OMRON PROXIMITY SENSOR, E6C3-AG5C

OMRON PROXIMITY SENSOR, E6C3-AG5C Specification

Interface
Cable (Wired)

Operating Temperature
-10C to +70C

Cable Length
2 meters (standard)

Sensor Type
Incremental Rotary Encoder

Sensitivity
High Sensitivity to Rotational Movements

IP Rating
IP64

Application
Position and Speed Measurement

Signal Type
A, B, Z Phases (Quadrature Output)

Features
Compact Design, Robust Build, High Accuracy

Wireless
No

Mounting Type
Shaft Mount with Clamping Method

Power Consumption
Max. 70mA

Measurement Range
0-360 (Rotary Position)

Response Time
< 1ms

Product Type
Rotary Encoder (Proximity Sensor)

Material
Metal Housing with Plastic Components

Input
12-24V DC

Output
NPN Open Collector

Function
Rotational Position Detection

Usage
Industrial Automation, Machinery

Accuracy
0.5

Resolution
360 P/R (Pulses per Revolution)

Voltage
12-24V DC 10%

Weight
Approx. 200g

Ambient Humidity
35% to 85% RH (non-condensing)

Allowable Radial Load
20N

Permissible Vibration
10 to 55 Hz, Double Amplitude 1.5 mm

Bearings
Ball Bearings

Output Voltage Drop
Max. 0.4V at 40mA

Cable Type
Shielded multi-core cable

Control Output Capacity
Max. 30VDC, 40mA

Allowable Thrust Load
10N

Permissible Shock
500 m/s2, 3 times each in X, Y, Z directions

Shaft Diameter
6mm

Protection Circuitry
Reverse polarity, Output short-circuit protection

Maximum Rotational Speed
6000 rpm

About OMRON PROXIMITY SENSOR, E6C3-AG5C

Experience the acclaimed performance of the OMRON PROXIMITY SENSOR, E6C3-AG5C-your masterful solution for precise rotational position detection in industrial automation and machinery. This sensor features a lustrous, robust metal housing with plastic components and ball bearings, ensuring stability at shaft speeds up to 6000 rpm. With high sensitivity, perfect 0.5 accuracy, and a compact, IP64-rated design, it's built for demanding environments. Get it now from a top Japan-based supplier, wholesaler, and trader, all at the best price for uncompromising reliability and precision.

Superior Material & Features for Industrial Automation

The OMRON PROXIMITY SENSOR, E6C3-AG5C is expertly crafted for position and speed measurement in advanced machinery. Its robust metal housing and precision ball bearings deliver lasting durability even at high rotational speeds. Special features include a high-resolution 360 P/R output, shielded multi-core cable, and comprehensive protection circuitry. The sensor's IP64 rating, combined with a shaft mount clamping method and 2-meter cable, ensures seamless integration in diverse automation environments.

Packing, Dispatch & Export Markets-Efficiency Beyond Borders

Packing & Dispatch processes for the OMRON PROXIMITY SENSOR, E6C3-AG5C maintain product integrity throughout shipments. Standard packaging is secure and designed for safe transit to FOB ports in Japan. With a strong supply ability and competitive rate, we cater to main export markets across Asia, Europe, and beyond. Each order is processed efficiently, ensuring timely delivery and superior quality with every dispatch.

FAQ's of OMRON PROXIMITY SENSOR, E6C3-AG5C:

Q: How does the OMRON E6C3-AG5C proximity sensor enhance industrial automation?

A: The E6C3-AG5C leverages high accuracy, 360 pulses per revolution, and robust build quality to deliver precise position and speed measurements, optimizing performance in complex automation systems.

Q: What special protective features does this sensor offer during operation?

A: This sensor includes reverse polarity and output short-circuit protection, IP64 ingress protection, and a rugged metal housing, ensuring reliability and safety in demanding environments.

Q: Where can the OMRON E6C3-AG5C be installed and used?

A: Designed for versatile use, it mounts easily on rotational shafts in industrial machinery or automation settings that demand accurate rotary position and speed feedback.

Q: What is the process for signal output and monitoring?

A: The sensor provides A, B, Z phase quadrature outputs via a shielded multi-core cable, allowing for quick, reliable data transmission to control circuitry with under 1ms response time.

Q: When should this sensor be chosen over others for position measurement?

A: Choose the E6C3-AG5C when high-resolution, fast response, compact design, and resilience to mechanical stress are critical for your automation tasks.
