OMRON RELAY 24VDC, G2R-1

OMRON RELAY 24VDC, G2R-1 Specification

Working Temperature
-40C to +70C

Mechanical Life
10,000,000 operations min.

Dielectiric Strength
Between coil and contacts: 5,000 VAC, 50/60 Hz for 1 min

Protect Feature
Sealed, Dust Cover

Ambient Temperature
-40C to +70C

Power Consumption
Approx. 0.53 W

Contact Form
SPDT (1 Form C)

Coil Power
0.53 W

Contact Resistance
100 m max. (Initial)

Coil Voltage
24VDC

Contact Material
Silver alloy

Product Type
Electromechanical Relay

Insulation Resistance
1000 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
General Purpose, Industrial Automation

Contact Load
10A at 250VAC / 10A at 30VDC (Resistive Load)

Operate Time
10 ms max.

Terminal Type
Plug-in

Rated Voltage
24VDC

Supply Terminal
Screw / Solder Terminal

Size
Standard Miniature

Color
Transparent (Cover), Black (Base)

Dimension (L*W*H)
29 mm x 13 mm x 25.5 mm approx.

Weight
Approximately 35 g

Shock Resistance
1,000 m/s2 (approx. 100 G)

Mounting Type
DIN Rail / PC Board Mount (with socket options)

Humidity Resistance
5% to 85% RH

LED Indicator
Optional Available

Voltage Endurance
Between contacts: 1,000 VAC for 1 min

Release Time
5 ms max.

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Safety Approvals
UL, CSA, VDE, CE certified

Model Number
G2R-1

Coil Resistance
About 1,044

OMRON RELAY 24VDC, G2R-1 About

The OMRON RELAY 24VDC, G2R-1 stands as an elite and highly recommended component for demanding industrial applications. With first-class features including unparalleled vibration and shock resistance, an optional LED indicator, and UL, CSA, VDE, and CE certifications, this relay ensures both safety and reliability. Its noble design, sealed dust cover, and transparent housing make it a preferred choice among professionals. The robust 10A contact load, wide temperature range, and swift operation time cater to general purpose and automation needs with exceptional performance. Buy this relay to elevate your automation to a truly superior standard.

Advanced Features and Versatile Applications

The OMRON RELAY 24VDC, G2R-1 offers unrivaled reliability through outstanding insulation resistance, vibration, and shock protection, and robust contacts rated up to 10A. Designed for both PC board and DIN rail mounting, it excels in industrial automation, control panels, and OEM projects. Its transparent cover simplifies inspection, while optional LED indication enhances user convenience. This versatile relay is ideal for plant automation, machine controls, and general industrial solutions demanding consistent, long-life performance.

Payment, Sampling, and Domestic Market Details

Purchasing the OMRON RELAY 24VDC, G2R-1 requires a simple purchase order process, ensuring efficient shipment and prompt delivery. Cost outlay is competitive for such a first-class component. Samples may be available for evaluation, following supplier sample policy. The relay is primarily distributed within the main domestic market, leveraging reliable wholesale channels. Buyers benefit from secure transactions and streamlined logistics, making procurement straightforward for businesses and plant maintenance teams alike.

FAQ's of OMRON RELAY 24VDC, G2R-1:

Q: How can the OMRON RELAY 24VDC, G2R-1 be mounted?

A: The relay is highly versatile and can be mounted on either DIN rails or directly onto PC boards using the appropriate socket options, providing flexibility for different application requirements.

Q: What are the main benefits of using this relay in industrial automation?

A: The OMRON G2R-1 relay offers unparalleled reliability, rapid response, high contact load capacity, and durability, making it highly recommended for continuous industrial automation and control system operations.

Q: Where is the optimal environment to use this relay?

A: This relay is suitable for environments ranging from -40C to +70C, with ambient humidity of 5% to 85% RH. Its robust construction and certifications make it ideal for plant automation and general industrial applications.

Q: What are the safety certifications for this relay?

A: The relay boasts first-class safety approvals, having been certified by UL, CSA, VDE, and CE, ensuring compliance with international industrial standards.

Q: How does the sample policy work for the OMRON G2R-1 relay?

A: Sample availability depends on supplier policies. Prospective buyers can inquire about sample access when placing a purchase order or during initial communications with the trader or wholesaler.
