OMRON PROXIMITY SENSOR, E2EM-X16MX1 2M

OMRON PROXIMITY SENSOR, E2EM-X16MX1 2M Specification

Application
Metal sensing, industrial machinery automation

Measurement Range
16mm (sensing distance)

Operating Temperature
-25C to +70C

IP Rating
IP67

Sensitivity
Detects ferrous metals

Response Time
Less than 1ms

Interface
3-wire DC

Sensor Type
Inductive Proximity Sensor

Cable Length
2 meters

Power Consumption
15 mA

Wireless
No

Features
Long sensing distance, high durability, short-circuit protection

Mounting Type
Threaded (M18), flush mounting

Signal Type
NPN open collector

Product Type
Proximity Sensor

Material
Nickel-plated brass

Input
12 to 24 V DC

Output
NPN NO (Normally Open)

Function
Object detection (non-contact sensing)

Usage
Industrial automation, object detection

Accuracy
High

Resolution
Precise object detection, within sensing distance

Voltage
12-24 VDC

Weight
Approx. 140g

Diameter
M18

Maximum Load Current
200 mA max.

Connection Method
Pre-wired cable (2m)

Vibration Resistance
10 to 55 Hz, amplitude 1.5 mm, in X, Y, Z directions each 2h

Material Detail
Nickel-plated brass housing, PBT (Polybutylene Terephthalate) sensing face

Indicator
Operation indicator (LED)

Storage Temperature
-40C to +85C

Model
E2EM-X16MX1 2M

Shock Resistance
500 m/s2, 3 times each in X, Y, Z directions

Switching Frequency
500 Hz

Residual Voltage
2V (at load current 200mA)

Protection Circuit
Short-circuit and surge protection

Operating Voltage
10 to 30 V DC with ripple (p-p) 10%

Reverse Polarity Protection
Yes

Current Consumption
15mA

About OMRON PROXIMITY SENSOR, E2EM-X16MX1 2M

Access the dominant performance of the OMRON PROXIMITY SENSOR, E2EM-X16MX1 2M, a hot-selling choice acclaimed for its favorable reviews in industrial automation. With robust nickel-plated brass construction and a first-class PBT sensing face, this sensor delivers valorous object detection accuracy within a 16mm range. Advanced protection circuits, high IP67 rating, and exceptional vibration and shock resistance ensure longevity in demanding environments. Enjoy the confidence of reliable NPN output and precise metal sensing for top-tier machinery automation applications.

Applications and Special Features of OMRON Proximity Sensor

The OMRON PROXIMITY SENSOR, E2EM-X16MX1 2M, excels in metal sensing and industrial machinery automation. Its flush mounting design and 16mm sensing distance make it suitable for challenging environments including assembly lines and robotics. Featuring high accuracy, quick response under 1ms, and short-circuit protection, it ensures consistent reliability. Widely used for non-contact object detection, its durable construction and operation indicator add extra assurance for factories and automated production systems.

FOB Port, Delivery Timing, and Order Processing for the Sensor

OMRON PROXIMITY SENSOR, E2EM-X16MX1 2M is supplied via renowned FOB ports in China, ensuring streamlined global distribution. With favorable payment terms, order processing is efficient, and outlay is managed for both small and bulk requirements. Delivery times are swift due to robust supply chain operations. The supplier's proactive approach guarantees minimal delays-so customers benefit from quick installation and uninterrupted industrial activity.

FAQ's of OMRON PROXIMITY SENSOR, E2EM-X16MX1 2M:

Q: How does the OMRON E2EM-X16MX1 2M proximity sensor ensure reliable object detection?

A: The sensor utilizes advanced inductive technology to provide high-precision, non-contact detection of ferrous metals within a 16mm range, aided by its robust construction and a fast response time under 1ms.

Q: What protection features are integrated into the OMRON proximity sensor?

A: It is equipped with short-circuit and surge protection, reverse polarity protection, and an IP67 rating, making it resilient against harsh industrial conditions and ensuring consistent performance.

Q: Where is this proximity sensor most commonly applied?

A: It's widely used in industrial automation settings such as assembly lines, robotics, and metal object detection in industrial machinery.

Q: What are the benefits of the pre-wired cable connection on the sensor?

A: The 2-meter pre-wired cable simplifies installation, supports flexible mounting, and enhances operational reliability by reducing wiring errors.

Q: How does order processing and supply work for this sensor when purchasing from China?

A: The product is distributed through reputable FOB ports with prompt order processing and reliable supply chains, ensuring timely global delivery and competitive outlay management.
