OMRON, RELAY, MY4N-GS-R

OMRON, RELAY, MY4N-GS-R Specification

Ambient Temperature
-40C to +70C

Working Temperature
-40C to +70C

Coil Voltage
220-240 VAC

Contact Form
4PDT

Coil Power
Approx. 1.2 VA

Power Consumption
Approx. 1.2 VA

Dielectiric Strength
2,000 VAC for 1 min

Contact Material
Ag alloy

Mechanical Life
10,000,000 operations min.

Protect Feature
Sealed

Contact Resistance
100 m max.

Product Type
General Purpose Relay

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
Industrial Automation

Contact Load
5A at 250VAC / 30VDC

Operate Time
20 ms max.

Terminal Type
Plug-in

Rated Voltage
220-240 VAC

Supply Terminal
Screw / Socket

Size
Standard Miniature

Color
Transparent with Black Base

Dimension (L*W*H)
28 x 21.5 x 36 mm

Weight
About 90 g

Standards
IEC 61810, JIS C5442, EN61810-1

Vibration Resistance
10 to 55 Hz, 1.0 mm double amplitude

Shock Resistance
1,000 m/s2 (operating) / 100 m/s2 (error)

Enclosure Material
Polycarbonate (Housing)

Number of Pins
14 pins

Indicator
Built-in LED indicator

Manual Test Button
Yes (Lockable)

Mounting Type
Socket Mount

About OMRON, RELAY, MY4N-GS-R

Access the rare fusion of reliability and precision with the OMRON RELAY MY4N-GS-R, a premier choice for industrial automation tasks. Select this illustrious electromagnetic relay, featuring a robust socket mount and a redoubtable built-in LED indicator with lockable manual test button. Withstanding shock up to 1,000 m/s2 and vibrations between 10-55 Hz, it conforms to IEC 61810 and other global standards. Its transparent polycarbonate enclosure with a black base, 14 pins, and sealed protection offers security and convenience for demanding environments. Benefit from a substantial mechanical life and unwavering performance in extreme temperatures.

Designed for Industrial Brilliance

The OMRON RELAY MY4N-GS-R is expertly crafted for industrial automation, offering unmatched reliability and operational clarity. Suitable for plug-in applications, its direction of use is straightforward-mount securely using socket/screw connections. Gain a competitive advantage from features like the lockable manual test button, superior shock and vibration resistance, and a transparent housing for easy inspection. This relay distinguishes itself by ensuring secure operation in rigorous environments, making every process seamless and reliable.

Supply Assurance and Global Standards

With robust supply ability from trusted suppliers, traders, and wholesalers in China, the OMRON RELAY MY4N-GS-R is shipped swiftly to meet diverse demands. Samples are available for verification prior to large orders. Certified under IEC 61810, JIS C5442, and EN61810-1, every relay passes strict logistics and quality control. Shipped goods reach you efficiently, backed by well-documented certifications, reinforcing our reputation for excellence in global industrial logistics.

FAQ's of OMRON, RELAY, MY4N-GS-R:

Q: How do I install and use the OMRON RELAY MY4N-GS-R in an automation system?

A: Installation is simple: plug the relay into its socket mount, connect the supply terminals via screw or socket, and monitor operations using the built-in LED indicator. The lockable manual test button allows for easy operational checks during setup or maintenance.

Q: What are the benefits of the built-in LED indicator and lockable manual test button?

A: The built-in LED indicator provides instant visual feedback, making status monitoring effortless. The lockable manual test button enables secure manual operation for testing and diagnostics without disrupting live control processes.

Q: Where is the OMRON RELAY MY4N-GS-R typically used?

A: This relay is primarily employed in industrial automation applications requiring dependable switching and control, offering robust shock, vibration, and temperature resistance for harsh working environments.

Q: What certifications does the OMRON RELAY MY4N-GS-R hold?

A: It is certified under IEC 61810, JIS C5442, and EN61810-1 standards, ensuring international compliance for quality, safety, and performance.

Q: How is the supply and shipping process managed for this relay?

A: Suppliers in China offer strong logistics support, ensuring the relay is shipped quickly. Sample units can be shipped ahead of bulk orders, and secure packaging ensures goods arrive undamaged.
