automation security systems.

Logistics, Export, and Sample Availability

Samples of the OMRON G9SA-321-T075 are available to assist your initial trials and demonstrations. With structured logistics and reliable freight services, prompt delivery to key export markets across Asia, Europe, and North America is assured. Each unit is carefully packaged to ensure safety and integrity during transit. Take advantage of our streamlined process and competitive export support-order with peace of mind, knowing your shipment will arrive securely and on time.

FAQ's of OMRON SAFTEY RELAY, G9SA-321-T075:

Q: How does the OMRON SAFTEY RELAY, G9SA-321-T075 enhance safety in industrial environments?

A: By providing dual-channel safety input monitoring, short circuit detection, and compliance with PLe/Cat.4 standards, the relay delivers ace-level safety for emergency stop circuits and safety door monitoring, ensuring inestimable protection of personnel and equipment.

Q: What are the main application methods for this safety relay?

A: The relay is designed for DIN rail mounting, making it easy to integrate into control panels. Connection is straightforward using screw terminals, suitable for both automatic and manual reset procedures.

Q: When should I use the G9SA-321-T075 in my system?

A: Use this relay when high-level safety category (up to PLe/Cat.4) and reliable emergency stop or safety door monitoring are required, especially in industrial machines and automation environments.

Q: Where can the OMRON G9SA-321-T075 be installed?

A: It is ideal for installation in industrial control panels or automation cabinets, thanks to its compact width of 22.5 mm and DIN rail compatibility.

Q: What are the benefits of ordering this safety relay from a trusted supplier or wholesaler in China?

A: Ordering from a reliable supplier ensures access to competitive discounts, prompt delivery, sample availability, and efficient logistics for international markets, maximizing both cost-effectiveness and convenience.

Q: How can I monitor the relay's operational status?

A: The unit includes LED indicators for supply, input, and output status, providing immediate visual confirmation of operating conditions and diagnostics for maintenance staff.
