OMRON PROXIMITY SENSOR,E2E-X2ME1

OMRON PROXIMITY SENSOR,E2E-X2ME1 Specification

Signal Type
Digital

Mounting Type
Flush/Embedded Mounting

Features
Short-circuit Protection, Reverse Polarity Protection

Cable Length
2m Pre-wired Cable

Sensitivity
Adjustable

Power Consumption
15mA

Response Time
1 ms

Application
Detecting Metallic Objects

Wireless
No

Measurement Range
2mm Sensing Distance

Interface
Wire

IP Rating
IP67

Sensor Type
Inductive Proximity Sensor

Operating Temperature
-25C to +70C

Product Type
Proximity Sensor

Material
Nickel-plated Brass Housing

Input
3-Wire DC

Output
NPN Normally Open

Function
Sensing Ferrous Metal Objects

Usage
Industrial Automation, Position Sensing

Accuracy
High Accuracy

Resolution
Standard

Voltage
12-24V DC

Weight
Approx. 30g

Ripple Voltage
10% of Rated Voltage

Protection Circuits
Surge absorber, Load short-circuit protection

Repeat Accuracy
0.01 mm

Max Load Current
200mA max.

Insulation Resistance
50 M minimum (at 500 VDC)

Material Sensing Face
Polybutylene Terephthalate (PBT)

Connection Type
Cable Type (PVC)

Storage Temperature
-40C to +85C

LED Indicator
Operation Indicator (Yellow)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Dielectric Strength
1000 V AC 50/60 Hz for 1 min

Thread Size
M121

Case Length
40 mm

Shock Resistance
500 m/s2 (Approx. 50G), 3 times each in X, Y, Z axes

Operating Frequency
1 kHz

Housing Diameter
12 mm

About OMRON PROXIMITY SENSOR,E2E-X2ME1

Unlock astounding reliability with the OMRON PROXIMITY SENSOR, E2E-X2ME1. Benefit from an outstanding discount when you purchase or reserve bulk orders through our leading supply channels in China. With impeccable repeat accuracy of 0.01 mm and robust protection circuits, this sensor is tailored for industrial automation, delivering high accuracy for detecting ferrous metal objects. The device boasts a durable nickel-plated brass housing, PBT sensing face, and IP67 protection, ensuring flawless performance even in demanding environments. Reserve yours today and experience unmatched value with every purchase.

Engineered for Precision and Durability

The OMRON PROXIMITY SENSOR, E2E-X2ME1, is perfectly suited for industrial automation and precise position sensing applications. Its primary competitive advantages include impeccable repeat accuracy, robust protection circuits such as surge absorber and short-circuit protection, and an astounding IP67-rated housing. Easy flush or embedded mounting, outstanding build with nickel-plated brass, and sensitivity adjustment ensure reliable long-term use. Users in automation and process control industries greatly benefit from its digital NPN output and high mechanical endurance.

Optimal Domestic Distribution and Supply Services

Our supply ability ensures that the OMRON PROXIMITY SENSOR, E2E-X2ME1, is readily available for rapid domestic delivery. Goods transport is streamlined, ensuring swift handover and minimal downtime. Purchase at the lowest price with flexible payment terms, ideal for wholesalers, traders, and industrial suppliers within the region. Comprehensive after-sales support and a robust logistics network guarantee hassle-free transactions, making us the preferred supplier for this impeccable sensor.

FAQ's of OMRON PROXIMITY SENSOR,E2E-X2ME1:

Q: How can I purchase or reserve the OMRON PROXIMITY SENSOR, E2E-X2ME1 at a discount?

A: You may purchase or reserve the E2E-X2ME1 directly through our official channels as a supplier, trader, or wholesaler. Bulk orders often come with special discounts and promotional offers to help you save on each unit.

Q: What industries can benefit most from using this sensor?

A: The OMRON PROXIMITY SENSOR, E2E-X2ME1, is ideal for industrial automation, manufacturing, and metal detection applications, where high precision and robust performance are required.

Q: Where can I install the E2E-X2ME1 sensor?

A: This sensor is designed for flush or embedded mounting in machinery and automation systems, suitable for use in harsh industrial environments thanks to its IP67-rated protection and resistance to vibrations and shocks.

Q: What makes the E2E-X2ME1 sensor outstanding compared to competitors?

A: Its outstanding repeat accuracy, robust protection features, and reliable operation in extreme environments set it apart from competitors. The combination of durable materials and advanced circuitry ensures dependable long-term use.

Q: How does the handover process and goods transport work for domestic orders?

A: Once you confirm your order, goods are promptly transported using trusted logistics partners. Efficient handover is ensured to minimize downtime and keep your operations running smoothly.
