OMRON RELAY SOCKET, PYFZ-14-N

OMRON RELAY SOCKET, PYFZ-14-N Specification

Contact Material
Relay Dependent

Contact Form
Supports DPDT, 4PDT Relays

Contact Resistance
N/A (Socket)

Working Temperature
-40C to 70C

Power Consumption
N/A (Socket)

Mechanical Life
N/A (Socket)

Coil Power
Relay Dependent

Coil Voltage
Relay Dependent

Ambient Temperature
-40C to 70C

Dielectiric Strength
2000VAC for 1 min

Protect Feature
Finger Safe and Standards Compliant

Product Type
Relay Socket

Insulation Resistance
>100 M at 500VDC

Theory
Socket for Plug-in Relays

Usage
Relay Socket for Industrial Automation and Control Panels

Contact Load
Depends on fitted relay

Operate Time
N/A (Socket)

Terminal Type
Screw Terminal

Rated Voltage
250V AC

Supply Terminal
Screw Clamp Terminal

Size
Standard, 14 Pin

Color
Black / Grey

Dimension (L*W*H)
Approx. 78mm x 28mm x 23mm

Weight
Approx. 45g

Mounting Type
DIN Rail or Panel Mount

Standards Met
IP20 Finger Protection, IEC Compliance

Quantity per Box
50 Pieces

No. of Pins
14 Pin

Part Number
PYF14A-N (Alias Model Indicated on Box)

Body Material
High-Grade Plastic

Model Number
PYFZ-14-N

Lot No.
0336

Compatible Relays
MY4 Series, 14-pin Relays

OMRON RELAY SOCKET, PYFZ-14-N About

Order the stellar OMRON RELAY SOCKET, PYFZ-14-N today and elevate your industrial automation setup! Crafted with brilliant high-grade plastic and engineered for superlative reliability, this 14-pin socket offers both DIN Rail and Panel Mount flexibility. Featuring IP20 finger protection and compliant with IEC standards, it ensures safe operation in demanding environments. Grab yours for a limited time - each box includes 50 pieces, compatible with MY4 Series and 14-pin relays. Don't miss out on this stellar solution for control panels-supply is limited!

Optimized Application for Industrial Reliability

The OMRON RELAY SOCKET, PYFZ-14-N, is expertly designed for integration in control panels and automation systems across various industrial sectors. This socket excels on both DIN Rail and Panel Mount surfaces, ensuring secure installation and broad compatibility. Its robust, high-grade plastic body and IP20 finger protection offer excellent safety for applications within machinery rooms, automation cabinets, and process control setups. Suitable for dry and controlled indoor media, the PYFZ-14-N supports reliable performance in demanding environments.

Secured Payment and Efficient Global Delivery

Payment for the OMRON RELAY SOCKET, PYFZ-14-N, is handled smoothly through flexible terms for a seamless handover. Upon order confirmation, shipped goods are carefully packaged-50 relay sockets per box-to ensure safe arrival at your doorstep. With well-organized export logistics, the main export markets include Asia, Europe, and the Middle East. Experience secure transactions and meticulous packaging, guaranteeing that each shipment arrives in premium condition, ready for immediate integration into your projects.

FAQ's of OMRON RELAY SOCKET, PYFZ-14-N:

Q: How do I mount the OMRON PYFZ-14-N relay socket?

A: You can mount the PYFZ-14-N relay socket on either a DIN rail or directly onto a panel, providing installation versatility for industrial control applications.

Q: What relays are compatible with the PYFZ-14-N socket?

A: This socket is designed to work with OMRON's MY4 Series and other 14-pin plug-in relays, supporting DPDT and 4PDT contact forms.

Q: Where can I apply the OMRON PYFZ-14-N in my facility?

A: It is suitable for installation inside control panels, automation cabinets, and industrial environments needing reliable relay interfacing for signal switching and device control.

Q: What are the payment and shipping details for the PYFZ-14-N socket?

A: Payment terms are flexible and confirmable during ordering. Each box contains 50 sockets, with shipped goods securely packaged for safe international arrival.

Q: What are the main benefits of using the PYFZ-14-N relay socket?

A: The PYFZ-14-N socket offers stellar safety with IP20 protection, ease of installation, compatibility with standard relays, and durable construction, making it a superlative choice for industrial automation systems.
