OMRON PROXIMITY SWITCH, E2EM-X15B2

OMRON PROXIMITY SWITCH, E2EM-X15B2 Specification

Rated Voltage
12 to 24V DC Volt (V)

Mechanical Life
2,000,000 operations min.

Temperature Range
-25C to +70C

Finish Type
Nickel-plated

Protection Level
IP67

Circuit Type
NPN/PNP (depending on model)

Max. Current
200 mA max.

Number of Module
1

Response Time
1 ms max.

Automation Grade
Automatic

Product Type
Proximity Switch

Material
Nickel-plated brass (case), PBT (sensing face)

Insulation Resistance
50 M min. (at 500 VDC megger)

Contact Resistance
100 m max.

Max. Voltage
12 to 24V DC Volt (V)

Operating Temperature
-25C to +70C (with no icing or condensation)

Size
5m (cable length)

Color
Silver/Black

Weight
Approx. 110 g (with 5m cable)

Mounting Type
Flush

Current Rating
200 mA max.

No Of Poles
2-Wire

Storage Temperature
-40°C to +85°C

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude, 2 hrs each in X, Y, and Z directions

Output Type
DC 2-wire

Sensing Distance
15 mm

Model
E2EM-X15B2

Humidity
35% to 95% RH

Indicator
Operation indicator (red LED)

Additional Product Specifications

Standard
CE Compliant, RoHS Compliant

Shock Resistance
1,000 m/s², 10 times each in X, Y, and Z directions

Cable Type
PVC Insulated

About OMRON PROXIMITY SWITCH, E2EM-X15B2

Get It Now: the OMRON PROXIMITY SWITCH, E2EM-X15B2, an incomparable solution designed for dynamic automation environments. With a soaring sensing distance of 15mm, this astounding device boasts a fresh, sturdy construction of nickel-plated brass for superior durability. Its ephemeral yet powerful operation indicator (red LED) ensures quick diagnostics, while its IP67 protection and CE/RoHS compliance offer steadfast performance. Experience minimal downtime and maximum efficiency thanks to outstanding shock and vibration resistance, plus a 2-wire DC output for effortless integration. Suitable for demanding conditions, this switch is your key to unrivaled reliability.

Commercial Applications, Construction & Easy Mounting

The OMRON PROXIMITY SWITCH, E2EM-X15B2 is expertly engineered for commercial automation, manufacturing lines, and industrial control systems. Constructed from nickel-plated brass with a robust PBT sensing face, it ensures a fresh finish and extended service life. This automatic, flush-mount device enables seamless application and effortless integration, catering to dynamic workspace needs. The 5-meter PVC-insulated cable further enhances installation flexibility, making it ideal for complex configurations and fast-paced environments.

Main Export Markets, Compliance & Fast Delivery

Focused on the outlay for commercial and industrial sectors, the E2EM-X15B2 is widely favored in international markets owing to CE and RoHS certifications. With quick dispatch and streamlined order completion, customers enjoy expedited service and reliable delivery timelines. The product meets stringent export requirements to regions including Europe, Asia, and North America. Choose this OMRON switch to ensure robust performance and trusted compliance, supported by prompt logistics and industry partnerships.

FAQs of OMRON PROXIMITY SWITCH, E2EM-X15B2:

Q: How do I mount and connect the OMRON PROXIMITY SWITCH, E2EM-X15B2?

A: This switch features a flush mounting design and comes with a 5-meter PVC-insulated cable, enabling straightforward installation. Simply connect the two-wire output to your DC circuit as per the wiring diagram provided in the manual.

Q: What are the key benefits of using the E2EM-X15B2 in automation systems?

A: The E2EM-X15B2 offers unparalleled reliability, resistance to shock and vibrations, and an operation indicator for quick diagnostics. Its 15 mm sensing distance and fast 1 ms response time ensure exceptional performance in demanding automation environments.

Q: Where can the E2EM-X15B2 be effectively deployed?

A: This proximity switch is ideal for commercial and industrial settings such as manufacturing lines, conveyor systems, and automated machinery control, especially where high durability and accuracy are essential.

Q: What certifications does the OMRON PROXIMITY SWITCH hold?

A: The E2EM-X15B2 is CE compliant and RoHS compliant, affirming its suitability for international standards and environmentally conscious operations.

Q: When can I expect delivery after placing an order?

A: Order completion and quick dispatch are prioritized, ensuring that products typically ship swiftly following confirmation, subject to supplier policies and shipping arrangements.

Q: How does the device handle harsh environmental conditions?

A: With an IP67 protection level, the E2EM-X15B2 resists dust and water ingress. It also operates efficiently within a wide temperature range and is designed to withstand heavy shock and vibrations, making it highly dependable in rigorous sectors.
