OMRON LIMIT SWITCH, ZC-W2155, E32-D12, E32-TC200, E32-TC200E, E32-D11N

OMRON LIMIT SWITCH, ZC-W2155, E32-D12, E32-TC200, E32-TC200E, E32-D11N Specification

Rated Voltage
250VAC/24VDC

Circuit Type
SPDT (Single Pole Double Throw)

Response Time
1 ms max.

Number of Module
Single

Max. Current
5A

Temperature Range
-25C to +70C

Automation Grade
Automatic

Finish Type
Epoxy Coated

Protection Level
IP67

Mechanical Life
10,000,000 operations min.

Product Type
Limit Switch, Fiber Optic Sensor Unit

Material
Zinc Alloy, Resin, Polycarbonate

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial)

Max. Voltage
250 VAC

Operating Temperature
-25C to +70C

Stoke
1 mm to 3 mm (depending on model)

Size
Standard, compact head sizes

Color
Black/Gray

Weight
Approx. 120g (varies by model)

Mounting Type
Panel Mount, Screw Mount

Current Rating
5A

No Of Poles
1 pole

Switching Capacity
5A at 250 VAC (resistive load)

Shock Resistance
1,000 m/s² min.

Fixing Method
Pre-drilled mounting holes

Contact Type
Snap Action

Cable Length
2m (standard for fiber sensor units)

Actuator Type
Plunger, Rod, Fiber Optic Head (model-dependent)

Body Dimensions
varies with model, see datasheet

Fiber Type
Coaxial/Through-beam (E32 models)

Accessory
Mounting screws included

Ambient Humidity
35%-95% RH (no condensation)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Torque for Mounting Screw
0.59 to 0.78 N·m

Head Shape
Roller Plunger, Fiber Head Type

Sensing Method
Mechanical (limit switch), Fiber Optic (E32 series)

About OMRON LIMIT SWITCH, ZC-W2155, E32-D12, E32-TC200, E32-TC200E, E32-D11N

Discover the Best-seller OMRON LIMIT SWITCH series: ZC-W2155, E32-D12, E32-TC200, E32-TC200E, E32-D11N. These sought-after switches offer Marvelous reliability and first-class durability, with options for plunger, rod, and fiber optic actuator types. Featuring fresh designs and Hot deal value, their snap-action contacts deliver switching capacity up to 5A at 250 VAC. With robust IP67 protection, vibration and shock resistance, and versatile fiber optic sensing (standard 2m cable), these automation-grade switches excel in demanding environments. Mounting hardware included for effortless installation.

Versatile Usage & Key Advantages

OMRON LIMIT SWITCH models are well-suited for automation systems, mechanical machinery, and safety interlocks. Their distinct advantage lies in robust performance, long mechanical life, and accurate response times. Ideal for environments needing precise actuation, these switches are utilized in conveyor systems, industrial doors, and fiber optic detection setups, providing dependable results across multiple applications.

Main Domestic Market & Certifications

Stock ready for immediate dispatch, with Express Shipping and quick Handed Over for urgent requirements. OMRON LIMIT SWITCHES serve premier markets across India, as well as global clients. Models are certified to industry electrical standards ensuring safe operations. Payment terms include advance, net banking, and cash on delivery, catering to wholesalers, suppliers, and traders. Quality assurance is always prioritized.

FAQ's of OMRON LIMIT SWITCH, ZC-W2155, E32-D12, E32-TC200, E32-TC200E, E32-D11N:

Q: How do I select the right OMRON LIMIT SWITCH model for my application?

A: Choose your model based on actuator type (plunger, rod, fiber optic), sensing method (mechanical or fiber optic), and required switching capacity. Refer to the datasheet for specific body dimensions and operational details.

Q: What are the main benefits of using OMRON LIMIT SWITCHES in automation systems?

A: These switches offer precise response, high durability (up to 10,000,000 cycles), and excellent resistance to vibration/shock. IP67 protection ensures reliability in harsh environments.

Q: When should I use the fiber optic head version over mechanical models?

A: Fiber optic head models are best for detecting transparent objects, long-range sensing, or tight spaces where traditional mechanical switches are impractical.

Q: Where can OMRON LIMIT SWITCHES be installed?

A: They can be mounted on machinery, control panels, conveyor lines, and automated production systems using pre-drilled mounting holes or screw mounts as specified.

Q: What is the process for installation and setup?

A: Install using provided mounting screws and pre-drilled holes. Connect wiring as per the circuit type (SPDT), and ensure proper torque for mounting screws. Verify insulation and contact resistance prior to commissioning.

Q: How does usage in industrial applications improve performance?

A: With accurate switching, fast response time, and robust construction, these switches reduce downtime and enhance operational safety for industrial automation.
