OMRON PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RN11

OMRON PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RN11 Specification

Signal Type
Digital

Features
Compact size, LED indicator, Short-circuit protection

Cable Length
2m Meter (m)

Sensor Type
Retro-reflective

Wireless
No

Operating Temperature
-25°C to +55°C Celsius (oC)

IP Rating
IP67

Mounting Type
Panel or surface mount

Interface
Wired

Measurement Range
0 to 4m (with E39-R1 reflector)

Sensitivity
Adjustable

Application
Position and presence detection

Product Type
Photoelectric Sensor

Material
Plastic

Input
10 to 30VDC

Output
NPN (Normally Open/Normally Closed)

Function
Object Detection

Usage
Industrial Automation

Resolution
Reliable object recognition

Voltage
10 to 30VDC Volt (v)

Weight
Approx. 65g Grams (g)

Reflector Model
E39-R1 compatible

Vibration Resistance
10 to 55 Hz, 1.5mm double amplitude

Short Circuit Protection
Yes

Reverse Polarity Protection
Yes

Light Source
Red LED (660nm)

Enclosure Material
ABS Plastic

Storage Temperature
-40C to +70C

Connection Method
Pre-wired cable

Dimension
Diameter 18mm, Length 62mm

Shock Resistance
500m/s2, 3 times each direction

Indicator
Operation indicator (LED)

EMC Standards
Conforms to EN60947-5-2

Ambient Humidity
35% to 85% RH

OMRON PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RN11 Trade Information

Minimum Order Quantity
20 Number

Supply Ability
1000 Per Month

Delivery Time
7 Days

OMRON PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RN11 About

Experience the incomparable efficiency of the OMRON PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RN11an acclaimed, hot-selling solution in industrial automation. Engineered for sublime reliability, this retro-reflective sensor is customizable to diverse environments and offers venerable accuracy with a measurement range up to 4m using an E39-R1 reflector. Its compact, ABS plastic enclosure ensures robust vibration and shock resistance, while built-in LED indicators provide clear operation status. Enjoy precise, reliable object detection aided by short circuit and reverse polarity protection, conforming to stringent international EMC standards. Suitable for suppliers, traders, and wholesalers in China.

Application Excellence: Direction, Advantage, and Usage

The OMRON PHOTOELECTRIC SENSOR E3FA-RN11 is designed for industrial automation where rapid, reliable object detection is paramount. Simply mount on panels or surfaces and connect via the pre-wired 2m cable. Its main advantage lies in sublime accuracy and high sensitivity, making it suitable for position and presence detection applications. With adjustable sensitivity and a robust IP67 rating, this sensor excels in both challenging and routine environments that demand continuous uptime and precise performance.

Shipping, Packaging, and Payment Value

Shipped promptly from Chinas key FOB ports, the OMRON E3FA-RN11 sensor ensures secure delivery through reliable transport services. Packaging is meticulously designed for safe transit, providing optimal product protection during bulk or individual shipments. Payment terms are highly valued by clients, accommodating various transaction preferences to streamline procurement. This enables efficient project execution and favorable business relationships for suppliers, traders, and wholesalers seeking top-tier automation components.

FAQs of OMRON PHOTOELECTRIC SENSOR 10 TO 30VDC, E3FA-RN11:

Q: How do I install the OMRON E3FA-RN11 photoelectric sensor?

A: Installation is straightforward; mount the sensor on your desired panel or surface using the provided accessories, and connect the pre-wired 2m cable to your system according to the wiring diagram in the manual.

Q: What types of objects can this sensor reliably detect?

A: The E3FA-RN11 is designed for accurate object and presence detection in industrial automation, capable of recognizing a wide range of materials at distances up to 4 meters with a compatible E39-R1 reflector.

Q: When should I consider adjusting the sensors sensitivity?

A: Adjust the sensors sensitivity when optimizing detection distance for smaller, transparent, or uniquely shaped objects, or when adapting to varying environmental conditions for maximum performance.

Q: Where can this sensor be typically used?

A: It is ideal for industrial automation environments, including assembly lines, material handling, and conveyor systems requiring dependable object and position detection.

Q: What benefits does the OMRON E3FA-RN11 offer compared to similar sensors?

A: It stands out with its high accuracy, stellar reliability, quick response time under 1ms, and added protections such as short-circuit and reverse polarity safeguards, all in a compact, durable enclosure.

Q: How is the sensor maintained for long-term operation?

A: Routine inspection for dust or contaminants on the lens, checking secure mounting and connection integrity, and ensuring no damage to the pre-wired cable will help maintain optimal sensor function.
