OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-M1-B1

OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-M1-B1 Specification

Housing Material
Nickel-plated brass

Features
Short body, robust housing, easy installation

Wireless
No

Ingress Protection
IP67

Sensitivity
Standard for M18 inductive proximity sensors

Operating Temperature
-25 to 70C

Response Time
< 2ms

Mounting Thread
M18

Interface
M12 connector, 4-pin

IP Rating
IP67

Signal Type
Discrete (on/off)

Measurement Range
Sensing distance: 8mm

Sensor Type
Inductive Proximity Sensor

Mounting Type
Flush mount

Application
Position sensing, limit switching, motion detection

Power Consumption
10mA (no load)

Cable Length
Connector type, no cable

Product Type
Proximity Sensor

Material
Metal

Input
10 to 30VDC

Output
PNP, Normally Open (NO)

Function
Sensing (Proximity Detection)

Usage
Non-contact object detection, industrial automation

Accuracy
Standard for industrial proximity sensors

Voltage
10 to 30VDC

Weight
Approx. 40g

Reverse Polarity Protection
Yes

Output Current
Max. 200mA

Connection Type
M12 quick connector

Switching Frequency
Up to 800Hz

Short Circuit Protection
Yes

Series
E2B

About OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-M1-B1

Get kingly performance and top-class reliability with the OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-M1-B1. This inductive proximity sensor is the paragon of cost-effective automation solutions, engineered for optimum efficiency in position sensing, limit switching, and motion detection. With a robust IP67-rated metal housing, reverse polarity and short circuit protection, this sensor ensures durability and precision. Its M12 quick connector, up to 800Hz switching frequency, and standard 8mm sensing distance make installation and operation swift and seamless, making it a preferred choice for modern industry.

Features, Applications, and Versatility

The OMRON E2B-M18LS08-M1-B1 proximity sensor distinguishes itself with a short body design, nickel-plated brass housing, and reliable IP67 ingress protection. Its standard industry sensitivity and robust construction support a range of application media, including metals and machine components. Ideal for commercial use in industrial automation, this device excels in non-contact object detection, motion monitoring, and limit positioning across manufacturing, packaging, and process environments.

Supply Ability, Domestic Market & Sample Policy

Freight efficiency and timely delivery are integral to our service, ensuring a smooth supply of the OMRON E2B-M18LS08-M1-B1 sensor to the domestic market. With a strong supply ability, we serve traders and wholesalers nationwide. We offer a transparent sample policy, allowing product evaluation at a competitive list price. Domestic mar (market) customers benefit from responsive support, and international export is streamlined for all commercial partners.

FAQ's of OMRON PROXIMITY SENSOR 10 TO 30VDC, E2B-M18LS08-M1-B1:

Q: How do I install the OMRON PROXIMITY SENSOR E2B-M18LS08-M1-B1?

A: The sensor uses a flush mount with an M18 thread and connects via an M12 quick connector. Ensure correct alignment and secure the housing for optimum functionality.

Q: What are the primary applications of this proximity sensor?

A: It is designed for position sensing, limit switching, and motion detection in industrial automation, manufacturing, and process monitoring environments.

Q: When should I use a PNP normally open (NO) output sensor like this?

A: Use this sensor when you require an output signal to be 'on' when an object is detected, which is standard for many automation control systems.

Q: Where is the OMRON E2B-M18LS08-M1-B1 best suited for commercial use?

A: This sensor is ideal for use in factories, assembly lines, and automated machinery where non-contact detection and durability are crucial.

Q: What benefits does the reverse polarity and short circuit protection offer?

A: They safeguard the sensor and connected devices, prolonging operational life and ensuring reliable performance even in challenging electrical conditions.
