AUTONICS, FIBER OPTIC SENSOR, BF5R-S1-P

AUTONICS, FIBER OPTIC SENSOR, BF5R-S1-P Specification

Sensitivity
Adjustable (Potentiometer/Teach-key)

Power Consumption
Max. 960 mW (40 mA at 24 VDC)

Mounting Type
DIN rail or direct panel mount

Signal Type
Digital

Sensor Type
Photoelectric

Interface
Pre-wired cable

Cable Length
2 m (pre-wired)

Wireless
No

Features
Compact design, high-speed response, selectable NPN/PNP output, LED status indicator

Response Time
0.5 ms or less

Measurement Range
Depends on fiber cable used (typically up to several meters)

Operating Temperature
-10C to +55C (No freezing)

Application
Industrial automation, Robotics, Electronics assembly, Packaging

IP Rating
IP40

Product Type
Fiber Optic Sensor

Material
Plastic (housing), Metal (mounting parts)

Input
NPN/PNP selectable, Light ON/Dark ON selectable

Output
NPN/PNP Open collector

Function
Detection of small or distant objects using fiber optic cables

Usage
Object detection, position detection, counting, presence sensing

Accuracy
High

Resolution
Micron-level (dependent on fiber unit used)

Voltage
12-24 VDC 10%

Weight
Approx. 26 g

Enclosure Material
Polycarbonate

Ambient Humidity
35% to 85% RH

Display
Operation indicator (Red LED), Stability indicator (Green LED), Sensitivity adjuster

Shock Resistance
500 m/s2 (approx. 50G)

Light Source
Red LED (660 nm)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Fiber Unit Compatibility
Compatible with Autonics standard fiber optic cables

Control Output Capacity
Max. 30 VDC, 100 mA

About AUTONICS, FIBER OPTIC SENSOR, BF5R-S1-P

Try Now the popular AUTONICS FIBER OPTIC SENSOR BF5R-S1-P, a spotlight in industrial automation. This praiseworthy sensor features a superlative red LED (660 nm) light source, with lofty accuracy and micron-level resolution. Designed for versatility, it detects small or distant objects in challenging environments. Its compact build includes selectable NPN/PNP output, adjustable sensitivity, and status indicators. Compatible with standard fiber optic cables, it endures vibrations, shocks, and humidity, making it an exceptional choice for robotics, electronics, and packaging. Experience elevated precision with this top-tier solution.

Versatile Applications & Cutting-Edge Features

The AUTONICS BF5R-S1-P Fiber Optic Sensor thrives in demanding surface detection environments. Praiseworthy for its high sensitivity and durable construction, it excels in industrial automation, robotics, electronics assembly, and packaging applications. Its compact design, high-speed response, LED indicators, and adjustable sensitivity enable effortless object detection, position sensing, counting, and presence sensing. Suitably mounted via DIN rail or directly, this sensor seamlessly adapts to both intricate production lines and standalone setups, highlighting its superlative feature set.

Export Markets, Payment Flexibility & Delivery Terms

AUTONICS BF5R-S1-P enjoys significant demand in international markets, especially from China as a leading supplier, trader, and wholesaler. The standard charge and payment terms are typically through secure channels, ensuring reliable transactions and minimal expenditure for buyers. Products are usually shipped via FOB port arrangements, streamlining exchange processes. Serving diverse export markets, this sensor guarantees quality and efficiency in every transaction, making it a sound investment for enterprises seeking robust, cost-effective automation equipment.

FAQ's of AUTONICS, FIBER OPTIC SENSOR, BF5R-S1-P:

Q: How does the AUTONICS BF5R-S1-P Fiber Optic Sensor enhance industrial automation?

A: The sensor's micron-level precision, fast 0.5 ms response, and compatibility with standard fiber optic cables make it ideal for high-accuracy object, position, and presence detection within automated production lines, robotics, and electronics assembly.

Q: What types of applications are suitable for the BF5R-S1-P sensor?

A: It is perfect for object detection, counting, position detection, and presence sensing in industries such as packaging, robotics, electronics manufacturing, and general automation environments.

Q: Where can the AUTONICS BF5R-S1-P be installed?

A: The sensor offers flexible installation as it supports both DIN rail mounting and direct panel mounting, making it adaptable for a variety of industrial and automation settings.

Q: When should the sensitivity or output mode be adjusted?

A: Sensitivity and output mode (NPN/PNP, Light ON/Dark ON) should be adjusted during setup or when process requirements change, ensuring optimal detection accuracy for different target objects or environmental conditions.

Q: What are the main export and payment terms for purchasing this sensor?

A: Buyers can arrange payment via secure standard terms, with products typically shipped using FOB port. This approach helps manage expenditures efficiently, with an easy exchange or transaction process for international markets.

Q: How does the status indicator benefit users during operation?

A: The dual-color LED indicators provide real-time feedback regarding sensor operation and stability, minimizing troubleshooting time and maximizing operational uptime for users.
