OMRON POWER SUPPLY 24VDC, S8FS-G60024C

OMRON POWER SUPPLY 24VDC, S8FS-G60024C Specification

Output Type
Single

Power Factor
>0.90 at 230VAC full load

Features
High Reliability, Long-life Design, Conforms to EN/IEC Standards

Cooling Method
Natural Air Cooling

Rated Current
25A

Connector Type
Screw Terminal

Application
Industrial Automation Equipment, Control Panels

Rated Power
600W

Current Range
0-25A

Noise Level
Less than 50 dB

Output Current
25A

Power Supply
AC-DC

Operating Temperature
-25C to +60C

Working Temperature
-25C to +60C

Phase
Single Phase

Product Type
Switching Power Supply

Output Power
600 W

Output Frequency
50/60 Hz (Input)

Input Voltage
100-240 VAC, 2.0-1.0A, 50/60Hz

Voltage Protection
Overvoltage, Overcurrent, Short-circuit Protection

Efficiency
Typically 89%

Material
Metal (Enclosure)

Line Regulation
0.5%

Storage Temperature
-25C to +65C

Weight
Approx. 1.7 kg

Dielectric Strength
3.0 kVAC (input to output)

Insulation Resistance
100 M min. (at 500 VDC)

Altitude
Up to 2,000 m

Ripple & Noise
Less than 120 mVp-p

Ingress Protection Rating
IP20

Dimensions
121 x 82 x 158 mm (H x W x D)

Output Voltage Adjustment Range
22.8 to 26.4 VDC

Mounting Method
DIN Rail or Panel Mount

Cooling System
Convection

About OMRON POWER SUPPLY 24VDC, S8FS-G60024C

Last Chance to get the rarefied OMRON POWER SUPPLY 24VDC, S8FS-G60024C, engineered for those who seek marvelous performance and sublime reliability. Personalise your industrial automation setup with 600W output, adjustable voltage range (22.8-26.4 VDC), and a robust metal enclosure. This unit offers overvoltage, overcurrent, and short-circuit protection for comprehensive safety. With high efficiency (89%) and silent, convection-based cooling, it's designed for longevity. IP20 rated, panel or DIN rail mountable, and conforming to strict EN/IEC standards, it's an exceptional solution for demanding environments.

Versatile Applications in Industrial Automation

The OMRON POWER SUPPLY 24VDC, S8FS-G60024C excels in diverse application areas including control panels and plant automation systems. It's ideal for powering industrial automation equipment, offering stable single-phase output to ensure precision in process controls and machinery operation. Specifically used in environments requiring reliable voltage regulation and safety, this power supply supports critical applications across manufacturing and processing plants, making it a valuable addition to any modern industrial setting.

Premium Packaging, Trusted Transport, and Flexible Payment

Enjoy premium packaging with the OMRON POWER SUPPLY 24VDC, S8FS-G60024C, reflecting its valuation as a trusted industrial product. Our dedicated transport services guarantee safe delivery directly to your location. Payment terms are flexible, tailored to meet your procurement requirements. The standard FOB Port is China, ensuring global shipment accessibility. Each order is handled with careful attention, reinforcing product security from warehouse to destination.

FAQ's of OMRON POWER SUPPLY 24VDC, S8FS-G60024C:

Q: How does the voltage adjustment feature benefit users?

A: The output voltage adjustment range (22.8 to 26.4 VDC) allows users to precisely tailor the power supply output, accommodating various equipment requirements and enhancing operational flexibility.

Q: What application areas can the OMRON S8FS-G60024C be used for?

A: This power supply is ideal for industrial automation equipment, control panels, and plant applications where consistent and reliable 24VDC output is essential.

Q: Where can the OMRON POWER SUPPLY 24VDC be mounted?

A: It can be conveniently installed using either DIN Rail or Panel Mount methods, enabling integration into diverse industrial setups.

Q: What protection features are included in this model?

A: It offers overvoltage, overcurrent, and short-circuit protection to ensure safe operation and safeguard connected devices against power anomalies.

Q: How efficient is the power supply and what are its cooling methods?

A: With up to 89% efficiency and a natural convection cooling system, the S8FS-G60024C operates efficiently and quietly, making it suitable for noise-sensitive environments.
