OMRON PLC TEMPERATURE SENSOR UNIT,CP1W-TS002

OMRON PLC TEMPERATURE SENSOR UNIT,CP1W-TS002 Specification

Operating Temperature
0°C to 55°C

Power Consumption
Approx. 1.8W

Sensor Type
Thermocouple Input Module

Signal Type
Analog input (converted to digital output via PLC)

Interface
PLC Expansion Unit (direct interface with PLC)

Response Time
250 ms (sampling period)

Wireless
No

Mounting Type
DIN Rail/Direct Panel Mount

Sensitivity
Selectable via PLC program

Cable Length
Depends on thermocouple cable used (not included)

Features
High accuracy, compact design, easy integration with OMRON CP1 Series PLC

Measurement Range
-200°C to +1,300°C (K type), -100°C to +850°C (J type)

IP Rating
IP20

Application
Industrial Automation, Process Control

Product Type
Temperature Sensor Unit for PLC

Material
Plastic/Metal (Module Enclosure)

Input
Thermocouple (K, J type)

Output
Digital (via PLC Communication Link)

Function
Temperature Measurement and Monitoring

Usage
For CP1W Series PLC Systems

Accuracy
±0.3% of FS ±1 digit (K/J input)

Resolution
0.1°C / 1°C (switchable)

Voltage
24V DC (Supplied from PLC base unit)

Weight
Approx. 75g

Hot Swapping
Supported

Calibration
Factory calibrated

Humidity
10% to 90% RH (no condensation)

No. of Input Channels
2 channels

Storage Temperature
-20C to 75C

Input Resistance
1 M or higher (for thermocouple input)

Status Indication
LED Status Indicator (per channel)

Current Consumption
60 mA typ.

Display
None-data monitored via PLC

Isolation
Photocoupler Isolation between input terminals and internal circuits

Compatible PLC Series
OMRON CP1E/CP1L/CP1H

Dimensions
38 mm W 90 mm H 60 mm D

About OMRON PLC TEMPERATURE SENSOR UNIT,CP1W-TS002

Buy the OMRON PLC TEMPERATURE SENSOR UNIT, CP1W-TS002 for impeccable process control and enviable industrial efficiency. This highly recommended thermocouple input module delivers monumental accuracy0.3% FS 1 digitacross a vast temperature range. Designed for seamless integration with CP1E/CP1L/CP1H PLCs, it supports hot swapping, photcoupler isolation, and keeps you informed with LED status per channel. Instant checkout ensures minimal downtime, while robust calibration and sturdy construction provide reliability in the most demanding automation environments. Elevate your process monitoring today!

Versatile Performance in Industrial Automation

The CP1W-TS002 Temperature Sensor Unit offers monumental advantages, blending precise measurement with robust reliability. Suitable for general and specific temperature monitoring, its ideal for process control, industrial automation, and power monitoring. With broad application across OMRON CP1 PLC systems, its enviable accuracy and seamless integration provide industry-leading performance. Fast response, adaptable sensitivity, and flexible mounting make it a versatile choice for factories, laboratories, and energy management settings.

Swift Delivery and Secure Packaging Options

Orders for the OMRON CP1W-TS002 are processed promptly, with swift delivery to meet your timeline. The asking price includes industry-standard packaging to ensure your unit arrives in impeccable condition. Multiple payment terms are available to cater to diverse business needs, and charges are transparent with no hidden fees. We serve all main domestic markets, supporting both traders and wholesalers across China with efficient logistics and support.

FAQs of OMRON PLC TEMPERATURE SENSOR UNIT,CP1W-TS002:

Q: How does the OMRON CP1W-TS002 enhance temperature monitoring in industrial automation?

A: The CP1W-TS002 offers high accuracy and fast response time, enabling precise temperature control across a wide measurement range. Its seamless integration with OMRONs PLC systems ensures real-time data monitoring and easier process management.

Q: What are the supported thermocouple types and temperature ranges for this unit?

A: This sensor unit supports K and J type thermocouples, covering ranges from -200C to +1,300C for K type and -100C to +850C for J type inputs.

Q: Where can the CP1W-TS002 be mounted in an automation setup?

A: You can install this module on a DIN rail or directly on a panel, offering flexibility to fit various system layouts in both new and existing PLC installations.

Q: What is the benefit of factory calibration for this temperature sensor unit?

A: Factory calibration ensures monumental reliability and accuracy out of the box, minimizing setup time and eliminating the need for manual adjustments before use.

Q: How do I view temperature data when there is no direct display on the sensor unit?

A: All temperature data is monitored digitally via the connected PLC interface, allowing users to access and analyze real-time information on their existing PLC system.
