OMRON , ROTARY ENCODER , E6B2-CWZ5B 500P/R

OMRON , ROTARY ENCODER , E6B2-CWZ5B 500P/R Specification

Sealed Type
Splash Proof

Features
Compact size, High-speed response, Incremental output, Reverse connection protection

Current Type
DC

Bearing Type
Ball Bearing

Voltage
12-24V DC

Ambient Temperature
-10 to +70C (No Freezing)

Rated Voltage
12-24V DC

Product Type
Rotary Encoder

Protect Feature
Reverse Connection Protection

Phase
Single Phase (Output: A, B, Z Phase)

Speed
Max. Response Frequency: 100 kHz

Color
Black/Gray

Dimension (L*W*H)
50 mm (Diameter) x 48.5 mm (Length)

Weight
Approx. 200 g

Shaft Diameter
8 mm

Mounting Type
Servo Mount / Clamp type mounting

IP Rating
IP64

Body Material
Metal/ABS

Allowable Radial Load
Max. 50 N

Connection Type
Cable type (2 meters)

Power Consumption
Max. 80 mA

Max. Rotational Speed
6,000 RPM

Applicable Industry
Automation, Packaging, Robotics, CNC Machines

Shock Resistance
1,000 m/s2 (approx. 100G), 3 times each in X, Y and Z directions

Resolution
500 pulses per revolution (P/R)

Cable Output
5-wire, shielded

Shaft Material
Stainless Steel

Model
E6B2-CWZ5B

Output Signal
Incremental

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Operating Humidity
35% to 85% RH (Non-condensing)

Storage Temperature
-25 to +85C

Output Type
NPN Open Collector

Allowable Axial Load
Max. 30 N

About OMRON , ROTARY ENCODER , E6B2-CWZ5B 500P/R

Experience unprecedented reliability with the OMRON ROTARY ENCODER E6B2-CWZ5B 500P/R, crafted for those seeking enlightened automation solutions. Its stainless-steel shaft and robust metal/ABS body encapsulate phenomenal durability, while the compact design ensures effortless integration. Achieve precision with a resolution of 500 pulses per revolution and high-speed responses up to 100 kHz. With splash-proof IP64 protection, reverse connection security, and a vibration-resistant build, this encoder is ideal for critical, ephemeral operations. Advance purchase secures the lowest price for an unparalleled automation investment.

Versatile Application Across Diverse Industries

The OMRON ROTARY ENCODER E6B2-CWZ5B 500P/R is designed for both specific and general automation uses. It is highly suitable for robotics, CNC machines, packaging systems, and a variety of industrial automation applications. Those requiring steadfast performance in harsh environments benefit from its robust construction and compact, adaptable design. Known for its accuracy and reliability, this encoder is commonly used by professionals in production lines, assembly systems, and automated machinery to ensure seamless and precise motion control.

Sample Availability and Dependable Distribution

Sample units of the OMRON ROTARY ENCODER E6B2-CWZ5B 500P/R are available to support your evaluation process, with secure shipping methods ensuring product safety. Our extensive supply ability caters to both domestic markets and international export demands, delivering promptly to clients worldwide. Export markets include various regions, supported by streamlined order processing and optional charges for extra services. Trust our commitment to providing swift deliveries and comprehensive support for your procurement needs.

FAQs of OMRON , ROTARY ENCODER , E6B2-CWZ5B 500P/R:

Q: How does the OMRON E6B2-CWZ5B rotary encoder benefit automation processes?

A: This rotary encoder provides exceptional accuracy and high-speed response, ensuring precise motion control in automated systems. Its robust build and resistance to harsh conditions make it reliable in continuous industrial operations.

Q: What are the main applications suitable for this model?

A: The E6B2-CWZ5B is ideal for robotics, packaging machines, CNC equipment, and other automation fields requiring precise position or speed detection. Its compatibility with a wide range of machines ensures broad utility.

Q: When should I consider using a 500 pulses per revolution (P/R) encoder?

A: A 500 P/R encoder is recommended when high precision and detailed feedback are needed for motion control tasks, such as in CNC machines, automated assembly lines, or precise robotics applications.

Q: Where can this rotary encoder be installed?

A: Thanks to its compact, servo/clamp type mounting and splash-proof IP64 rating, the encoder can be mounted in challenging industrial environments, including production floors, packing systems, and machine enclosures.

Q: What process ensures secure delivery of encoders to buyers?

A: Products are packed professionally with secure shipping methods to protect the encoder from damage, and tracking is provided for all domestic and international shipments, ensuring peace of mind.
