OMRON RELAY 24VDC, MY2N-GS-R

OMRON RELAY 24VDC, MY2N-GS-R Specification

Contact Material
Silver alloy

Dielectiric Strength
2,000 VAC, 1 min.

Working Temperature
-40C to 70C

Protect Feature
With mechanical indicator and diode

Ambient Temperature
-40C to 70C

Coil Voltage
24VDC

Contact Resistance
50 m max.

Mechanical Life
50,000,000 operations min.

Power Consumption
Approx. 0.9 W

Coil Power
0.9W

Contact Form
DPDT (Double Pole Double Throw)

Product Type
Electromechanical Relay

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
General Purpose

Contact Load
5A at 250VAC / 30VDC

Operate Time
20 ms max.

Terminal Type
Plug-in

Rated Voltage
24VDC

Supply Terminal
Screw terminal

Size
Standard Miniature Size

Color
Transparent with blue base

Dimension (L*W*H)
27.0 mm x 21.0 mm x 35.6 mm

Weight
Approx. 35 g

Mounting Type
DIN Rail/Socket Mount

Maximum Switching Voltage
250VAC / 30VDC

Shock Resistance
1,000 m/s2

Minimum Switching Current
10 mA

Storage Temperature
-40C to 70C

Housing Material
Polycarbonate

Release Time
20 ms max.

Model Number
MY2N-GS-R

Number of Pins
8

Rated Carry Current
5A

Contact Configuration
2NO-2NC (Double Throw)

Application
Control Panels, Automation Systems, Power Supplies

LED Indicator
Yes

Vibration Resistance
Frequency: 10 to 55 Hz, Amplitude: 1.0 mm

About OMRON RELAY 24VDC, MY2N-GS-R

Take advantage of extraordinary reliability with the OMRON RELAY 24VDC, MY2N-GS-R. Select this brilliant relay, offering an opulent polycarbonate housing and a transparent, blue-accented design. With 2NO-2NC contact configuration, LED indicator, and a strong 5A switching capacity, it meets demanding standards of modern automation and control panels. Benefitting from a compact, DIN rail/socket mountable profile, rapid 20 ms max. operate/release times, and mechanical durability of up to 50 million operations, this relay represents a versatile, general-purpose solution with superior mechanical and environmental resistance.

Optimal Application and Versatile Performance

The OMRON RELAY 24VDC, MY2N-GS-R is engineered for extraordinary performance in control panels, automation systems, and power supplies. Take advantage of its robust insulation resistance, opulent polycarbonate construction, and plug-in, screw terminal installation. This relay is exceptionally suitable for general-purpose industrial use, offering reliable switching in varied ambient conditions. Its brilliant design ensures optimal operation in demanding environments, making it a top choice for integrators and automation professionals alike.

FOB, Supply Capability, and Delivery Processes

Drop-off at major Chinese ports is facilitated for the OMRON RELAY 24VDC, MY2N-GS-R through meticulous packing & dispatch systems. Delivered to suppliers, traders, or wholesalers with efficiency, the company offers excellent supply ability to meet high-volume orders. Sample availability ensures you can review the relay's opulent features prior to bulk requests. Each order is securely packed, promising seamless transport from dispatch to destination, guaranteeing customer satisfaction at every level.

FAQ's of OMRON RELAY 24VDC, MY2N-GS-R:

Q: How can the OMRON RELAY 24VDC, MY2N-GS-R be integrated into automation systems?

A: The relay can be easily mounted using a DIN rail or socket, making it compatible with various automation systems. Its compact size and plug-in terminals streamline installation in control panels.

Q: What are the primary applications for this relay model?

A: This relay is widely used in control panels, automation systems, and power supplies, where dependable switching and insulation resistance are essential.

Q: When is it beneficial to use the OMRON MY2N-GS-R relay?

A: This relay is ideal for general-purpose use when you require reliable operation, mechanical durability, and high switching capacity in industrial environments.

Q: Where is the relay shipped from, and is sample availability an option?

A: The relay is shipped from China, with FOB options for major ports. Sample units are available for evaluation before large-scale purchasing.

Q: What are the key advantages of the mechanical indicator and diode protective feature?

A: The mechanical indicator provides a visual status, while the diode ensures protection from voltage spikes, enhancing relay longevity and reliability.

Q: How does the supply and delivery process work for bulk orders?

A: Bulk orders are securely packed and dispatched from China, with efficient delivery to wholesalers, traders, or suppliers at designated drop-off points.
