OMRON RELAY, G2R-1-E

OMRON RELAY, G2R-1-E Specification

Contact Resistance
100m max. Milliohm (m)

Working Temperature
-25C to +55C Celsius (oC)

Contact Form
SPDT (Single Pole Double Throw)

Coil Power
0.4W

Coil Voltage
24V DC Volt (V)

Power Consumption
Approx. 0.4W Watt (W)

Ambient Temperature
-25C to +55C Celsius (oC)

Contact Material
Silver Alloy

Protect Feature
Dust-proof Case

Product Type
Electromechanical Relay

Insulation Resistance
100M min. (at 500 VDC)

Theory
Electromagnetic

Usage
General purpose electrical control

Contact Load
10A at 250VAC / 24VDC

Terminal Type
Plug-in

Rated Voltage
24V DC Volt (V)

Supply Terminal
Screw Terminal

Color
Transparent/Black

Dimension (L*W*H)
29 x 13 x 25.5 mm Millimeter (mm)

Weight
Approximately 21 g Grams (g)

Minimum Load
10 mA at 5VDC

Model Number
G2R-1-E

Application
Panel Boards, PLCs, Industrial Automation

Rated Current
10A

Humidity
5% to 85% RH (Non-condensing)

Vibration Resistance
10 to 55 Hz at double amplitude of 1.5 mm

Storage Temperature
-40C to +70C

Mounting Type
PCB/Socket

Shock Resistance
1,000 m/s

Contact Arrangement
1 Form C

Coil Resistance
1,440

Release Time
5 ms Max.

Coil Type
DC Coil

OMRON RELAY, G2R-1-E Trade Information

Minimum Order Quantity
30 Number

Supply Ability
100 Per Month

Delivery Time
7 Days

About OMRON RELAY, G2R-1-E

Jump on this top-ranking OMRON RELAY, G2R-1-Especially designed for peak performance in panel boards, PLCs, and industrial automation. With impeccable reliability, it boasts 10A contact load, ineffable mechanical life of 10 million cycles, and robust dust-proof casing. The bargain on this limited stock relay is unbeatable, offering SPDT (1 Form C) contact, 24V DC coil, and plug-in/screw terminal design. Sized standard at just 29 x 13 x 25.5 mm and weighing 21g, it fits seamlessly into your electrical controls. Secure your supply today from a trusted China trader and supplier!

Unmatched Features, Flexible Applications, Easy Usage

The OMRON RELAY, G2R-1-E offers seamless integration for panel boards and industrial automation setups. Simply mount it on a PCB or socket, using screw terminals for a secure fit. The transparent case plus vibration and shock resistance ensures dependable operation. With a 1 Form C SPDT contact arrangement and versatile compatibility with a wide range of electrical control systems, its dust-proof and ideal for both general and demanding usage environments. Operate confidently across -25C to +55C ambient conditions.

Reliable Supply, Transparent Policy, Competitive Pricing

Our sample policy provides access to trial units, subject to a competitive list price and quotation based on order size. Reliable transport services ensure safe delivery with every order of the OMRON RELAY, G2R-1-E. We maintain consistent supply ability to meet bulk and repeat demands, and provide certifications upon request to verify quality and compliance. As an established supplier and wholesaler, we assure customer satisfaction with prompt quotations and dedicated support throughout the procurement process.

FAQs of OMRON RELAY, G2R-1-E:

Q: How is the OMRON RELAY, G2R-1-E typically mounted for use?

A: The relay is designed for easy installation with options for PCB or socket mounting, using plug-in and screw terminal connections to ensure a secure fit in electrical panels and automation systems.

Q: What types of applications suit the G2R-1-E relay best?

A: It is ideal for panel boards, PLCs, and various industrial automation systems due to its high durability, compact size, and reliable performance under challenging environmental conditions.

Q: What certifications and quality assurances are provided with the relay?

A: Certifications are available upon request, and compliance is maintained with industry standards for reliability, mechanical life, and environmental resistance to ensure impeccable operation.

Q: What is the process for obtaining a quotation or sample of the G2R-1-E relay?

A: To receive a quotation or sample, simply contact us with your requirements. Well provide a competitive list price, arrange sample shipment, and offer detailed information on transport services and supply ability.

Q: How does the dust-proof and shock resistance feature benefit the user?

A: The dust-proof case and vibration/shock resistance enhance operational longevity, minimize maintenance, and ensure reliable switching even in harsh or demanding environments.

Q: What is the usage process and connection method for this relay?

A: Install the relay on a compatible PCB or socket, connect via screw terminals, and integrate it into your control circuit using the SPDT switch mechanism for flexible electrical control.
