OMRON PROXIMITY SENSOR ,E2E-X2D1-M3G, E2E-X2D1-M1GJ ,E2E-X2D1R-M1TG-U, E2E-X2D1-M1, E2E-X2D1-M1G E2E-X2D1-M1GJ E2E-X2D1-M1TG E2E-X2D2-M1GJ-1M E2E-X2D2-M1TGJ-U, E2E-X2D2-M3+A19, E2E-X2D1-N, E2E-X2D1-N, E2E-X2D1-N E2E-X2D1-M1,

OMRON PROXIMITY SENSOR ,E2E-X2D1-M3G, E2E-X2D1-M1GJ ,E2E-X2D1R-M1TG-U, E2E-X2D1-M1, E2E-X2D1-M1G E2E-X2D1-M1GJ E2E-X2D1-M1TG E2E-X2D2-M1GJ-1M E2E-X2D2-M1TGJ-U, E2E-X2D2-M3+A19, E2E-X2D1-N, E2E-X2D1-N, E2E-X2D1-N E2E-X2D1-M1, Specification

Sensitivity
Factory-set

Cable Length
2 m (standard models), 1 m (designated by -1M), M12 connector type variations

Wireless
No

Features
Short-body, high resistance to noise, reverse polarity protection, surge protection

Response Time
<1 ms

Sensor Type
Cylindrical Inductive Proximity Sensor

Measurement Range
Detecting distance: 2 mm (flush mounting), 2.5 mm (non-flush)

IP Rating
IP67

Mounting Type
M12 threaded (flush/non-flush)

Application
Object/machine part position detection in control systems

Interface
3-wire or 2-wire DC, M12 connector optional

Operating Temperature
-25C to +70C

Signal Type
Digital (NO/NC depending on model)

Power Consumption
12 mA (at 24 V DC, typical)

Product Type
Proximity Sensor (Inductive)

Material
Nickel-plated brass housing, Polyamide sensing face

Input
DC (3-wire/2-wire)

Output
NPN or PNP open collector

Function
Non-contact object detection

Usage
Industrial automation, position sensing

Accuracy
10% of sensing distance

Resolution
Continuous (analog) or standard (digital switching)

Voltage
12 to 24 V DC

Weight
Approx. 25 g to 50 g (varies by model)

Switching Frequency
1 kHz (typical)

Connection Type
Pre-wired/Cable or Connector Type (M12)

Enclosure Material
Brass (Nickel-plated), Plastic (on connector type)

Series
E2E-X2D1, E2E-X2D2 Variants

Storage Temperature
-40C to +85C

Operation Mode
Normally Open (NO) / Normally Closed (NC) Selectable

Insulation Resistance
50 M min. (at 500 V DC)

Typical Targets
Iron, Steel, Ferrous Metals

Maximum Load Current
200 mA max.

Shock Resistance
500 m/s2, 3 times in 6 directions

Indicator
Built-in Operation LED

Protection Circuit
Load short-circuit and surge absorber

Case Diameter
12 mm (M12)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Installation
Flush or non-flush in metal as specified per model

About OMRON PROXIMITY SENSOR ,E2E-X2D1-M3G, E2E-X2D1-M1GJ ,E2E-X2D1R-M1TG-U, E2E-X2D1-M1, E2E-X2D1-M1G E2E-X2D1-M1GJ E2E-X2D1-M1TG E2E-X2D2-M1GJ-1M E2E-X2D2-M1TGJ-U, E2E-X2D2-M3+A19, E2E-X2D1-N, E2E-X2D1-N, E2E-X2D1-N E2E-X2D1-M1,

Experience a virtuoso of performance and unbeatable reliability with the OMRON PROXIMITY SENSOR seriesfeaturing models like E2E-X2D1-M3G and E2E-X2D2-M1TGJ-U. These cylindrical inductive sensors offer glorious industrial automation solutions at an unassailable deal and best price. Designed for robust object detection in factory settings, each sensor flaunts a durable nickel-plated brass housing, high sensitivity, and unwavering stabilityeven in harsh environments. Benefit from IP67 protection, selectable NO/NC operation, and advanced short-circuit and surge protection. Reliable, precise, and competitively priced for discerning professionals seeking excellence.

Application & Industry Usage

The OMRON PROXIMITY SENSOR series, including models such as E2E-X2D1-M1GJ and E2E-X2D2-M3+A19, is extensively used for non-contact position detection in industrial automation. Employed by manufacturers, assembly lines, and machine builders, these sensors provide feedback in control systems and are vital for detecting iron, steel, or other ferrous components during production. Perfect for installation across automotive, packaging, and material handling sites, they enhance operational efficiency and process reliability.

Export, Samples, and Payment Terms

Obtain premium solutions for your automation needs with the OMRON PROXIMITY SENSOR range, celebrated across major export markets. Samples are available upon request to ensure your expenditure aligns perfectly with expectations. For bulk requirements, please request a tailored quotation. Flexible payment terms are provided to support seamless procurement processes, ensuring a straightforward, professional transaction for enterprises prioritizing quality and cost-effectiveness.

FAQs of OMRON PROXIMITY SENSOR ,E2E-X2D1-M3G, E2E-X2D1-M1GJ ,E2E-X2D1R-M1TG-U, E2E-X2D1-M1, E2E-X2D1-M1G E2E-X2D1-M1GJ E2E-X2D1-M1TG E2E-X2D2-M1GJ-1M E2E-X2D2-M1TGJ-U, E2E-X2D2-M3+A19, E2E-X2D1-N, E2E-X2D1-N, E2E-X2D1-N E2E-X2D1-M1,:

Q: How do I select the right OMRON PROXIMITY SENSOR model for my application?

A: Selecting the appropriate sensor depends on the target material, mounting requirements (flush or non-flush), switching mode, connector type, and the desired sensing distance. Review your applications specifications and match them with the sensors features for optimum results.

Q: What are the primary benefits of using an OMRON PROXIMITY SENSOR in industrial automation?

A: OMRON PROXIMITY SENSORS offer accurate, non-contact detection of metallic objects, reducing mechanical wear and minimizing maintenance. Their robust design ensures long-lasting, reliable operation even in demanding industrial environments.

Q: Where are these sensors typically installed?

A: These sensors are commonly installed in automated manufacturing lines, machinery for object or position detection, conveyor systems, and control panels across automotive, packaging, and electronics industries.

Q: When should I consider using a flush vs. non-flush mounting configuration?

A: Flush mounting is ideal for applications that require minimal protrusion and reduced risk of physical damage, while non-flush mounting offers superior sensing distance where installation space allows.

Q: How can I obtain a sample or request a quotation for bulk orders?

A: You may contact the supplier or authorized distributor directly to request product samples and receive a premium, customized quotation tailored to your order size and specific requirements.

Q: What is the process for integrating these sensors into an existing control system?

A: Integration involves connecting the sensors wiring or M12 connector to your control unit, configuring the NO/NC output per your needs, and confirming stable detection through the built-in LED indicator. Detailed instructions are included with each model.
