OMRON PROXIMITY SENSOR,E2B-M18KN16-WP-C1

OMRON PROXIMITY SENSOR,E2B-M18KN16-WP-C1 Specification

IP Rating
IP67

Application
Metal Detection, Position Sensing

Mounting Thread
M18

Interface
3-wire DC

Response Time
< 1 ms

Cable Length
2 m

Mounting Type
Flush Mount / Embeddable

Ingress Protection
IP67

Measurement Range
16 mm Sensing Distance

Sensitivity
Detects ferrous metals

Wireless
No

Housing Material
Nickel-plated brass

Signal Type
Digital

Features
Short-circuit and reverse polarity protection

Sensor Type
Inductive Proximity

Power Consumption
<= 15 mA

Operating Temperature
-25C to +70C

Product Type
Proximity Sensor

Material
Metal Body

Input
DC

Output
PNP Normally Open (NO)

Function
Detection of Metallic Objects

Usage
Industrial Automation

Accuracy
High

Resolution
Discrete (On/Off)

Voltage
10-30 V DC

Weight
Approx. 90 g

Tightening Torque
60 Nm max

Supply Current
<= 15 mA (no load)

Switching Frequency
Up to 300 Hz

Ambient Humidity
35-95% RH

Shock Resistance
IEC 60068-2-27, 30g, 11 ms

Vibration Resistance
IEC 60068-2-6, 10-55 Hz, 1.5 mm double amplitude

Shell Thread Length
50 mm

Connection Method
Pre-wired cable (PVC)

Protection Circuit
Reverse polarity and surge protection

Indication
LED Status Indicator

About OMRON PROXIMITY SENSOR,E2B-M18KN16-WP-C1

The OMRON PROXIMITY SENSOR, E2B-M18KN16-WP-C1, is a cost-effective solution for reliable metal detection in industrial automation. Featuring a formidable nickel-plated brass body and pristine construction, this inductive proximity sensor offers superior accuracy and a robust sensing capacity up to 16 mm. With an impressive switching frequency of up to 300 Hz and IP67 ingress protection, it stands resilient in harsh environments. The pre-wired cable ensures efficient installation while advanced protection circuits deliver heightened durability. Take advantage of exclusive price cuts and redeem top quality at remarkable value from trusted suppliers in China.

Versatile Industrial Applications

The OMRON PROXIMITY SENSOR, E2B-M18KN16-WP-C1, is expertly crafted for usage in industrial automation settings. Its primary use is the precise detection and position sensing of metallic objects using its superior inductive technology. This sensor is ideal for operations requiring dependable discrete (On/Off) responses, making it suitable for use across assembly lines, packaging facilities, and manufacturing plants where accurate metal object detection is essential.

Main Export Destinations and Supply Certainty

This advanced sensor is regularly shipped to key markets worldwide and supported by reputable certifications. Stock is ready for immediate dispatch, ensuring quick goods transport and delivery. Reliable sample policies make it easier for bulk buyers to evaluate quality before large-scale orders. Accredited suppliers and wholesalers in China maintain a robust inventory, guaranteeing a smooth procurement process for global buyers requiring timely and certified electronic components.

FAQ's of OMRON PROXIMITY SENSOR,E2B-M18KN16-WP-C1:

Q: How does the OMRON E2B-M18KN16-WP-C1 detect metallic objects?

A: The sensor utilizes inductive proximity technology to sense the presence of ferrous metals within its 16 mm range, providing discrete On/Off digital signals for automation processes.

Q: What is the main benefit of using this proximity sensor in industrial automation?

A: It offers superior detection accuracy and high reliability, ensuring consistent position sensing and metal detection in challenging industrial environments.

Q: When can I expect shipped goods after placing an order for this sensor?

A: Stock is ready with trusted suppliers, allowing for prompt goods transport and swift export to main international markets following order confirmation.

Q: Where is the OMRON E2B-M18KN16-WP-C1 commonly used?

A: The sensor is widely used in assembly lines, packaging machinery, metal fabrication, and manufacturing plants for metallic object detection and position sensing tasks.

Q: What certifications and protections does the sensor have?

A: It complies with IEC standards for shock and vibration resistance and features advanced protection circuits such as short-circuit, reverse polarity, and surge protection for enhanced operational safety.

Q: How does the supply process ensure product authenticity and quality?

A: Suppliers in China adhere to strict quality control and certification policies, with the option for buyers to request samples before larger purchases, ensuring only superior goods are provided.
