OMRON RELAY, MKS3PN 24VDC 11PIN

OMRON RELAY, MKS3PN 24VDC 11PIN Specification

Coil Voltage
24VDC

Contact Material
Silver alloy

Power Consumption
Approx. 0.9W

Ambient Temperature
-10C to +55C

Protect Feature
With dust cover

Working Temperature
-10C to +55C

Mechanical Life
20,000,000 operations min.

Contact Resistance
100 m max. (initial)

Coil Power
0.9W

Dielectiric Strength
2,000VAC, 50/60 Hz for 1 min (between coil & contacts)

Contact Form
3PDT (3 Form C)

Product Type
General Purpose Relay

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
Industrial Automation, Control Panels, Power Management

Contact Load
10A at 250VAC / 24VDC

Operate Time
15 ms max.

Terminal Type
11 Pin

Rated Voltage
24VDC

Supply Terminal
Screw Terminals

Size
Standard 11 Pin Octal

Color
Transparent/Black

Dimension (L*W*H)
Approx. 35.5 x 35.5 x 53 mm

Weight
Approx. 85g

Voltage Range
80% to 110% of rated voltage

Storage Temperature
-25C to +70C

Mounting Type
Plug-in

Enclosure Material
Polycarbonate

Coil Resistance
Approx. 650 Ohm (at 20C)

Number of Pins
11

Release Time
10 ms max.

Vibration Resistance
10 to 55 Hz, 1.0 mm double amplitude

Contact Arrangement
3PDT

Shock Resistance
1,000 m/s2 (approx. 100G)

About OMRON RELAY, MKS3PN 24VDC 11PIN

Experience the sizzling innovation of the OMRON RELAY, MKS3PN 24VDC 11PIN-an advanced, trending solution crafted for world-class performance in industrial automation, control panels, and power management systems. With optimum coil resistance of approximately 650 Ohm at 20C, this relay boasts ineffable durability, thanks to its robust polycarbonate enclosure and dust cover. Engineered with an 11-pin octal design and silver alloy 3PDT contacts, it assures reliable switching under diverse conditions and a stellar mechanical life of 20 million operations. Explore advance purchase opportunities from our trusted network of suppliers, traders, and wholesalers in China.

Versatile Applications in Industrial Settings

The OMRON RELAY, MKS3PN 24VDC 11PIN is optimized for plant applications spanning industrial automation, power management, and precision control panels. Its robust 3PDT contact arrangement and transparent polycarbonate enclosure are ideal for usage in dynamic and demanding operations. The relay excels in application media that include electrical automation, safety circuits, and high-load switching, offering resilient performance under rigorous working temperatures and environmental conditions.

Flexible Sampling, Certifications, and Shipping Solutions

Sample units of the OMRON RELAY, MKS3PN 24VDC 11PIN are available for testing and evaluation to ensure suitability for your applications. Goods transport and packaging are carefully managed, utilizing certified protective packing for express shipping and secure handling of shipped goods. Our supply process conforms to international quality and safety standards, guaranteeing your product arrives safely and swiftly, ready for immediate integration into your systems.

FAQ's of OMRON RELAY, MKS3PN 24VDC 11PIN:

Q: How does the OMRON RELAY, MKS3PN 24VDC 11PIN benefit industrial automation systems?

A: Its robust design, fast response times, and high contact load capacity ensure reliable switching and optimum performance in industrial automation, making it a trending choice for both new and retrofit applications.

Q: What applications can use the MKS3PN 24VDC relay?

A: This relay is ideally suited for control panels, power management setups, and industrial automation processes where dependable electromagnetic switching is essential.

Q: When should I opt for advance purchase of this relay?

A: Advance purchase is recommended for large-scale projects, high-volume requirements, or to secure trending components before peak demand periods.

Q: Where is the OMRON RELAY, MKS3PN 24VDC 11PIN primarily manufactured and supplied from?

A: This product is sourced and supplied by reputable suppliers, traders, and wholesalers originating from China, ensuring worldwide distribution.

Q: What certifications and protections come with the relay during shipping?

A: The relay is backed by certifications relevant to industrial standards and is shipped using protected, certified packaging for safe transport.

Q: How quickly can shipped goods reach me, and what packaging is used?

A: With express shipping options, goods can be delivered promptly, and they are packaged using robust materials to prevent damage during transportation.
