OMRON PROXIMITY SENSOR, E2E2-X5C1

OMRON PROXIMITY SENSOR, E2E2-X5C1 Specification

Measurement Range
5mm sensing distance

Operating Temperature
25C to +70C

Application
Sensing metal objects on conveyors, assembly lines, and machinery

IP Rating
Ro

Cable Length
5m

Signal Type
Discrete (ON/OFF)

Wireless
No

Features
Short barrel design, high resistance to noise, easy installation

Power Consumption
Maximum 15 mA

Mounting Type
Shielded, flush mountable

Sensitivity
High for ferrous metals

Sensor Type
Inductive Proximity Sensor

Interface
2-Wire DC

Response Time
1ms

Product Type
Proximity Sensor

Material
Brass (Nickel-plated)

Input
12 to 24 VDC

Output
NPN Normally Open (NO)

Function
Detects presence of metal objects without contact

Usage
Industrial automation, object detection

Accuracy
High

Voltage
12 to 24 VDC

Weight
Approximately 200g

Shock Resistance
500 m/s2 (approx. 50G)

Thread Size
M18

Operation Indicator
LED

Color
Metallic silver with black cap on sensing surface

Standards Compliance
CE, RoHS

Maximum Load Current
200mA

Switching Frequency
500Hz

Shell Diameter
18mm

Insulation Resistance
50M min (at 500VDC Megger)

Housing Material
Nickel-plated Brass

Ambient Humidity
35% to 95% RH

Operating Pressure
Not applicable (non-contact sensor)

Connection Type
Pre-wired (cable)

Storage Temperature
-40C to +85C

Shape
Cylindrical

Sensing Object
Ferrous Metals

Vibration Resistance
10 to 55 Hz, 1.5mm double amplitude

Protection Circuit
Surge protection, load short-circuit protection

Dielectric Strength
1000VAC 50/60Hz for 1 min

Leakage Current
0.8mA max

About OMRON PROXIMITY SENSOR, E2E2-X5C1

Unlock exceptional value with the OMRON PROXIMITY SENSOR, E2E2-X5C1where unbeatable price meets grand industrial performance. Featuring advanced surge and short-circuit protection, this sensor is the perfect solution for precise, non-contact detection of ferrous metals. Its cylindrical, nickel-plated brass housing offers robust durability, while the high switching frequency of 500Hz ensures rapid response. Benefit from a bargain advance purchase and enjoy a seamless installation with 5m pre-wired cable, reliable LED indicator, and high vibration/shock resistance. CE and RoHS compliance guarantee quality for industrial automation.

Advantage and Uses of OMRON PROXIMITY SENSOR, E2E2-X5C1

The E2E2-X5C1 proximity sensor provides an exceptional advantage in industrial automation, ensuring high accuracy for detecting metal objects on conveyors, assembly lines, and machinery. Ideal for general and specific usage alike, this sensor is widely utilized by manufacturers, engineers, and automation specialists. Robust and reliable, it streamlines detection processes, significantly enhancing productivity and operational precision in diverse industry environments.

Packaging, Supply Ability, and Delivery Details

Experience premium shipment services with the OMRON PROXIMITY SENSOR, E2E2-X5C1, meticulously packaged for maximum safety. Our strong supply network ensures consistent availability, facilitated by trusted suppliers, traders, and wholesalers in China. Rapid delivery times are prioritized to promptly meet your automation demands, reinforcing our commitment to premium service and seamless supply of essential industrial sensors.

FAQs of OMRON PROXIMITY SENSOR, E2E2-X5C1:

Q: How does the OMRON E2E2-X5C1 proximity sensor detect metal objects?

A: The E2E2-X5C1 uses inductive sensing technology to detect the presence of ferrous metals without physical contact, making it ideal for automated industrial applications.

Q: What are the primary benefits of advance purchasing the OMRON E2E2-X5C1 sensor?

A: Advance purchase guarantees access to unbeatable prices and ensures prompt availability during critical project phases, reducing production delays.

Q: Where can the E2E2-X5C1 sensor be used most effectively?

A: This proximity sensor is especially effective in industrial environments such as conveyor systems, assembly lines, and machinery where metal object detection is needed.

Q: What is the process for installing the E2E2-X5C1 sensor?

A: Installation is straightforward; Secure the cylindrical, shielded sensor in place, connect the pre-wired cable, and confirm power and indicator functions before commencing operation.

Q: When should the sensor be replaced or maintained for optimum performance?

A: Maintenance or replacement is recommended when sensing accuracy declines, or if the sensor experiences consistent exposure to extreme vibration or harsh operating conditions.
