OMRON PHOTOELECTRIC SENSOR, E3JM-DS70M4T-G

OMRON PHOTOELECTRIC SENSOR, E3JM-DS70M4T-G Specification

Operating Temperature
-25C to +55C

Power Consumption
2.5 VA max. (AC), 1.5 W max. (DC)

Sensor Type
Photoelectric Sensor

Sensitivity
Adjustable by potentiometer

Signal Type
Light ON/Dark ON Selectable

Cable Length
2 m

IP Rating
IP66

Interface
Cable Connection

Application
Assembly Lines, Packaging, Material Handling

Wireless
No

Measurement Range
700 mm (max. for white paper, diffuse reflective)

Response Time
20 ms max.

Features
LED Operation Indicator, Sensitivity Adjustment

Mounting Type
Panel or Surface Mount

Product Type
Photoelectric Sensor

Material
Plastic Housing

Input
12 to 240V AC/DC

Output
Relay SPDT

Function
Diffuse-Reflective Sensing Type

Usage
Object Detection in Industrial Automation

Accuracy
High Accuracy Detection

Voltage
12-240V AC/DC

Weight
Approx. 180 g

Polarization
None (Diffuse Type)

Ambient Humidity
35% to 85% RH, non-condensing

Case Material
ABS Resin

Shock Resistance
500 m/s2 (approx. 50G), 3 times each in X, Y, Z directions

Setting Distance
70 cm (rated)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Control Output Capacity
250VAC 3A Resistive Load max.

Detection Method
Diffuse Reflective

Connector Type
Prewired

Indicator
Operation Indicator (Red), Stability Indicator (Green)

Light Source
Red LED (660 nm)

OMRON PHOTOELECTRIC SENSOR, E3JM-DS70M4T-G About

Unlock sizzling performance with the OMRON PHOTOELECTRIC SENSOR, E3JM-DS70M4T-G - an impeccable, customizable solution for discerning automation professionals. This potent sensor leverages a Red LED (660 nm) for uncommon accuracy, featuring diffuse-reflective detection within a robust ABS resin housing. Ready for hot deals in industrial environments, it boasts a 70 cm setting distance, high vibration and shock resistance, adjustable sensitivity, and IP66 protection. Prewired with a reliable SPDT relay output, this sensor is engineered for versatile object detection, ensuring seamless integration into demanding assembly lines and packaging operations.

Versatile Performance and Specialized Usage

The OMRON PHOTOELECTRIC SENSOR, E3JM-DS70M4T-G is frequently used in assembly lines, packaging, and material handling tasks, thanks to its high accuracy and potent diffuse-reflective sensing. Its special features include adjustable sensitivity, IP66-rated protection, and both light ON/dark ON selection options. This customizable sensor is ideal for automation systems seeking reliable and speedy object detection amidst variable industrial settings.

Global Export Reach and Trusted Certification

With a thriving presence in key export markets, the OMRON PHOTOELECTRIC SENSOR, E3JM-DS70M4T-G is favored by clients worldwide for its secure shipping practices and timely order completion. Certified to meet international standards, this product is often available for sample provision under mutually agreed terms. Professional traders, suppliers, and wholesalers in China ensure unparalleled service and support for every transaction.

FAQ's of OMRON PHOTOELECTRIC SENSOR, E3JM-DS70M4T-G:

Q: How does the OMRON PHOTOELECTRIC SENSOR, E3JM-DS70M4T-G achieve high detection accuracy?

A: It uses a potent Red LED (660 nm) light source and diffuse-reflective sensing, providing precise object detection with adjustable sensitivity for customized performance.

Q: What are the main applications of this photoelectric sensor?

A: This sensor is widely used in assembly lines, packaging machinery, and material handling systems for reliable and fast object detection in industrial automation environments.

Q: Where can I mount the E3JM-DS70M4T-G sensor?

A: You can mount the sensor on panels or surfaces, making installation easy for a variety of industrial equipment and setups.

Q: What certifications and export policies are associated with this sensor?

A: The sensor conforms to key international standards, and sample policies are available upon agreement. Secure packaging and order completion ensure delivery to major export markets.
