OMRON PHOTOELECTRIC SWITCH ,E3Z-D62

OMRON PHOTOELECTRIC SWITCH ,E3Z-D62 Specification

Finish Type
Molded

Temperature Range
-25 to +55C

Response Time
1 ms max.

Max. Current
100 mA (Load current)

Mechanical Life
Not Applicable (Solid-state Device)

Circuit Type
NPN Open Collector Output

Protection Level
IP67

Automation Grade
Automatic

Rated Voltage
12 to 24 VDC

Number of Module
Single

Product Type
Photoelectric Switch

Material
PBT (Polybutylene Terephthalate) housing

Insulation Resistance
20 M min. (at 500 VDC)

Contact Resistance
Not Applicable (Solid-state Output)

Max. Voltage
26.4 VDC

Operating Temperature
-25 to +55C (no icing or condensation)

Size
10.8 mm x 20 mm x 31 mm (W x H x D)

Color
Black

Weight
Approx. 65 g (including cable)

Mounting Type
Panel/Surface Mount

Current Rating
100 mA maximum (load current)

No Of Poles
3-wire (NPN output)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Light Source
Red LED (660 nm)

Reverse Polarity Protection
Yes

Short-circuit Protection
Yes

Shock Resistance
500 m/s2, 3 times in each direction

Supply Voltage
12 to 24 VDC 10%

Output Type
NPN

Indicators
Operation indicator (orange), Stability indicator (green)

Applicable Standard
CE, RoHS

EMC
EN60947-5-2 compliant

Sensing Distance
100 mm

Cable
Standard pre-wired, 2 m

Sensing Method
Diffuse-reflective

Connection Method
Pre-wired type

About OMRON PHOTOELECTRIC SWITCH ,E3Z-D62

Spotlight the eminent OMRON PHOTOELECTRIC SWITCH, E3Z-D62, for unrivaled precision in automation. Featuring a diffuse-reflective sensing method with a 100 mm range and equipped with an excellent red LED (660 nm) for stable detection, this switch delivers both reliability and efficiency. Benefit from easy access to its advanced functions: NPN output, robust PBT housing, and IP67 protection. Buy now to access top-tier short-circuit and polarity protection, CE and RoHS compliance, and solid-state excellence-an ideal choice for any industrial application.

Superior Plant Integration & Competitive Edge

The OMRON PHOTOELECTRIC SWITCH, E3Z-D62, is designed for seamless integration in automated plant environments. Its primary competitive advantages include unrivaled reliability, EMC compliance, and robust IP67 protection. Extra features such as quick response time, dual indicators, and solid-state output guarantee optimum performance. Eminently suited for demanding tasks, this sensor elevates operational efficiency and safety, making it the excellent choice for industries seeking both innovation and value.

Sample Policy & Pricing Essentials

Requesting a sample of the OMRON E3Z-D62 is straightforward, with rates and asking prices structured for convenience. Samples are shipped from the designated FOB port in China, ensuring prompt delivery. Estimates can be tailored to your needs, and the main domestic market benefits from dedicated support and reliable supply. Connect with suppliers and traders for your best pricing estimate and to explore flexible access options for varied industrial requirements.

FAQ's of OMRON PHOTOELECTRIC SWITCH ,E3Z-D62:

Q: How does the OMRON E3Z-D62 photoelectric switch operate?

A: The OMRON E3Z-D62 functions using a diffuse-reflective sensing method, detecting objects by analyzing reflected light from its red LED emitted at 660 nm. It offers precise object detection within a 100 mm distance, making it suitable for automatic, high-speed applications.

Q: What are the main usage benefits of this switch in industrial settings?

A: This switch provides excellent vibration and shock resistance, IP67 protection for demanding conditions, and rapid 1 ms response time, all ensuring reliable operation and minimal downtime in automated production lines.

Q: When should I choose a diffuse-reflective sensor like the E3Z-D62?

A: Choose this sensor when you require non-contact object detection in environments where direct interaction with the object is not ideal, especially within short sensing distances up to 100 mm and in applications demanding high reliability.

Q: Where can the E3Z-D62 be easily installed?

A: Thanks to its compact size and panel/surface mounting options, the E3Z-D62 can be efficiently installed on various types of machinery and conveyor systems, making it versatile for use across multiple industrial domains.

Q: What extra protective features does the E3Z-D62 offer?

A: The sensor includes built-in short-circuit and reverse polarity protection. It is also compliant with CE, RoHS, and EMC standards, and its PBT housing shields internal components from dust, moisture, and mechanical stresses.

Q: How can I initiate the purchasing process and request samples?

A: Simply contact the supplier or wholesaler based in China to request a sample or quotation. They will provide detailed rates, asking prices, and estimate timelines appropriate for your quantity and market.
