OMRON PROXIMITY SENSOR 12 TO 24VDC, E2E-X7D1-U 2M

OMRON PROXIMITY SENSOR 12 TO 24VDC, E2E-X7D1-U 2M Specification

Mounting Thread
M18

Measurement Range
7 mm sensing distance (nominal)

Signal Type
DC, 3-wire

Interface
Cable (hardwired)

Mounting Type
Flush/Embedded

Cable Length
2 meters

Sensitivity
Detects ferrous metals

Sensor Type
Inductive Proximity Sensor

Housing Material
Stainless Steel

Operating Temperature
-25C to +70C (no freezing or condensation)

Ingress Protection
IP67

Application
Industrial automation, machinery, object detection

Wireless
No

Features
High reliability, durable housing, short-circuit protection

Response Time
1 ms

IP Rating
IP67

Spectral Range
Not applicable (Inductive type)

Power Consumption
Max. 15 mA (typical)

Product Type
Proximity Sensor

Material
Stainless Steel

Input
12 to 24 VDC

Output
PNP/NPN (check specific variant); 3-wire

Function
NO (Normally Open) Inductive Proximity Sensing

Usage
Position and Presence Detection

Accuracy
High precision switching capability

Voltage
12 to 24 VDC

Weight
Approx. 110g including 2m cable

Connector Type
Pre-wired (2m cable, no separate connector)

Protection Circuits
Reverse polarity, surge suppressor

Maximum Load Current
200 mA (typically, check datasheet for exact figure)

Switching Frequency
500 Hz (typical for 7mm model)

Detection Object
Ferrous metals best; may detect non-ferrous at reduced range

Storage Temperature
-40C to +85C

Model
E2E-X7D1-U

Cable Material
PVC, oil-resistant type

Indicator
Red LED (Operation Indicator)

Approvals/Certifications
CE, UKCA, RoHS compliant

Dropout Voltage
3V at full load

About OMRON PROXIMITY SENSOR 12 TO 24VDC, E2E-X7D1-U 2M

Jump on this hot deal and grab the remarkable OMRON PROXIMITY SENSOR 12 TO 24VDC, model E2E-X7D1-U 2M-a virtuoso performer engineered for industrial automation and machinery. With a superior stainless steel housing and oil-resistant PVC cable, it delivers high precision with a nominal 7mm sensing distance, ideal for ferrous metals. Boasting CE, UKCA, and RoHS compliance, this sensor ensures reliable object detection, reverse polarity and surge protection, plus IP67 ingress protection. Experience supreme durability, steadfast performance, and first-rate safety features in one remarkable package.

Versatile Applications and Precise Usage

The OMRON PROXIMITY SENSOR 12 TO 24VDC, E2E-X7D1-U is perfect for application in industrial automation environments. It excels in position and presence detection for machinery, conveyors, and object counting systems. This general-purpose, high-accuracy sensor is widely used in manufacturing plants, assembly lines, and quality control setups, where reliable and accurate metal detection is crucial. Its flush mounting capability and high precision make it suitable for both specialized and standard industrial usage.

Sample Availability, Packaging, and Certifications Details

Evaluate this product prudently with available samples, helping you determine its suitability for your setup before any expenditure or charge. Each sensor is carefully packaged to safeguard its integrity during transport. With top-tier certifications like CE, UKCA, and RoHS, you are assured a product of superior valuation-fully meeting international safety and environmental standards, which is integral to compliance for exporters, suppliers, traders, and wholesalers alike.

FAQ's of OMRON PROXIMITY SENSOR 12 TO 24VDC, E2E-X7D1-U 2M:

Q: How does the OMRON E2E-X7D1-U proximity sensor contribute to industrial automation?

A: The OMRON E2E-X7D1-U proximity sensor enhances industrial automation by accurately detecting ferrous metals, supporting flawless position and presence sensing in machinery and assembly lines, ultimately improving process reliability and operational efficiency.

Q: What certifications does the E2E-X7D1-U sensor carry, and why are they important?

A: This sensor is CE, UKCA, and RoHS compliant, ensuring it meets stringent safety, quality, and environmental standards, which is critical for international trade, regulatory acceptance, and user safety.

Q: When should I use this inductive proximity sensor in my application?

A: Use the E2E-X7D1-U sensor when you need reliable, precise detection of metallic objects within a 7mm range, especially in industrial automation, machinery, conveyors, and where oil resistance or rugged durability are required.

Q: Where is the best place to install the OMRON E2E-X7D1-U proximity sensor?

A: The sensor is best installed in flush or embedded mounting positions on equipment frames, conveyor sides, or automation equipment, areas where accurate monitoring of metal object presence or position is necessary.

Q: What is the process for connecting and operating this sensor?

A: Simply mount the sensor using the M18 threaded section, connect the hardwired 2-meter cable to your control system's DC input (12-24V), and ensure proper electrical connections per the wiring diagram for optimal sensing and operation.
