AUTONICS, PROXIMITY SENSOR PRD12-8DP

AUTONICS, PROXIMITY SENSOR PRD12-8DP Specification

Interface
3-wire DC

Response Time
2ms

Power Consumption
15mA

Features
Short-circuit protection, reverse polarity protection, LED indicator

Application
Object presence detection, position sensing

Sensitivity
Factory set, not user adjustable

Operating Temperature
-25C to +70C

IP Rating
IP67

Mounting Type
Flush/Embeddable

Measurement Range
Detection Distance 8mm 10%

Cable Length
2 meters

Wireless
No

Sensor Type
Inductive Proximity Sensor

Signal Type
Discrete/On-Off

Product Type
Proximity Sensor

Material
Nickel-plated brass

Input
DC 12-24V

Output
PNP Normally Open (NO)

Function
Detection of metal objects without physical contact

Usage
Industrial automation and control

Accuracy
High (typical for inductive sensors)

Voltage
12-24V DC

Weight
Approx. 41g

Target Material
Ferrous metals

Connection Type
PVC cable

Residual Voltage
2V

Housing Diameter
M12

Shock Resistance
500m/s2 (approx. 50G)

EMC
IEC 60947-5-2 compliance

Storage Temperature
-30C to +80C

LED Indicator
Yes (operation status)

Vibration Resistance
10 to 55Hz, double amplitude 1.5mm

Switching Frequency
1kHz

Dielectric Strength
1000VAC 50/60Hz for 1 minute

Cable Specification
3-wire, 4mm, 2m length

Hysteresis
10% of sensing distance

About AUTONICS, PROXIMITY SENSOR PRD12-8DP

Get It Now the EXCLUSIVE AUTONICS PROXIMITY SENSOR PRD12-8DP, engineered for those seeking FIRST-CLASS, reliable, and MATCHLESS performance in industrial automation. Designed with a grand M12 housing and a robust nickel-plated brass body, this sensor assures durability and precision. Enjoy competitive pricing without compromising on quality. The 8mm detection distance, high-speed 1kHz switching frequency, and LED operation status indicator provide unmatched confidence in object detection. Featuring IP67 protection, short-circuit and reverse polarity safeguards, and seamless PNP NO output, its the preferred choice for demanding applications. Secure yours today!

Features, Competitive Advantages, and Versatile Uses

AUTONICS PRD12-8DP proximity sensor boasts a robust nickel-plated brass housing, factory-set high sensitivity, and reliable LED operation indication. Engineered for ferrous metal detection, it excels with a discrete on-off signal and fast response time. Enjoy competitive advantages with EMC compliance, IP67 rating, and advanced protection features. Widely used in object presence detection and position sensing, this grand sensor is built for industrial automation and control, offering unmatched accuracy and long-term performance in varied environments.

Export Markets, Supply Ability, and Packing & Dispatch

Serving a broad export footprint, AUTONICS PRD12-8DP is supplied across international markets, including Asia, Europe, and Africa. Packing & Dispatch is streamlined for prompt drop-off, supported by efficient transport services and global logistics partners. Bulk supply ability meets diverse client demands, while competitive payment termswhether advance or scheduledfurther ease procurement. Each unit is carefully packaged to ensure safe arrival, reflecting our commitment to professional service and consistent worldwide delivery.

FAQs of AUTONICS, PROXIMITY SENSOR PRD12-8DP:

Q: How does the AUTONICS PRD12-8DP proximity sensor detect objects?

A: The sensor uses inductive technology to detect ferrous metal objects without physical contact. It generates an electromagnetic field and senses disturbances caused by metallic targets within its 8mm range.

Q: What are the main benefits of using this proximity sensor in industrial automation?

A: Key benefits include highly accurate object detection, fast response time (2ms), durable construction with IP67 rating, EMC compliance, and reliable operation indicated via a built-in LED, making it ideal for harsh environments.

Q: Where can the AUTONICS PRD12-8DP proximity sensor be installed?

A: This sensor is designed for flush or embeddable mounting in industrial machinery and automation systems, suitable for applications such as object presence detection and position sensing in manufacturing lines.

Q: What features ensure safe and stable operation of this sensor?

A: Short-circuit protection, reverse polarity protection, and strong dielectric strength assure safe, stable operation. The IP67 rating provides resistance to dust and water, enhancing reliability.

Q: When is it recommended to use a sensor with factory-set sensitivity?

A: Use this sensor when you need consistent, maintenance-free performance. The non-adjustable, factory-set sensitivity is optimal for standard metal detection tasks and reduces setup errors in industrial automation scenarios.
