OMRON PRXIMITY SENSOR, E2E-X5MY2

OMRON PRXIMITY SENSOR, E2E-X5MY2 Specification

Response Time
10 ms

Sensor Type
Proximity Switch

Application
Industrial automation, conveyer systems, packing machinery

Features
Robust design, easy installation, high switching frequency

Interface
2-wire AC connection

IP Rating
IP67

Mounting Type
M12 threaded, flush

Cable Length
2m

Power Consumption
2.0 VA

Signal Type
NO (Normally Open)

Operating Temperature
-25C to +70C (non-freezing, non-condensing)

Measurement Range
5 mm (sensing distance)

Wireless
No

Sensitivity
Standard type (iron/ferrous metal target)

Product Type
Proximity Sensor

Material
Nickel-plated brass housing

Input
24 to 240 VAC

Output
Relay output (2-wire AC, NO)

Function
Non-contact object detection

Usage
Position and presence detection

Accuracy
High accuracy, reliable detection

Voltage
24 to 240 VAC

Weight
Approx. 110g (with 2m cable)

Housing Diameter
M12 (12mm)

Max Switching Frequency
20 Hz

Set Distance
0 to 4 mm

Indicator
Operation indicator (LED)

Shock Resistance
1,000 m/s², 10 times each in X, Y, Z directions

Max Switching Current
200 mA

Connection Type
Pre-wired cable

Storage Temperature
-40°C to +85°C

Model Number
E2E-X5MY2

Detection Method
Inductive

Standards Compliance
CE, RoHS

Environmental Resistance
Oil-resistant, water-resistant housing

Target
Ferrous metal (optimal for mild steel)

Protection Circuitry
Surge suppressor, overcurrent protection

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

About OMRON PRXIMITY SENSOR, E2E-X5MY2

Discover the OMRON PRXIMITY SENSOR, E2E-X5MY2, engineered to deliver unrivaled performance and pristine detection for industrial automation. With a select, nickel-plated brass housing and an incomparably robust design, this high-accuracy sensor features inductive detection, a 5 mm range, and supports reliable position and presence detection at an unbeatable price. Enjoy reduced price, premium quality, and reliability, ideal for conveyor systems and packing machinery. Certified to CE and RoHS standards, it combines swift response, exceptional shock and vibration resistance, and superior protection features for demanding environments.

Versatile and Robust Sensor for Industrial Precision

The OMRON PRXIMITY SENSOR, E2E-X5MY2, is tailored for high-precision, non-contact object detection in demanding industrial environments. Its advanced featuresincluding an operation indicator LED, oil- and water-resistant housing, and overcurrent protectionguarantee reliability. Whether its managing conveyor systems, automating packing processes, or ensuring flawless position and presence sensing, this sensors rugged construction and high sensitivity to ferrous metals make it an invaluable component for any industrial automation project.

Premium Sample, Prompt Delivery, and Professional Packaging

Obtain a sample of the OMRON PRXIMITY SENSOR, E2E-X5MY2 to experience its premium performance firsthand. We offer fast dispatching after confirming the asking price, ensuring timely delivery for your business needs. Each sensor is meticulously packaged to maintain pristine condition during transit, guaranteeing safe arrival. Our trusted supply network from China enables efficient service for traders, wholesalers, and suppliers seeking reduced price options without compromising on quality.

FAQs of OMRON PRXIMITY SENSOR, E2E-X5MY2:

Q: How does the OMRON E2E-X5MY2 proximity sensor detect objects?

A: This sensor uses inductive detection technology to recognize ferrous metal targets without making physical contact, optimizing accuracy for mild steel and similar applications.

Q: What are the main applications for the E2E-X5MY2 sensor?

A: The E2E-X5MY2 is widely used in industrial automation, particularly for conveyor systems and packing machinery, where high-precision position and presence detection are essential.

Q: How is the OMRON E2E-X5MY2 installed in machinery?

A: Its M12 threaded, flush-mount design allows for secure and easy installation, and the pre-wired 2m cable offers convenient connectivity within equipment or process lines.

Q: What advantages does the OMRON proximity sensor offer in tough environments?

A: With an IP67 rating, oil- and water-resistant housing, and robust vibration and shock resistance, this sensor delivers reliable performance in harsh industrial settings.

Q: Where can samples of the E2E-X5MY2 sensor be requested?

A: Samples are available through authorized suppliers, traders, or wholesalers, especially when requesting a quote on the asking price and arranging for prompt dispatching from stock in China.
